Model: WT-3143A www.lacrossetechnology.com/support Page | 1

Model: WT-3143A

Instruction Manual

DC: 031716

14” Atomic Wall Clock

Get Started

1: Slide the switch to select a time zone and DST ON or OFF.

2: Insert 1 freshAA, LR6 1.5 volt ALKALINE battery according to the polarity

marked on the case.

OPTIONAL: To extend battery life (over 3 years), insert two batteries in the

compartment below the movement.

3: For the best reception, please place clock on a wall that faces Ft. Collins,

Colorado. During the night, your clock will automatically set itself.

Note: The hands will move to the 12:00 position and search for the radio signal.

If the radio signal is not received in the first 10 minutes, the clock will start

running from the 12:00 position and will continue to run. Do not attempt to

reset the hands manually even though the time on the clock is incorrect. The

clock is synchronizing to the WWVB signal and once the radio signal is decoded,

the hands will automatically adjust to the correct time. This may take up to 5

nights if there is atmospheric interference.

Position Clock

•Signal reception is at its peak when there is only one wall or window

between the clock and the outside.

•The antenna is best positioned for signal reception when the front or back of

the clock faces Colorado.

•Choose a location 6 feet or more from electronics such as cordless phones,

wireless gaming systems, televisions, microwaves, routers, baby monitors,

etc., which can prevent signal reception.

•Large office buildings, schools, or hospitals may not receive the WWVB time

signal in every room.

Time Zone

DST ON/OFF

Model: WT-3143A www.lacrossetechnology.com/support Page | 2

•Building with a metal roof may interfere with reception.

Reset:If the clock does not respond to the various function modes, reset the

clock by pressing the RESET button on the movement case.

Manual Set Time

On rare occasions in certain areas, the clock may not be

able to utilize the radio controlled function because of the

strength of the signal or the geographic location. In this

case, the clock can be set manually and used as a regular

quartz wall clock.

Note: Allow up to five nights for the clock to receive the WWVB signal before

manually setting the time.

Set the clock manually:

1. Press and hold the SET button for 3+ seconds to activate the manual mode.

Once the clock is in manual mode, there are two ways to move the minute

hand forward.

2. Hold the SET button down to move the minute hand forward consistently.

3. Alternatively, press the SET button rapidly (more than once per second) to

move the minute hand forward step by step (in minute increments).

4. Use these features to move the minute hand forward until the correct time is

set. The clock will automatically leave manual mode after the SET button is

not pressed for 6+ seconds.

Troubleshooting

The wonderful advantage of owning a radio-controlled clock is that it is virtually

trouble free. If the clock receives a clear time signal, it will set itself perfectly. If it

does not receive a time signal, consider the following:

•Battery – The clock must have a fresh battery to receive and process the

time signal.

•Location – Try a different location, ideally near a window. Your clock should

be at least six feet from computers, TVs, air conditioners, other radio-

controlled clocks and other electrical appliances that cause interference.

•Weather – Electrical storms between you and Colorado during the night will

interfere with the WWVB signal.

Daylight Saving Time:

The National Institute of Standards and Technology and WWVB encode a special

DST “bit” in the WWVB transmission for DST. Your clock will read this information

and automatically advance the hands one hour in the spring and eleven hours in

the fall.

Arizona

If you live in an area that does not recognize DST, you must slide the DST switch

OFF. To reactivate the DST program simply slide the switch to the ON position.

Model: WT-3143A www.lacrossetechnology.com/support Page | 3

Manual WWVB Time Signal Search

For information about WWVB, visit: www.nist.gov/pml/div688/grp40/wwvb.cfm

Manual Signal Search:

The WWVB signal is strongest at night.

•Hold the WAVE button down for 3+ seconds.

•The hands will automatically reset to the 12:00 position, and the movement

will search for the WWVB time signal from Fort Collins, CO.

•If the movement successfully receives the signal, the clock will reset

automatically to the correct time. The signal search takes approximately 3-8

minutes.

•Set the clock manually, and the movement's micro-CPU will control the time

keeping function.

Internal Synchronization:

Once the clock has set correctly by the radio signal, the clock’s CPU operates

continuously. To ensure accuracy, the clock synchronizes the position of the

second and minute hands to the time calculated by the CPU every day. Second

hand synchronization occurs at 1:30 a.m. and 9:30 a.m. and minute hand

synchronization occurs between 1:50 and 2:01 am every day.

Signal Interference:

In some cases, the signal is affected by weather conditions and electrical

interferences, or the location of the clock itself may result in poor reception. If the

clock has not synchronized to the correct time within a few days of activation, you

may need to move the clock to a different location.

