16 17
Regulatory Compliance
Type BF Applied Part
To maintain your power adaptor follow these instructions:
Troubleshooting
Troubleshooting the Lansinoh Afnity®Pro Double Electric Breast Pump
Interruption of Electrical Service
If you experience an interruption in the normal operation of the electrical and/or
mechanical functioning of the pump, simply do the following:
n Unplug the AC adapter cord from the electrical outlet.
n Wait a few seconds, and then plug the AC adapter cord back into the electrical outlet.
If you still experience electrical failure, try using the pump with the six AA batteries
making sure the AC adapter is removed.
Discomfort While Pumping
If you feel any discomfort, you may need a different size ange.
Visit www.lansinohstore.com or call 800-292-4794.
Decreased Suction
If it feels like the suction has decreased, try the following:
n Remove the tubing from pump and place a nger over the tubing connector. If you
feel suction, the pump is operating properly, but the Breastmilk Expression Set may
not be correctly assembled or the white valve may be damaged. If no suction is felt
on your nger, try unplugging the adapter from the electrical outlet, wait a few
seconds, and plug it back into the electrical outlet.
n Make sure the Breastmilk Expression Set has been properly assembled. Check the
assembly information in the section “Assembling the Breastmilk Expression Set”, page 10.
n Inspect the white valve for a tear or pinhole. This component is critical to achieving
proper suction. Replace the white valve with one of the spare valves provided with
the product.
nWhen single pumping, check the tubing connector on the front of the pump to make
sure it is closed for single pumping. If open, close the connector.
nIf double pumping, ensure that the breastmilk expression set is on both breasts
before starting the pump.
Increased suction level for single pumping:
If it feels like the suction is higher than usual when single pumping, check that the plug
for the tubing is clean and that the airway in the plug is not blocked.
DO NOT wrap cord
of power adaptor
around the plug body.
CORRECT DO NOT unplug
power adaptor by
pulling on the cord.
CORRECT
DO NOT use power adaptor if damaged.
Technical Data
Power Requirements
AC Adapter (included)
AC Adapter – North American
Plug Conguration
110Vac/220Vac wall plug type
AC adaptor, galvanically isolated
adaptor with 9Vdc output voltage.
Batteries (not included)
6 AA batteries, 1.5V alkaline
Regulatory Compliance
UL (E302267 ) and CSA approved
with North American power adapter.
Technical Data Warranty
Limited Consumer Product Warranty (United States)
This product is warranted to the original consumer purchaser (the “purchaser”)
to be free from defects in material and workmanship which are not commercially
acceptable for the period of one year from the date of purchase on the pump
mechanism and the period of 90 days on all other product components. Warranty
coverage terminates if you sell or otherwise transfer this product to another person.
This warranty gives you specic legal rights and you may also have other rights,
which vary, by location.
LANSINOH® MAKES NO EXPRESS WARRANTY OF ANY KIND REGARDING
THE PRODUCT OTHER THAN THOSE WARRANTIES EXPLICITLY SET FORTH
HEREIN. ANY IMPLIED WARRANTY, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR ANY IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, TO THE EXTENT PERMITTED BY LAW, SHALL BE
LIMITED IN DURATION TO A PERIOD OF 90 DAYS FROM THE DATE OF
PURCHASE BY THE ORIGINAL PURCHASER.
In the event the product is found by Lansinoh®to not meet the above limited
warranty, as purchaser’s sole and exclusive remedy Lansinoh®will repair or, at the
option of Lansinoh®, replace this product without charge for such replacement or
parts or labor.
NOTE: The purchaser shall bear all expense for returning this product
to Lansinoh®. This warranty does not apply to any product that has
been subjected to misuse, abuse, or alteration.
Only Lansinoh®brand replacement parts are recommended for use with Lansinoh®
breastfeeding products. Improper or incorrectly performed maintenance or repair, or
use of non-Lansinoh® brand replacement parts may invalidate this warranty.
TO THE EXTENT PERMITTED BY LAW, LANSINOH®SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES IN-
CLUDING, BUT NOT LIMITED TO, REPLACEMENT COSTS RESULTING
FROM THE BREACH OF ANY WRITTEN OR IMPLIED WARRANTY.
If you wish to make a claim under this warranty, you must return the product to Lan-
sinoh Laboratories Inc., prepaid, together with your dated bill of sale or other dated
proof of purchase and a brief statement of the problem, along with a Replacement
Authorization (RA) number. You may obtain the appropriate Replacement Authoriza-
tion number and shipping address by calling the phone number or sending an email
to the email address provided below.
Items returned without an associated Replacement Authorization Number will be
returned to sender.
To obtain the address to Return Goods or a Replacement Authorization Number:
800-292-4794
Operating
instructions
CLASS II
equipment
Transport /
Storage
Transport /
Storage
!
Caution Operation Operation
!
Warning: Children have STRANGLED in cords.
Keep the cords out of the reach of children.
+122 ˚F
-4 ˚F
+122 ˚F
-4 ˚F 20% - 80%
20% - 95%
104 ˚F
41 ˚F
