METALINE® splashbacks
FABRICATION manual
10
Product Characteristics
Laminex Metaline Splashbacks are an aluminium composite panel consisting of two coil-coated aluminium sheets
bonded onto both sides of a Flame Retardant (FR) core. Bonding of the aluminium and FR core is achieved by
both chemical and mechanical action, which gives excellent bond integrity. An exceptionally flat, corrosion-resistant
panel, Laminex Metaline Splashbacks are simple to install and produces a premium finish.
The coated aluminium sheets are
0.5mm thick, sandwiched onto a 3mm
FR core to give a total thickness of
4mm and density of 7.5 kg/m2.The
high gloss decorated surface is a
proprietary formulation that is easy
to clean, mark and stain resistant and
fire resistant. It has a minimum gloss
measurement of 80 gloss units.
The corrosion-proofed surface is a
matt grey colour. Printed onto the
back surface are the product name,
product colour, ASW code and
manufacturing batch code.
Product Applications
Laminex Metaline Splashback panels are suited for use in all splashback applications, when installed according to
“Section 5 – Kitchen Splashback Installation”, for both gas and electric cooktops. Laminex Metaline Splashbacks are
CodeMark certified to meet the requirements of the BCA and BCNZ.
Other applications suited to Metaline include:
• Wallpanelsforwetareas(laundry,bathroom,toilets)
• Wallpanelsfordryareas(commercialanddomesticapplications)
• Wallliningsforcommercialapplications(lifts,displays,caravans,etc.)
• Decorativeverticalpanels
Sheet Sizes
Laminex Metaline Splashbacks come in 2 main sheet sizes:
• 3600x800mm
• 3600x1500mm
Introduction to LAMINEX® METALINE® splashback systems
SECTION 2: product introduction
a) High gloss coil coated aluminium sheet
c) Fire Resistant (FR) core
d) Corrosion proofed coated aluminium sheet
b) Thermo-adhesive film between the
aluminium sheets and FR core
