Freestanding Fridge Freezer FLM6304/5/6/7
Instructions and Installation
Free 3 year
guarantee
Call now1
0333 010 0009
Alternatively, visit www.howdens.com/appliance-registration
3 year guarantee available.
Register your appliance within 90 days2
By registering your appliance and creating an account,
we will keep you up to date with the latest product information
and notify you immediately of any important product updates
1Lines are open Monday to Friday 9am to 5pm. Calls will be charged at your local rate
and may be recorded and monitored for training and quality purposes.
2So that in the event of an important product update, or recall, we can contact you.
3
Instructions and Installation
3Exclusive to Howdens
04
04
06
06
07
07
09
10
10
10
Contents
Before Using the Appliance
General Warnings
Old and Out-Of-Order Fridges
Safety Warnings
Installing and Operating Your Fridge
Before Using Your Fridge Freezer
Dimensions
The Parts of the Appliance
The Controls and Operation
Thermostat Setting
Warnings about Temperature
Adjustments Accessories 10
Ice tray 11
Freezer boxes 11
Humidity controller 11
Cleaning and Maintenance 12
Defrosting 12
Defrosting the fridge compartment 12
Defrosting the freezer compartment 12
Replacing the light bulb 12
13
13
14
17
17
17
18
Arranging Food in the Appliance
Refrigeration Compartment
Freezer Compartment
Transportation and Changing of Installation Position
Reversing the Door
Before Calling Aftersales Service
Tips for Saving Energy
Your Guarantee 20
Warning; Risk of fire / flammable materials
Warning; Risk of serious injury / death
Warning; Risk of Elecrtric shock Warning; Risk of Injury or Property damage
08
4
www.howdens.com
Freestanding Fridge Freezer FLM6304/5/6/7
4 www.howdens.com
WARNING: Keep ventilation openings in the appliance clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting from the instability of the appliance, it must be
fixed in accordance with the instructions:
If your appliance uses R600a as a refrigerant (this information will be provided on the rating label)
you should take care during transportation and installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and natural gas, but it is explosive. In the event of a
leak due to damage of the cooler elements, move your fridge away from open flames or heat sources
and ventilate the room where the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the refrigerant gas circuit.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
• This appliance is intended to be used in household and domestic applications (see Guarantee
page) such as:
− staff kitchen areas in shops, offices and other working environments.
− farm houses and by clients in hotels, motels and other residential type environments.
– bed and breakfast type environments;
– catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be replaced by a service agent or similarly
qualified persons in order to avoid a hazard.
• An earthed plug has been fitted to the power cable of your refrigerator. This plug should be used with a
suitable earthed socket. If there is no such socket in your house, please have one installed by a qualified
electrician.
Before using the Appliance
General Warnings
5
Instructions and Installation
5Exclusive to Howdens
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children (3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older children (8-14 years old) and vulnerable people can use
appliances safely after they have been given appropriate supervision or instruction concerning use of the
appliance. Very vulnerable people are not expected to use appliances safely unless continuous supervision
is given.
• If the supply cord is damaged, it must be replaced by an authorised service agent, or similarly qualified
person, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding 2000m.
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
• Regularly clean surfaces that come into contact with food and also clean any accessible defrost drainage
channels.
• Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with, or drip
onto other food being stored.
• If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door
open to prevent mould developing within the appliance.
INFORMATION FOR TEST INSTITUTES
Appliance for any EcoDesign verification shall be compliant with EN 62552. Ventilation
requirements, recess dimensions and minimum rear clearances shall be as stated in
this User Manual (Page 10). Please contact the manufacturer for any other further
information, including loading plans.
SUPPLIER’S NAME MODEL IDENTIFIER
A
A
(*)
SUPPLIER’S NAME MODEL IDENTIFIER
A
A
(*)
Information
The model’s technical information can be retrieved by scanning the QR code on the Energy label and
proceeding to the website entering the model identifier.
This product contains a light source of energy efficiency class F.
(Replaceable by a service technician)
6
www.howdens.com
Freestanding Fridge Freezer FLM6304/5/6/7
6 www.howdens.com
Disposal of your old appliance
The symbol on the product or on its packaging indicates that this product may not be treated
as household waste. Instead it shall be handed over to the applicable collection point for
the recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product, please contact your local
council, your household waste disposal service or the depot where you purchased the product.