Frequently Asked Questions

Q. How long will the battery last?

A.One good AAalkaline battery will last over 12 months, and over 3 years with

the optional, 2 additional batteries.

Q: Can I wire a control timing circuit to the La Crosse Technology® atomic

clock?

A: No, the clock cannot work on a timing circuit. Opening the clock voids the

warranty.

Q: Is there a booster antenna to receive the WWVB signal in a difficult

location?

A: No, the clock cannot work with a booster antenna. Opening the clock or

movement voids the warranty.

Q: Can I shut off the WWVB signal?

A: No. If you manually set the time, when the clock receives a WWVB signal,

that signal will override the manual set. The WAVE button will temporarily

stop a WWVB search, but will not permanent stop the clock from receiving a

WWVB time signal.

Model: WT-3143A www.lacrossetechnology.com/support Page | 4

Q: Is there a version of analog clock with more than the four continental US

times zones?

A: La Crosse Technology® does not make an analog clock with more than four

time zones. These time zones are P (Pacific Time), M (Mountain Time), C

Central Time), and E (Eastern Time).

Q: Why do the hands spin?

A: When the hands spin about the same time every day the clock is auto-

correcting the time. The hour hand should not spin more than twice around

the clock.

A: Hands may spin if the battery is under powered or over powered. Use only

Alkaline batteries in the clock.

Care and Maintenance

•Do not mix old and new batteries

•Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries

•Always purchase the correct size and grade of battery most suitable for

intended use.

•Replace all batteries of a set at the same time.

•Clean the battery contacts and also those of the device prior to battery

installation.

•Ensure the batteries are installed with correct polarity (+and -).

•Remove batteries from equipment which is not to be used for an extended

period of time.

•Remove expired batteries promptly.

Warranty and Support Information

La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of

purchase) on this product relating to manufacturing defects in materials &

workmanship.

Before returning a product, please contact our friendly customer support

with questions or visit our online help (manuals and FAQS):

Phone: 1-608-782-1610

Online Product Support: www.lacrossetechnology.com/support

Product Registration:

www.lacrossetechnology.com/support/register

View full warranty details online at:

www.lacrossetechnology.com/warranty_info.pdf

Warranty Address:

La Crosse Technology, Ltd

2830 S. 26th St.

La Crosse, WI 54601

Model: WT-3102S www.lacrossetechnology.com/support Page | 1

Model: WT-3102S

Instruction Manual

DC: 033115

10” Atomic Wall Clock

Get Started

Step 1: Slide the switch to select a time zone.

Step 2: Insert 1 fresh AA, Alkaline battery according to the

polarity marked on the case.

Step 3: For the best reception, please place clock on a wall that

faces Ft. Collins, Colorado. During the night, your clock

will automatically set itself.

When the battery is installed, the hands will move to the 12:00

position and search for the radio signal.

If the radio signal is not received in the first 10 minutes, the

clock will start running from the 12:00 position and will

continue to run.

Do not attempt to reset the hands manually even though the

time on the clock is incorrect. The clock is synchronizing to

the WWVB signal and once the radio signal is decoded, the

hands will automatically adjust to the correct time. This may

take up to 5 nights if there is atmospheric interference.

Reset: If the clock does not respond to the various function

modes, press the RESET button on the movement case.

Model: WT-3102S www.lacrossetechnology.com/support Page | 2

Position Clock

For the best reception, please place clock on a wall that faces

Ft. Collins, Colorado. The antenna is best positioned for signal

reception when there is only one wall or window between the

clock and outside.

Choose a location 6 feet or more from electronics such as

cordless phones, wireless gaming systems, televisions,

microwaves, routers, baby monitors, etc., which can prevent

signal reception.

Large office buildings, schools, or hospitals may not receive

the WWVB time signal in every room.

Buildings with a metal roof may interfere with reception.

Note: We recommend that you change the battery every 24

months to maintain accuracy. Remove the battery when the clock

will not be in use for an extended period.

Manual Set Time

On rare occasions, the clock may

not be able to utilize the radio

controlled function because of the

strength of the signal or the

geographic location. In this case,

the clock can be set manually and

used as a regular quartz wall clock.

Note: Allow up to five nights for the clock to receive the WWVB

signal before manually setting the time.

Set the clock manually:

1. Hold the SET button for 3+ seconds to activate the manual

mode. There are two ways to move the minute hand forward.

Hold the SET button down to move the minute hand

forward consistently.

Alternatively, press the SET button rapidly (more than once

per second) to move the minute hand forward step by step

(in minute increments).

Use these features to move the minute hand forward until

the correct time is set. The clock will automatically leave

manual mode after the SET button is not pressed for 6+

seconds.

