Labnet S0200 Manuel utilisateur

Lit M00047 Rev 4; June 2016

Vortex Mixer

User Manual

S0200

S0200-230V-EU

S0200-230V-UK

S0200-230V-CH

About This Manual

This manual is designed to assist you in the optimal usage of your Labnet Vortex Mixer.

The manual is available in English, French, German, Italian, Portuguese, and Spanish on

our website at www.labnetinternational.com/document-center

Introduction

The Labnet Vortex Mixer is a general purpose laboratory vortexer. Mixing speed is

adjustable up to 3,400rpm. A three position switch allows the mixer to be operated

continuously or by “touch” activation. The shaking mechanism is specially designed to

offer enhanced stability under various loads. The metal baseplate and rubber feet

provide additional stability and prevent the unit from “walking” across the bench, even at

maximum speed.

Read this manual thoroughly before attempting to operate the Vortex Mixer. All persons

operating this piece of equipment should review the Safety Precautions section of this

manual.

Specifications

Speed Range 3400rpm (60 Hz)

2850rpm (50 Hz)

Operating Modes Touch or Continuous

Ambient Operating Range +4ºc to 65ºc

Dimensions (w x d x h) 14 x 16 x 12 cm

Weight 2.2 kg

Electrical 120V, 60Hz, 0.6A

230V, 50Hz, 0.3A

Unpacking the Vortex Mixer

Upon receipt of the Vortex Mixer, examine the exterior carton for damages. In the event

of shipping damage, a claim must be filed with the transportation carrier within 10 days

of receipt. Save all packaging for inspection by the carrier.

Carefully unpack the unit and check for completeness. Included in the carton should be

the following:

Vortex mixer with cup head

Line cord

Instruction manual

If any of these items are missing, contact Labnet’s Customer Service Department

immediately. Save the original packaging until the unit has been shown to be operating

properly.

Verify that the unit is rated for the proper voltage by checking electrical / serial no. label

on the back.

Installation

Locate the mixer on a level, stable surface near a grounded electrical outlet. The

surface should be clean and free of dust to ensure that the feet grip the surface firmly.

Allow sufficient clearance on all sides of the unit for proper ventilation.

With the power switch in the OFF position, plug the power cord into a grounded

receptacle.

Operating the Vortex Mixer

All operating controls are located on the front panel. The power switch, located on the

left side of the panel, has three positions - TOUCH, OFF and ON. When set to the

TOUCH position, the mixer is activated by depressing the mixing head. When pressure

is released from the mixing head, operation will stop. When set to the ON position, the

mixer will operate continuously until the switch is moved to either the OFF or TOUCH

position.

The speed control, located on the right side of the panel, is continuously adjustable.

Oscillating speed increases at a non-uniform rate to a maximum of 3,400rpm as the

knob is turned clockwise. Before turning on the mixer, set the speed control to the

minimum.

To begin operation, move the power switch to either the TOUCH or ON position and turn

the speed control to the desired setting. If the power switch is in the ON position, the

shaking head will begin moving immediately. If the power switch is in the TOUCH

position, operation will begin when an object is placed on the shaking head and slight

pressure is applied to depress the head. Shaking will cease when the object is removed

and pressure released.

Safety Precautions

The following precautions should be taken when operating or working near the Vortex

Mixer:

• CAUTION; A PINCH POINT EXISTS BETWEEN CUP HEAD AND ENCLOSURE.

• Never operate the unit without a shakinghead securelyattached.

• Alwayswear shatterproofeye protection.

• Donotuseor mix solventsand flammables on or near the mixer.

• Shake hazardous samples in appropriatecontainmentvessels.

• Repair should be performedonly byqualified individuals

• Protection impairment may resultif used in a manner not specified by the manufacturer.

Optional Accessories

Instruction for using accessories:

1 – Turn power off and rotate speed knob to minimum

2 – Hold the unit down and lift the mixing head

3 – Apply the desired optional accessory and load it in a balanced manner

4 – Turn on the unit

5 – Slowly rotate the speed knob clockwise until the desired mixing level is achieved

Important: If the unit starts to walk, reduce speed accordingly

Optional shaking heads are as follows:

S0200-21 Microtube head, foam, for 80 tubes

S0200-22 Microplate head, foam, for 1 microplate or 64 x 0.2mL tubes

S0200-23 10-13mm and 15mL tube head, for 16 tubes

S0200-24 50mL tube head, for 6 tubes

S0200-25 Head for 12 x 1.5ml tubes, held horizontally

S0200-26 Head for 4 x 15 ml tubes, held horizontally

S0200-27 Head for 2 x 50 ml tubes, held horizontally

Contact your Labnet dealer for information about ordering additional heads

Care and Maintenance

Warning: Disconnect the vortexer from power source before attempting any

cleaning or maintenance procedures.

