Inverter Air Source Heat Pump
Split System
Lailey and Coates
Heat Pumps Engineered for British Homes
Product Installation Manual
2 Installation Manual 2014 - Riv 2
Inverter Air Source Heat Pump
Split System
3 Installation Manual 2014 - Riv 2
Contents
General Information..............................................................................................5
Technical Specification ..........................................................................................6
Installation of External Unit...................................................................................7
Installation of Internal Unit...................................................................................8
Wiring Instructions................................................................................................9
Rated power input and fuse information............................................................10
Indoor Electrical Connections..............................................................................11
Plumbing Installation...........................................................................................12
Refrigeration Installation.....................................................................................14
Dip Switch Settings..............................................................................................16
Pre-Operation Checklist.......................................................................................17
Commissioning ..................................................................................................18
LCD controller......................................................................................................19
How to set up LCD controller...............................................................................20
Setting the Hot Water Temperature....................................................................21
Setting the Heating Water Temperature..............................................................22
Setting the Heat Pump Timer..............................................................................23
Holiday Timer......................................................................................................26
Simple Trouble Shooting Guide.........................................................................27
Access to change system parameters..................................................................27
Fault / Error Codes...............................................................................................30
Commissioning Sheet..........................................................................................34
Installation Manual 2013 Riv 2 4
Thank you for purchasing a Lailey and Coates Air source Heat Pump.
Please read this manual carefully before installation and operation. It contains
important
information to enable a safe and successful installation. If you have any queries please
ring our Technical Helpline on 01753-537830 before running the Heat Pump.
Safety Instructions
To prevent injury/damage to persons or property the following instructions should be
followed at all times:
· This product should only be installed by Approved Lailey and Coates partners. All
installation engineers should be suitably qualified and made aware of the contents
of this manual.
· Repairs and Maintenance should be carried out by Approved Lailey and Coates
partners to ensure validity of Warranty.
· Internal and external units should be securely fixed to solid surfaces ensuring a
minimum support weight of 20g/mm2.
· All local regulations, by-laws and standards should be checked and adhered to at
all
times.
· Internal and External Units should be installed as per guidelines in this manual
ensuring adequate ventilation and airflow around the units.
· Care should be taken when cleaning/installing product so as to avoid water
ingress,
electric shock or damage to unit and associated pipework and cables. Both internal
and External units should be isolated for these purposes.
· This product has been designed for use by persons with experience of Heating
controls and as such should not be operated by children or persons with reduced
physical, sensorial or mental faculties unless supervised by a responsible person.
5 Installation Manual 2014 - Riv 2
General Information
The Lailey and Coates Split System consists of two major parts: The Internal and External
Units. They are connected via refrigeration pipes and an ELV, shielded, communication
Cable.
The external units can either be wall mounted or hard-standing but should be secured via
suitably designed mounting systems available from Lailey and Coates. When siting the
outdoor unit it is essential that an adequate, un-restricted level of airflow is available to
ensure correct operation and maximum efficiency of the system. See page 7.
The Internal Unit is designed to be wall mounted in a suitably dry position.
The Lailey and Coates Split System will accommodate all your heating and hot water
demands and is suitable for use with; under floor Heating, Radiators and Fan Coil Units.
The system is integrated with an Electrical Heater for extreme weather conditions and also
acts as a backup if there is a problem with the External Unit.
Model identification
LC - 15
Model Type
Lailey and Coates
Unit Size
Nominal Heating
Capacity
= 15 kW
Installation Manual 2013 Riv 2 6
Indoor unit LC-07 LC-10 LC-12 LC-15
Dimensions indoor unit
Height mm 549 549 609 609
Width mm 450 450 450 450
Depth mm 262 262 262 262
Weight
Gross Kg 35 36 39 40
Net Kg 30 31 34 35
Sound pressure level dBA 26 27 28 29
Water flow temperature Heating max ⁰C 55 55 55 55
Minimum water flow L / min 12 18 24 30
Pump heat at min flow ⁰C 55 55 55 55
Electrical Heaters
Power Supply W 220-240v
Capacity kW 3 kW 3 kw 4 kW 4 kW
*TaDB/WB7⁰C/6⁰CLWC35⁰C ∆T5⁰C as per EN 14511
Technical Specification
Outdoor Unit LC-07 LC-10 LC-12 LC-15
Power supply 220-240v 50 Hz
Nominal capacity * Heating kW 6.93 9.68 12.67 15
Nominal input * Heating kW 1.43 2.05 2.73 3.33
COP*7⁰C(A7/W35) Heating kW 4.84 4.73 4.64 4.5
Outdoor temperature range
Min ⁰C -15 -15 -15 -15
Max ⁰C 35 35 35 35
Refrigerant pipe diameter Diameter ins ½ - ⁄ ⁄- ⁄¾ - ⁄¾ - ⁄
Refrigerant Type
R 410 a
R 410 a
R 410 a
R 410 a
Compressor Rotary DC compressor
Fan Speed Variable
Heater mats fitted Yes Yes Yes Yes
Sound pressure level Heating dBA 48 50 51 52
Maximum pipe run (indoor to outdoor unit) Maximum m 15 20 20 25
Piping connections (flow and return) ⁄" (female)
Dimensions outdoor unit
Height mm 892 892 1250 1250
Width mm 963 963 963 963
Depth mm 342 342 343 343
Weight
Gross Kg 105 108 118 120
Net Kg 89 92 101 103
7 Installation Manual 2014 - Riv 2
Installation of External Unit
When locating the External Unit the following considerations should be taken into account:
● Ifwallmountingensurethatthestructureissufficientlysolidtobeartheweightofthe
unit without causing vibration.