Model: WT-3102S www.lacrossetechnology.com/support Page | 3

Troubleshooting

The wonderful advantage of owning a radio-controlled clock is that

it is virtually trouble free. If the clock receives a clear time signal, it

will set itself perfectly. If it does not receive a time signal, consider

the following:

Battery – The clock must have a fresh battery to receive and

process the time signal.

Location – Try a different location, ideally near a window that

faces Colorado.

 Weather – Electrical storms between you and Colorado

during the night will interfere with the WWVB signal.

Hands Spin- When the hands spin about the same time every

day the clock is auto-correcting the time. The hour hand

should not spin more than twice around the clock. Hands may

spin if the battery is under powered or over powered.

Daylight Saving Time:

The National Institute of Standards and Technology and WWVB

encode a special DST “bit” in the WWVB transmission for DST.

Your clock will read this information and automatically advance the

hands one hour in the spring and eleven hours in the fall.

If you live in an area that does not recognize DST, you must slide

the DST switch OFF. To reactivate the DST program simply slide

the switch to the ON position.

Manual WWVB Time Signal Search

For WWVB information: www.nist.gov/pml/div688/grp40/wwvb.cfm

Manual Signal Search:

The WWVB signal is strongest at night.

Hold the WAVE button down for 3+ seconds.

The hands will automatically reset to the 12:00 position, and

the clock will search for the WWVB time signal.

If the clock receives the signal, the clock will set automatically

to the correct time. The signal search takes approximately 3-8

minutes.

Set the clock manually, and the movement's micro-CPU will

control the time keeping function.

Model: WT-3102S www.lacrossetechnology.com/support Page | 4

Frequently Asked Questions

Q. How long will the battery last?

A. A good AA alkaline battery will last over 24 months.

Q: Can I wire a control timing circuit to the La Crosse Technology® atomic

clock?

A: The clock cannot work on a timing circuit. Opening the clock voids the warranty.

Q: Is there a booster antenna to receive the WWVB signal in a difficult location?

A: The clock cannot work with a booster antenna. Opening the clock or movement

voids the warranty.

Q: Can I shut off the WWVB signal?

A: No. If you manually set the time, when the clock receives a WWVB signal, that

signal will override the manual set. The WAVE button will temporarily stop a WWVB

search, but will not permanent stop the clock from receiving a WWVB time signal.

Care and Maintenance

Do not mix old and new batteries

Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries

Always purchase the correct size and grade of battery suitable for intended use.

Replace all batteries of a set at the same time.

Clean the battery contacts and also those of the device prior to battery

installation.

Ensure the batteries are installed with correct polarity (+and -).

Remove batteries from clock which is not to be used for an extended period of

time.

Remove expired batteries promptly.

Warranty and Support Information

La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of

purchase) on this product relating to manufacturing defects in materials &

workmanship.

Before returning a product, please contact our friendly customer support with

questions or visit our online help:

Phone: 1-608-782-1610

Online Product Support: www.lacrossetechnology.com/support

Product Registration:

www.lacrossetechnology.com/support/register

View full warranty details online at:

www.lacrossetechnology.com/warranty_info.pdf

Warranty Address:

La Crosse Technology, Ltd

2830 S. 26th St.

La Crosse, WI 54601

Autres manuels pour WT-3143A

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels La Crosse Technology Horloge

La Crosse Technology

La Crosse Technology WT-3161BK Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-1225 Manuel utilisateur

La Crosse Technology

La Crosse Technology BBB87740x1 Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1417V2 Dimensions

La Crosse Technology

La Crosse Technology W85961 Manuel utilisateur

La Crosse Technology

La Crosse Technology C86279v4 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8248U-CH Manuel utilisateur

La Crosse Technology

La Crosse Technology BBB87740 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-8029U Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1417CH Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1417CHv2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1429THV2 Dimensions

La Crosse Technology

La Crosse Technology WT-3181P Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8117U-AL Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1417ALv4 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8001U Manuel utilisateur

La Crosse Technology

La Crosse Technology W88631 Dimensions

La Crosse Technology

La Crosse Technology BBB85654 Manuel utilisateur

La Crosse Technology

La Crosse Technology 512-1422 Series Dimensions

La Crosse Technology

La Crosse Technology WS-8120U Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8007U Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-3181 Manuel utilisateur

La Crosse Technology

La Crosse Technology KWS-8140U-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-54667 Manuel utilisateur

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

Sharp

Sharp SPC900 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur

LG LEC-005 Manuel utilisateur

IKEA

IKEA ROTBLÖTA Manuel utilisateur

U-Line

U-Line Н-2811 Manuel utilisateur

Digiview

Digiview RC305EL Manuel utilisateur