After each use, wipe down the mixer with a soft cloth. Do not immerse the unit or pour

liquids over it as electrical shock may occur. Clean up any spills immediately taking the

proper precautions. If required, the shaking head may be removed. First, disconnect

the vortexer from the power source and then remove the combo-cup head by holding the

housing securely while pulling up on the head. The head may then be cleaned with a

mild detergent. Be sure the head is thoroughly dry before replacing it on the unit.

The motor and shaking mechanism in the Vortex Mixer require no routine maintenance

or lubrication.

Appendix

Symbols and Conventions

The following chart is an illustrated glossary of the symbols that may be used in this

manual or on the product.

The electrical warning indicates the presence of a potential hazard which could

result in electrical shock.

CAUTION This symbol refers you to important operating and maintenance

(servicing) instructions within the product Instruction Manual. Failure to heed this

information may present a risk of damage or injury to persons or equipment.

This symbol identifies a Protective Earth (PE) terminal, which is provided for

connection of the supply system’s protective earth (green or green/yellow)

conductor.

EQUIPMENT DISPOSAL-EUROPEAN REGULATIONS

According to Directive 2012/19/EU of the European

Parliament and of the Council of 4 July 2012 on waste

electrical and electronic equipment (WEEE), Labnet Vortex

Mixer is marked with the crossed-out wheeled bin and must

not be disposed of with domestic waste.

Consequently, the buyer shall follow the instructions for reuse

and recycling of waste electronic and electrical equipment

(WEEE) provided with the products and available at the

following link: www.corning.com/weee

LIMITED WARRANTY

Labnet International Inc. warrants that this product will be free from defects in material

and workmanship for a period of one (1) year from date of purchase. This warranty is

valid only if the product is used for its intended purpose and within the guidelines

specified in the supplied instruction manual.

Should this product require service, contact Labnet’s Service department at 732-417-

0700 to receive a return authorization number and shipping instructions. Products

received without proper authorization will be returned. All items returned for service

should be sent postage prepaid in the original packaging or other suitable carton,

padded to avoid damage. Labnet International Inc.will not be responsible for damage

incurred by improper packaging. Labnet may elect for onsite service for larger

equipment.

This warranty does not cover damage caused by accident, neglect, misuse, improper

service, natural forces or other causes not arising from defects in original material or

workmanship. This warranty does not cover motor brushes, fuses, light bulbs, batteries

or damage to paint or finish. Claims for transit damage should be filed with the

transportation carrier.

ALL WARRANTIES INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION OF 12

MONTHS FROM THE ORIGINAL DATE OF PURCHASE.

LABNET’S SOLE OBLIGATION UNDER THIS WARRANTY IS LIMITED TO THE

REPAIR OR REPLACEMENT, AT LABNET INTERNATIONAL INC.’S. DISCRETION,

OF A DEFECTIVE PRODUCT. LABNET INTERNATIONAL, INC. IS NOT LIABLE FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGE, COMMERCIAL LOSS OR ANY

OTHER DAMAGES RESULTING FROM THE USE OF THIS PRODUCT.

Some states do not allow limitation on the length of implied warranties or the exclusion

or limitation of incidental or consequential damages. This warranty gives you specific

legal rights. You may have other rights which vary from state to state.

No individual may accept for, or on behalf of Labnet International Inc., any other

obligation of liability, or extend the period of this warranty.

Please register your product online at:

www.labnetinternational.com

Warranty/Disclaimer: Unless otherwise specified, all products are for research use only. Not

intended for use in diagnostic or therapeutic procedures. Labnet International makes no claims

regarding the performance of these products for clinical or diagnostic applications.

9299290000

31 Mayfield Ave. Edison, NJ 08837

P: +732-417-0700 F: +732-417-1750

Toll Free: 888-522-6381

labnetinfo@corning.com