NOTES:
•Please read the instruction manual carefully before installing and using your appliance. We are not
responsible for any damage incurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to
resolve any problems that may occur in the future.
• This appliance is designed to be used in homes and it should only be used in domestic environments
and for those specified purposes. It is not suitable for commercial or common use. Such use will cause
the guarantee of the appliance to be cancelled and our company will not be responsible for any losses
incurred.
• This appliance is designed for household use and is only suitable for cooling / storing foodstuffs. It is not
suitable for commercial use and/or for storing non-food substances. Our company is not responsible for
any losses incurred in these latter cases.
Safety warnings
• Do not connect your fridge freezer to the mains electricity supply using an extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by adults. Do not allow children to play with the appliance or hang off
the door.
• Never touch the power cord/plug with wet hands. This may cause a short circuit or electric shock.
• Do not place glass bottles or cans in the ice-making compartment as they will burst when the contents
freeze.
• Do not place explosive or flammable material in your fridge. Place drinks with high alcohol content
vertically in the fridge compartment and make sure their tops are tightly closed.
• When removing ice from the ice-making compartment, do not touch it. Ice may cause frost burns and/or
cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes immediately after they are
removed from the ice-making compartment.
• Do not re-freeze thawed frozen food. This may cause health issues such as food poisoning.
Old and Out-of-Order Fridges or Freezers
• If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may
get trapped inside it and may cause an accident.
• Old fridges and freezers contain insulation material and refrigerant with CFC. Therefore, take care not to
harm the environment when you are discarding old fridges.
This appliance is not designed to be used as a built-in appliance.
7
Instructions and Installation
7
Exclusive to Howdens
Before using your fridge freezer for the first time, please pay attention to the following points:
• The operating voltage for your fridge freezer is 220-240 V at 50Hz.
• The plug must be accessible after installation.
• Your fridge freezer may have an odour when it is operated for the first time. This is normal and the odour
will fade when your fridge freezer starts to cool.
• Before connecting your fridge freezer, ensure that the information on the data plate (voltage and
connected load) matches that of the mains electricity supply. If in doubt, consult a qualified electrician.
• Insert the plug into a socket with an efficient ground connection. If the socket has no ground contact or the
plug does not match, we recommend you consult a qualified electrician for assistance.
• The appliance must be connected with a properly installed fused socket. The power supply (AC) and
voltage at the operating point must match with the details on the name plate of the appliance (the name
plate is located on the inside left of the appliance).
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your fridge freezer where it will not be exposed to direct sunlight.
• Your fridge freezer must never be used outdoors or exposed to rain.
• Your appliance must be at least 50 cm away from stoves, gas ovens and heater cores, and at least 5 cm
away from electrical ovens.
• If your fridge freezer is placed next to a deep freezer, there must be at least 2 cm between them to prevent
humidity forming on the outer surface.
• Do not cover the body or top of fridge freezer with lace. This will affect the performance of your fridge
freezer.
• Clearance of at least 150 mm is required at the top of your appliance. Do not place anything on top of your
appliance.
• Do not place heavy items on the appliance.
• Use the adjustable front legs to make sure your appliance is level and stable. You can adjust the legs by
turning them in either direction. This must be done before placing food in the appliance.
• Clean the appliance thoroughly before use (see Cleaning and Maintenance).
• Before using your fridge freezer, wipe all parts with a solution of warm water and a
teaspoon of sodium bicarbonate. Then, rinse with clean water and dry.
Return all parts to the fridge freezer after cleaning.
• Install the two plastic distance guides (the parts on the black vanes condenser - at
the rear) by turning it 90° (as shown in the figure) to prevent the condenser from
touching the wall.
• The distance between the appliance and back wall must be a maximum of 75 mm.
• The product is not designed to be used in very low temperature environments such
as garages or sheds.
The thermostat control will not work correctly (unless it is designed to work in these
environments)
Installing and Operating your Fridge Freezer
Before Using your Fridge
• When using your fridge for the first time, or after transportation, keep it in an upright position for at
least 3 hours before plugging into the mains. This allows efficient operation and prevents damage to the
compressor.
• Your fridge may have a smell when it is operated for the first time. This is normal and the smell will fade
away when your fridge starts to cool.
