Laney Ironheart IRT212 Manuel utilisateur

IRT412A

The Ironheart IRT212,IRT412 & IRT412A are a series of cabinets optimised for use with

IRT120H,IRT60H,IRT60-212 - or indeed any amplifier in the Laney range.

The IRT212 is a 2 x 12” cabinet rated at 160 watts (8 ohms) and can be used in isolation

or combined with other Laney enclosures.Construction features a robust plywood

cabinet, with large top mounted 90 degree bar handles for ease of portability,textured

black fret material,steel corner protection and top mounted castor cups.

Rated at 320 watts (16 ohms) the IRT412 can be used singularly or as paired with an

IRT412A to form an 8 x 12 stack.In addition to the similar design & construction of its

smaller brother,both of the 412's also have a set of robust steel castors to make life easier

on the road.

All the cabinets have similar appearance,all have a great sound,choose whichever combination is best for your rig.

Every Laney product is extensively play tested by

experienced guitarists to ensure it has the tone and

durability to perform at the very highest level,before

being shipped to our customers.

We hope you enjoy using your new extension cabinet

as much as we enjoyed designing and making it.It

should give you years of trouble-free service,however

please take time to read this manual,as it will allow

you to get the best from your Ironheart Cabinet.

Best wishes from all at Laney.

IRT412AIRT412

IRT212

In order to take full advantage of your new product and enjoy long and trouble-free performance,please read this owner's manual

carefully,and keep it in a safe place for future reference.

1).Unpacking:On unpacking your product please check carefully for any signs of damage that may have occurred whilst in transit

from the Laney factory to your dealer.In the unlikely event that there has been damage,please repack your unit in its original carton

and consult your dealer.We strongly advise you to keep your original transit carton,since in the unlikely event that your unit should

develop a fault,you will be able to return it to you dealer for rectification securely packed.

2).Amplifier Connection: In order to avoid damage ,it is advisable to establish and follow a pattern for turning on and off your

system.With all system parts connected,turn on source equipment,tape decks,cd players,mixers,effects processors etc,BEFORE

turning on your guitar amplifier.Many products have large transient surges at turn on and off which can cause damage to your

speakers.

By turning on your guitar amplifier LAST and making sure its level control is set to a minimum,any transients from other equipment

should not reach your loud speakers.Wait till all system parts have stabilised,usually a couple of seconds.Similarly when turning off

your system always turn down the level controls on your guitar amplifier and then turn off its power before turning off other

equipment

3).Cables: Never use shielded or microphone cable for any speaker connections as this will not be substantial enough to handle

the amplifier load and could cause damage to your complete system.

4).Servicing:The user should not attempt to service these products.Refer all servicing to qualified service personnel

IRT212 IRT412/A

Weight 19Kg 30Kg

Impedance 8 Ohms 16 Ohms

Drivers 2 x 12" Custom Designed Driver

Overall

Dimensions W 715 x H 483 x D 358 W 715 x H 728 (over feet) 778 (over

castor) x D 358

Cabinet

Design Rugged plywood construction, black

metal corners, black textured fret

material, castor cups, comfortable top

edge bar handles and rubber feet

Rugged plywood construction, black

metal corners, black textured fret

material, castor cups, comfortable

side bar handles, metal castors and

rubber feet. Choice of angled or

straight design.

4x12" Custom Designed Drivers

Power RMS 160 Watts 320 Watts

Inputs 2 x 6.3 Jack sockets 2 x6.3 Jack sockets

UNPACKING INSTRUCTIONS (IRT412/A)

1. Open the top of the carton, remove the top foam tray, side

protectors and open the protective bag, pull back to sides.

2. Flip the carton over. Cabinet now rests on its castors.

3. Remove the carton, bottom foam tray and protective bag.

4. Enjoy.

IRT412 & IRT412A rear panels are similar 7

OPERATING INSTRUCTIONS Issue 1.1
