8130 ENTRY DEVICE RESPONSES

• Valid Code Entry - Two beeps 

• Invalid Code Entry - Three beeps 

• Input Disabled (AuditGard or TimeGard) - Four beeps 

• Timelock Denied Access (TimeGard) - One long beep (2 seconds) ...

DEVICE SETUP

At ﬁrst power up with a programmed lock (or after battery replacement), the entry device

must “learn” the settings of the lock to which it is attached.

Note: If the entry device has already been attached to the lock, powered up (ﬁrst time or

with replacement battery), and cycled through a time delay/open window cycle, you do

not need to complete the device setup at this time.

1. Connect the cable from the 8130 Entry Device into the connector port marked ENT on

the programmed lock.

2. If the battery has not yet been installed, remove the battery cover and connect a new

9-Volt Alkaline battery to the battery connector. Use of a high quality, name brand

battery (Energizer® or Duracell®) is recommended.

Note: Once the battery is connected, the system will run a self check of the display

and buzzer.

3. Place the battery back in the battery compartment and put the cover back in place.

4. Initiate a time delay opening of the lock by entering a valid combination. The time delay

period will start and you must let the full delay and opening period complete for

the entry device to “learn” the lock settings. DO NOT interrupt the time delay/

open window cycle.

Note: Regardless of the current jumper switch settings, the time delay cycle will

count up the ﬁrst time.

USER OPERATING INSTRUCTIONS

8130

ELECTRONIC ENTRY DEVICE

Page 1 of 4

The following instructions cover the user operations of the

8130 Electronic Entry Device.

FEATURES

• Keypad Entry for Electronic Lock

• LCD Display Area for Time Delay/Open Window and

Penalty Display

• Jumper Switches to Change Time Delay Counting Direction

• Compatible with the following lock code:

ComboGard (33E V2.13)

ComboGard Pro (39E V1.01)

AuditGard (66E LGA V1.20)

TimeGard (TL11 V1.30 and V2.22)

8130

Page 2 of 4

OPEN LOCK

1. Enter valid combination.

2. For Dual User access, enter the second valid combination.

3. Open the container within 4 seconds.

TIME DELAY DISPLAY

The time display will operate during a time delay period and opening window. The time

display format is mm:ss (minutes and seconds.) The default device operation is set to

count down for the time delay period and count up for the opening window. To change

the counting direction, see section on CHANGE COUNTING DIRECTION.

CHANGE COUNTING DIRECTION

Two jumper switches are available on the control card of

the entry device to control the counting direction of the LCD

display for time delay and open window.

No jumper = Count up

Jumper on = Count down

The device is shipped with a jumper on the switch for time

delay and no jumper on the switch for the opening window

as shown in the photo (Figure 1); therefore, the default status

of the device is that time delay counts down and the opening

window counts up.

An additional jumper is included in the hardware pack with

the entry device. You can change the counting direction(s)

by adding another jumper, by switching the position of the

original jumper, or by removing the original jumper.

Note: To remove the back cover, use a medium-sized Phillips head screwdriver. If you

change the jumper settings, they will not be recognized until the next power up of the

entry device. Therefore, you must remove the battery if installed and drain the remaining

power by holding and pressing a key or by pressing multiple keys continuously.

OPEN LOCK WITH TIME DELAY

1. Enter valid combination. The time delay display will be activated. (See TIME

DELAY DISPLAY.)

2. Once the Time Delay has expired and the lock has entered the “open window”, enter

valid combination again.

3. For Dual User access, enter the second valid combination.

4. Open the container within 4 seconds.

TIME DELAY OVERRIDE

This feature enables a User to override Time Delay. The feature must be programmed

when the lock is set up. Refer to the Manager instructions for more detail.

If operating in Dual Combo Mode, the manager or a user combination must ﬁrst be

entered, then the override combination.

Jumper On

- Delay

switch =

Count Down

No Jumper

- Open

switch =

Count Up

Figure 1

INITIATE SILENT DURESS ALARM

This operation is intended to work in conjunction with an alarm box. The feature must be

programmed when the lock is set up.

For ComboGard, AuditGard or TimeGard:

The silent duress combination is created by taking your existing combination and

adding or subtracting 1 from the last digit of the combination. For example, if the PIN is

“526674”, entering “526673” or “526675” will activate the silent duress alarm. If the

combination is “526699”, entering “526698” or “526690” will activate the alarm.

For ComboGard Pro:

The silent duress combination is created by taking your existing combination and

adding 1 to the last digit of the combination. For example, if the PIN is “526674”,

entering “526675” will activate the silent duress alarm. If the combination is

“526699”, entering “526690” will activate the alarm.

Once the silent duress combination is entered, the silent duress alarm is activated and

normal lock operation continues.

CHANGE COMBINATION

Caution: Before changing a combination, open the container door to allow testing with

the new combination. If you make a mistake while performing this operation, wait 30

seconds and start over.

For ComboGard:

1. Enter all 0’s for the combination.

2. Enter current valid combination.

3. Enter new valid combination.

Note: New combination will not be accepted if it varies from the current combination

by only one digit (+/-). When selecting a combination, do not use a birthday or

other predictable information that could give correlation between the user and the

combination.

4. Enter new valid combination again for veriﬁcation.

5. Record the new combination and store it in a secure place.

For ComboGard Pro, AuditGard, or TimeGard:

1. Enter current valid combination, holding down the last digit until two sets of double

beeps occur.

 

2. Press 0. Double beep 

3. Enter new valid combination.

Note: New combination will not be accepted if it varies from the current combination

by only one digit (+/-). When selecting a combination, do not use a birthday or

other predictable information that could give correlation between the user and the

combination.

4. Enter new valid combination again for veriﬁcation.

5. Record the new combination and store it in a secure place.

Page 3 of 4

WRONG TRY PENALTY DISPLAY

A time penalty of 5 minutes will start after the 4th consecutive wrong combination

has been entered. During a wrong try penalty period, PEN is displayed in the LCD

display area.

Two more consecutive wrong combinations entered after the penalty has expired will start

another 5 minute penalty.

BATTERY LOW WARNING

The battery low warning occurs if the battery drops below 6 volts during solenoid

activation. Multiple beeps  ....

BATTERY REPLACEMENT

1. Remove the battery compartment cover at the bottom of the entry device.

2. Remove the battery from the battery compartment & carefully disconnect the battery.

Caution: Hold the battery terminal connector while disconnecting the battery to avoid

ripping the battery wires out of the assembly.

3. Connect a new 9-Volt Alkaline battery to the battery connector. Use of a high quality,

name brand battery (Energizer® or Duracell®) is recommended.

Note: Once the battery is connected, the system will run a self check of the display

and buzzer. If the entry device beeps when the battery is reconnected, the power has

drained off completely and the entry device must go through a device setup. Initiate

a time delay/open window cyle once again to allow the entry device to “relearn” the

lock settings. Refer to the section on DEVICE SETUP.

4. Place the battery back in the battery compartment and put the cover back in place.

749 W. Short Street, Lexington, KY 40508 USA

Phone: (859) 253-4744 FAX: (859) 255-2655

Technical Support: (800) 950-4744

www.kaba-mas.com

Page 4 of 4