These new-generation products can create an array of sounds / noises during their normal daily operation.
This is normal.
Noises
8
www.howdens.com
Freestanding Fridge Freezer FLM6304/5/6/7
Dimensions
H1
H2
W2
D2
W1
D1
W3
90o
D3
Space required in use 2
H2 mm
2051,0
W2 mm
705,0
D2 mm
777,9
2the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air.
Overall space required in use 3
W3 mm925,9
D3 mm
1232,5
3the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air, plus
the space necessary to allow door
opening to the minimum angle
permitting removal of all internal
equipment.
Overall dimensions 1
H1 mm
1901,0
W1 mm605,0
D1 mm681,0
1the height, width and depth of the
appliance without the handle.
8
9
Instructions and Installation
9www.howdens.com
The Parts of the Appliance
This presentation is only for information about the parts of the appliance. Parts may vary according to
the appliance model.
A) Refrigerator compartment
B) Freezer compartment
1) Thermostat knob
2) Lamp cover
3) Wine rack
4) Fridge shelves
5) Crisper cover
6) Crisper
7) Freezer upper basket
8) Freezer middle basket
9) Freezer bottom basket
10) Levelling feet
11) Freezer glass shelves
12) Bottle shelf
13) Door shelf
14) Door shelf
15) Egg holder
16) Ice tray
17) Plastic scraper
B
3
A
4
5
6
7
8
9
10
14
13
2
1
12
15
16
17
11
Super freeze switch
(In some models)Thermostat knob
Lamp cover
(The images are representative)
10
www.howdens.com
Freestanding Fridge Freezer FLM6304/5/6/7
10
Exclusive to Howdens
Thermostat setting
The fridge freezer thermostat automatically regulates the inside temperature of
both the compartments. By rotating the knob from position 1 to 5, colder
temperatures can be obtained. Normal setting is 3
Freezer & fridge thermostat setting:
1 – 2: For short-term storage of food in the freezer compartment, you can set the
knob between the minimum and mid position.
3 – 4: For long-term storage of food in the freezer compartment, you can set the
knob to the mid position.
Thermostat knob
Controls and Operation
Temperature Adjustment Warnings
• We recommend that you do not operate your fridge in environments where the ambient temperature is
below 10°C because this will reduce its efficiency.
• Temperature adjustments should be made according to the frequency of door openings and the quantity
of food kept inside the fridge.
• Your fridge should be operated up to 24 hours according to the ambient temperature without interruption
after being plugged in to be completely cooled. Do not open doors of your fridge frequently and do not
place much food inside it during this period.
• During power cut, to prevent any compressor problem you should unplug the refrigerator. You should delay
pluging in 5 – 10 minutes after your power supply returns. If you plug out the refrigerator for a reason you
should wait at least 5 min to replug. It is important for avoiding damage to refrigerator’s components.
• This appliance is intended to be used at ambient temperatures
ranging from + 10 (°C) to + 43 (°C) SN-T Climate class Ambient (°C)
T16 to 43 (°C)
ST 16 to 38 (°C)
N16 to 32 (°C)
SN 10 to 32 (°C)
Ice tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely frozen, you can twist the tray as shown below to remove the ice cubes.
Accessories
Energy Efficiency Fridge- Most efficient use is ensured with food evenly distributed across shelves
and within the drawers, in their correct positions at the bottom of the fridge.
Freezer- Most efficient with comfortably full drawers in their dedicated positions.
hours after.
For freezing fresh food quickly select the Super Freeze switch.
Super Freeze Switch- Switch on up to 24 hours before loading fresh food and run for up to 24
Turn-off Super freeze in order to revert to normal operation after this time period.
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Lamona Réfrigérateur
Lamona
Lamona LAM6702 Manuel utilisateur
Lamona
Lamona FLM6351 Mode d’emploi
Lamona
Lamona LAM6380 Manuel utilisateur
Lamona
Lamona LAM6000 Mode d’emploi
Lamona
Lamona LAM6701 Manuel utilisateur
Lamona
Lamona HJA6312 Guide de dépannage
Lamona
Lamona LAM6300 Manuel utilisateur
Lamona
Lamona HJA6853 Guide de dépannage
Lamona
Lamona LAM 6700 Manuel utilisateur
Lamona
Lamona LAM6050 Manuel utilisateur
