Laice IPB-222S Manuel utilisateur

Megapixel HD IP Camera

Instruction Manual

- Thank you for purchasing this Megapixel HD Hybrid Camera.

- Before using the Hybrid HD Camera, please ensure that you read and understand the User Guide.

- Please store the CD-ROM including this User Guide at an easily accessible location.

- Before connecting and installing any third party monitors, computers and alarms, please refer to

the appropriate instruction manual for proper operation.

MS12052P0100A

Model Line

Indoor Dome Camera

Vandalproof Dome Camera

Bullet Camera

Contents

Disclaimer ...............................................................................................................................................

Warning ...................................................................................................................................................

Caution ....................................................................................................................................................

Preventing Malfunction .....................................................................................................................

1. Introduction

1.1 Key Features ..............................................................................................................................

1.2 Features of Network ...............................................................................................................

1.3 System Requirement ..............................................................................................................

1.4 Package Contents ....................................................................................................................

2. Product Views

2.1 Indoor Dome Camera Dimensions ....................................................................................

2.1.1 Parts Conguration .............................................................................................................

2.2 Vandalproof Dome Camera Dimensions .........................................................................

2.2.1 Parts Conguration ..............................................................................................................

2.3 Bullet Camera Dimensions ...................................................................................................

2.3.1 Parts Conguration ..............................................................................................................

3. IP Discovery .................................................................................................................................

4. Web Browser Connecting & Live View

4.1 Accessing Internet Explorer & Web Browser ..................................................................

4.2 Live Web View ...........................................................................................................................

5. Setup .................................................................................................................................................

5.1 Record ...........................................................................................................................................

5.2 Live .................................................................................................................................................

5.3 Camera ..........................................................................................................................................

5.4 Disk .................................................................................................................................................

5.5 Network ........................................................................................................................................

5.6 Device ...........................................................................................................................................

5.7 System ...........................................................................................................................................

5.8 Log ..................................................................................................................................................

6. Specication ................................................................................................................................

7. Appendix ........................................................................................................................................

(4)

(5)

(6)

(7)

(7) ~ (8)

(8) ~ (9)

(10)

(11)

(12)

(13)

(14)

(15)

(16) ~ (17)

(17) ~ (19)

(20)

(21)

(22) ~ (24)

(25) ~ (27)

(28) ~ (31)

(32) ~ (33)

(34) ~ (40)

(41) ~ (42)

(43) ~ (46)

(47)

(48) ~ (49)

(50)

Disclaimer

The information in this manual is believed to be accurate and reliable as of the date of publication.

The information contained herein is subject to change without notice. Revisions or New editions to

this publication may be issued to incorporate such change.

We makes no warranties for damages resulting from corrupted or lost data due to a mistaken

operation or malfunction of the IP Camera, the software, PC Hardware, peripheral devices, or

unapproved/unsupported devices.

Warning

Do not expose this product to rain or moisture to reduce a risk of re or electric shock.

In the event that the water or other foreign substances enter the interior, immediately turn the

Camera Power o or unplug the power cord from the power outlet. Continued use of the equipment

may result in re or electrical shock. Please consult your Camera distributor.

Do not attempt to disassemble or alter any part of the equipment that is not expressly described in

this guide. Disassembly or alteration may result in high voltage electrical shock.

The installation should be made by a qualied service person authorized by your equipment

distributor. They should conduct internal inspections,

alterations and repairs.

Stop operating the equipment immediately if it emits smoke or noxious fumes. Failure to do so may

result in re or electrical shock.

Immediately turn the Camera power o, remove the power cable from the power outlet. Conrm

that smoke and fume emissions have ceased. Please consult your Camera distributor.

Stop operating the equipment if the camera is dropped or the casing is damaged. Do not strike or

shake. Failure to do so may result in re or electrical shock. Immediately turn the Camera power o

or unplug the power cord from the power outlet. Please consult your Camera distributor.

For Installers Only – Instructions for installing the equipment on the ceiling or the wall.

Caution

Do not operate the appliance beyond its specied temperature, humidity or power source ratings.

Do not use the appliance in an extreme environment where there is high temperature or high

humidity. Use the device at temperatures within -10°C to +50°C and humidity below 90 %.

The normal operating power source for this device is DC 12V / PoE. For Power Supply – it operates on

DC 12V or PoE.

To prevent heat buildup, do not block air circulation around the camera.

When transporting the camera, repack it as originally packed at the factory or in materials of equal

quality.

Do not proceed beyond any of the above notices until you have fully understood the implications.

For LAN port – For safety reason, do not connect the LAN port to any network devices that might

have excessive voltage.

