IPEC-0101FT
1-Port 10/100TX to 100M-FX
User Manual
V1.00
Sep-2007
Slim Type Media Conv erter w/PoE injector
FCC Warning
This Equipment has been tested and found to comply with the limits for a
Class-A digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy. It may cause harmful interference to radio
communications if this equipment is not installed and used in accordance
with the instructions. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
Content
Introduction................................................................ 1
Features................................................................... 1
Package Contents.................................................... 2
Hardware Description ............................................... 3
Physical Dimension.................................................. 3
Front Panel .............................................................. 3
Top View.................................................................. 4
LED Indicators ......................................................... 5
DIP-Switch............................................................... 6
Ports......................................................................... 7
Cabling..................................................................... 9
Wiring the Power Inputs......................................... 10
Wiring the Fault Alarm Contact.............................. 11
Mounting Installation .............................................. 12
DIN-Rail Mounting.................................................. 12
Wall Mount Plate Mounting.................................... 14
Hardware Installation.............................................. 15
Installation Steps.................................................... 15
Network Application................................................ 16
Troubles shooting ................................................... 17
Technical Specification........................................... 18
1
Introduction
The 1 10/100TX + 100FX w/ 1 PoE Injector Industrial Switch is a cost-effective solution
and meets the high reliability requirements demanded by industrial applications. Using
fiber port can extend the connection distance that increases the network elasticity and
performance. Besides, the industrial switch provides the PoE function for kinds of
Powered Devices to receive power as well as data over the RJ-45 cable.
Features
System Interface/Performance
¾RJ-45 ports support Auto MDI/MDI-X Function
¾Embedded 1-port PoE Injection
¾Store-and-Forward Switching Architecture
¾Built-in Link Lose Forwarding Technology
Power Supply
¾DC 48V Redundant Power
¾Overload Current Re-settable Fuse Present
Case/Installation
¾IP-30 Protection
¾DIN Rail and Wall Mount Design
Provides EFT protection 3,000 VDC for power line
Supports 6,000 VDC Ethernet ESD protection
2
Package Contents
Please refer to the package contents list below to verify them against the checklist.
1 10/100TX + 100FX w/ 1 PoE Injector Industrial Switch
User manual
Pluggable Terminal Block
2 wall mount plates with screws
One DIN-Rail (attached on the switch)
Compare the contents of the industrial switch with the standard checklist above. If any
item is damaged or missing, please contact the local dealer for service.
3
Hardware Description
In this paragraph, the Industrial switch’s hardware spec, port, cabling information, and
wiring installation will be described.
Physical Dimension
1 10/100TX + 100FX w/ 1 PoE Injector Industrial Switch dimension (W x D x H) is 30mm
x 95mm x 140mm
Front Panel
The Front Panel of the 1 10/100TX + 100FX w/ 1 PoE Injector Industrial Switch is shown
as below:
Front Panel of the PoE Injectors Industrial Switch
4
Top View
The top view of the 1 10/100TX + 100FX w/ 1 PoE Injector Industrial Switch has one
terminal block connector of two DC power inputs.
Top View of the PoE Injectors Industrial Switch
5
LED Indicators
The diagnostic LEDs located on the front panel of the industrial switch provide real-time
information of system and optional status. The following table provides the description of
the LED status and their meanings for the switch.
LED Color Description
On Power input 1 is active
P1 Green
Off Power input 1 is inactive
On Power input 2 is active
P2 Green
Off Power input 2 is inactive
On Power input 1/2 or port connections failed
Fault Red
Off Power input 1/2 and port connections are functional, or
no power inputs
On Full-duplex modeFDX/COL
(fiber port) Yellow Flashing Collision occurs
On Connected to network
Flashing Networking is active
LNK/ACT
(fiber port) Green
Off Not connected to network
On Linking to 100Mbps network
100M (RJ-45) Yellow Off Linking to 10Mbps network or disconnected
On Connected to network
Flashing Networking is active
LNK/ACT (RJ-
45) Green
Off Not connected to network
On The port is supplying power to the powered-device
FWD Green
Off No powered-device attached or power supplying fails
6
DIP-Switch
The DIP-Switch is used to configure operation mode for LLF (Link Lose
Forwarding)/LFP (Link Fault Pass-Through), and operation mode for UTP/Fiber port.
The default value of DIP-switch is OFF.
S/W No Status Description
ON Enables Port/Power Alarm
1 OFF Disable Port/Power Alarm
ON Enables LLF/LFP
2 OFF Disables LLF/LFP
ON 100Base-FX Half-mode
3 OFF 100Base-FX Full-mode
ON Media mode (100TX to 100FX)
4 OFF Switching mode
LLF/LFP (DIP-Switch 2): Enabling LLF/LFP allows UTP/STP link failures to be
reported to the fiber side and also allows Fiber link failures to be reported to the
UTP/STP side. Therefore, a LLF/LFP feature is provided in both UTP/STP and Fiber
side.
Media mode (DIP-Switch 4): When media mode is enabled (ON), it operates with the
minimum latency. The transmission flow does not wait until entire frame is ready, but
instead it forwards the received data immediately after the data being received. And
TP port should be forced at 100M in this application. When DIP-Switch is set in
switching mode (OFF), the function is the same as a Switch/Hub.
Note Please don’t change the DIP-switch setting when UTP/STP or
fiber port is transmitting or receiving data. It may cause some
data error. Besides, if you change the DIP-switch setting, please
power off the switch and power on again to make the setting
effective.
7
Ports
RJ-45 ports
The UTP (RJ-45) Fast Ethernet ports will auto-sense for 10Base-T or 100Base-TX
connections. Auto MDI/MDIX means that the switch can connect to another switch or
workstation without changing straight through or crossover cabling. See the below
figures for straight through and crossover cable schematic.
RJ-45 Pin Assignments
Pin Number Assignment
1 Tx+
2 Tx-
3 Rx+
6 Rx-
Note “+” and “-” signs represent the polarity of the wires that make up each wire
pair.
All ports on this industrial switch support automatic MDI/MDI-X operation, user can use
straight-through cables (See figure below) for all network connections to PCs or servers,
or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of
the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the
cable. The table below shows the 10BASE-T/100BASE-TX MDI and MDI-X port pin outs.
Pin MDI-X Signal Name MDI Signal Name
1 Receive Data plus (RD+) Transmit Data plus (TD+)
2 Receive Data minus (RD-) Transmit Data minus (TD-)
3 Transmit Data plus (TD+) Receive Data plus (RD+)
6 Transmit Data minus (TD-) Receive Data minus (RD-)