● Iffloormountedensurebaseissolidwithnolikelihoodofsubsidence.
● Selectalocationsoastominimisedisruptiontoneighboursandavoidcloseproximityto
bedrooms. In accordance with MCS standards.
● Ensureadequateaccesstoandaroundtheunitformaintenanceandnon‐restrictionof
airflow.
● Closeproximitytopossiblegasleaksorelectricalequipmentshouldbeavoided.
● Whenindefrostexcesswaterwilldrainfromtheunitsoensureanadequatemethodof
disposal to same.
Air Flow Restrictions:
● Provideafrontclearanceofminimum4000mm.
● Tosidesandrearclearanceofminimum170mm.
Please note:
Floor and Wall mounting brackets are available from Lailey and Coates on request.
A wall mounting template is supplied with the External Unit.
8 Installation Manual 2014 - Riv 2
When locating the Internal Unit the following considerations should be taken into account:
● Ifwallmountingensurethatthesurfaceisflat,non‐combustibleandsufficientlysolidto
bear the weight of the unit without causing vibration.
● Provisionshouldbemadeforsufficientaccesstoensureeaseofmaintenance.
● Ensuretheunitisnotexposedtoextremesoftemperature.
● Avoidcloseproximitytopossibleinflammablegasleakage.
● MaximumrefrigerationpipelengthSeepage 13
Please note: a wall bracket and mounting template are supplied with the Internal Unit.
Installation of Internal Unit
Installation Manual 2013 Riv 2 9
Wiring Instructions
Warnings
This unit must be installed to conform with all relevant local standards and
regulations by suitably qualified engineers.
This unit must be earthed.
Please ensure this unit has a suitable, dedicated power supply/supplies, and is not
susceptible to frequent power loss via time clocks or other devices, etc.
Suitably rated and protected cables should be used.
Isolators should be double pole.
Isolate both units during maintenance and repairs.
Power Input and Communication Cables:
3 Core 0.75mm screened
AGB terminals
3 Core Cable from MCB LNE
Suitably Rated Internal Isolator
3 Core Cable from MCB LNE
Suitably rated
weather-proof isolator
10 Installation Manual 2014 - Riv 2
Rated power input and fuse information
Model Rated Outdoor Unit Indoor Unit Combined System
Hz Volts Watts
Max
Current
Amps
Max
Fuse
Rating
Amps
Watts
Max
Current
Amps
Max
Fuse
Rating
Amps
Watts
Max
Current
Amps
Max
Fuse
Rating
Amps
LC 07 50 220-240 3300 14 16 3054 14.4 16 6354 28.4 32
LC 10 50 220-240 4900 21 32 3054 14.4 16 7954 35.4 40
LC 12 50 220-240 6000 26 32 4054 17.4 20 10054 43.4 50
LC 15 50 220-240 6800 29 32 4054 17.4 20 10854 46.4 50
Please note:
● Indoorunitloadincludesbackupheaterbutnotpump(54Wrating).
● Indoorandoutdoorunitscanbesuppliedseparatelyorononededicatedsupplybut
slave unit should be suitably fused down.
● ShieldedheatresistantcabletobeinstalledonELVcables.
● 300mmspacingshouldbeensuredbetweenunshielded 230VandallELVcables
where practicable.
● LC12KWandLC15KWExternalUnitsshouldbesuppliedviamotorratedM.C.B’S.
On completion of Electrical Installation please ensure the following:
● 230VandELVcablesaresuitablyconnectedinappropriateconnectionblocks.
● DipswitchestobothInternalandexternalunitsarecorrectlyset.Seepage 15
● ELVconnections7/8,9/10,11/12arelinkedoutifunused.
● ElectricheaterswitchinInternalUnit(whereapplicable)isswitched‘on’.