FCC Compliance

Information to the User: This equipment has been tested and found to comply with the limits for a

Class A digital device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the

interference. For example, try reorienting or relocating the receiving antenna, increasing the

separation between the equipment and receiver, or connecting the equipment to an outlet on a

dierent circuit.

CE Compliance

Preventing Malfunction

To avoid operating or storing the camera in the following locations, as these can be a cause of a

malfunction.

Extremely hot or cold places.

Close to heating equipment (e.g., near heaters)

Close to sources of strong magnetism.

Close to sources of powerful electromagnetic radiation, such as radios or TV transmitters.

Locations subject to strong vibration or shock.

Humid or dusty locations.

Locations under inuence of uorescent light or reection of a window.

Under an unsteady light. ( the image will icker)

1. Introduction

This section introduces our new IP camera with its key features, and basic information about the

product. Refer to later chapters for information on setting up and conguring the product in more

detail.

1.1 Key Features

- 45 FPS @ 1080p

- 3D- DNR (Digital Noise Reduction)

- WDR ( Wide Dynamic Range)

- TDN (True Day and Night /IR Cut lter)

- Mirror Image Control (Horizontal control & Vertical Control)

- 4 Zone Motion Detection

- 3-Axis Gimbal (For Dome Camera only)

- DSS Max. x30

- PoE Supported

1.2 Features of Network

- H.264 Embedded Linux

- Up to 45 fps at 2M

- Multi-Codec : H.264 High Prole, MPEG4, MJPEG

- Easy Setup Program From Web Browser

- Multi-Streaming – Triple: Recording, HD and SD.

- Built in Web server (IE), Free DDNS

- Static and Dynamic IP

- Smart & Multi Steaming - Automatic control in Codec and frames

- Web Setup by IE, Safari, Chrome, Firefox

- Audio 8Khz, MONO, PCM (Input,Output) (Audio G.711)

- The IP-based Security Standard (ONVIF)

- IP Discovery : Auto IP Scan and Settting

1.3 System Requirement

To view the IP Camera images, your computer must have the following technical specications.

Powerful System

Operating System Microsoft Windows 7 32bit or Windows 7 64bit (Recommended)

Web Browser Microsoft Internet Explorer 8.0 or higher

CPU Intel Core i7 Core / VGA Internal CPU Graphic Core

Memory (RAM OVER 4G), NIC 1 Gbps network card installed

HDD (2T * over 8) and HDD RAID SYSTEM for Powerful Record Storage

Recommended System

Operating System Microsoft Windows Vista or higher

Web Browser Microsoft Internet Explorer 8.0 or higher

CPU Over Quad Core 1.8 GHz / VGA Microsoft DirectX 9.0

Memory (RAM 4G), NIC 1 Gbps 100 Mbps network card installed

HDD over 2T

Minimum System

Operating System Microsoft Windows XP or higher

Web Browser Microsoft Internet Explorer 7.0 or higher

(Safari, Firefox, Chrome: Setting only)

CPU Dual Core 2.8 GHz VGA Microsoft DirectX 9.0

Memory (RAM 2G), NIC 100 Mbps network card installed

HDD 500G

The system requirements for installing and running EMS must be adjusted depend on your PC

performance, number of accesses and the number of simultaneous monitoring video as follows.

Powerful(Maximum) System

It is possible to operate EMS at any condition with the Maximum System.

Recommended System

Set the individual camera when 6 channel of 2 megapixel camera simultaneously.

Please set the Performance on the EMS Setup Menu which is Default.

Minimum System

Set the individual camera when 2 channel of 2 megapixel camera simultaneously.

It might not perform well with record or other operation under the Minimum

System.

Warning

It might not perform well with some Hardware such as graphic card or others.

To use EMS, it is not recommended to use a web browser or other program such as MS OFFICE, Game

or etc. to prevent any malfunction of record.

1.4 Package Contents

The package should contain all the following. If anything is missing or appears damaged, contact

your dealer immediately.

INDOOR DOME TYPE

Megapixel HD IP Camera

CD with user’s manual and software (EMS)

Quick Start Guide, Mounting Template, Dowel (4pcs), ST4x38 (pcs)

VANDALPROOF DOME TYPE

Megapixel HD IP Camera

CD with user’s manual and software (EMS)

Quick Start Guide, Mounting Template, Torx Wrench

Dowel (4pcs), ST4x38 (pcs), M3x12

BULLET TYPE

Megapixel HD IP Camera

CD with user’s manual and software (EMS)

Quick Start Guide, PH T1 5x25 (4pcs)

2. Product Views

2.1 Indoor Dome Camera Dimensions

110

109

Ø150

Ø100
