SET UP GUIDE
MODEL NUMBER C79141
LIGHT ALARM CLOCK
LIGHT ALARM CLOCK
Table of Contents
LIGHT MODESBASICS ALARMS
APPENDIX SUPPORT
Selecting Your Light Mode
Color Cycle Mode
Evening Mode
Guided Breathing Mode
Comfort Meter Mode
Color Select Mode
Glow Color Options
Initial Setup
Buttons & Ports
LCD Display
LCD Display Brightness
Auto-Dim Settings
USB Charging Port
Temperature & Humidity
Natural Light Alarm
Setting the Light Alarm
Setting the Sound Alarm
Snoozing the Sound Alarm
Specifications
Warranty
Cautions/Statements
Recycling & Disposal
Support Information
Factory Reset
Stay in Touch
02
03
04
05
05
06
06
17
18
18-20
20
21
21
21
07
08
09
10
11
12
13
14
15
16
16
Use the +/- buttons on
the front of the clock to
adjust the values.
02
Initial Setup
Power Up
Settings Menu Order
Insert the 5V Power Adapter into an outlet, and then plug it into the AC Jack
on the bottom of the alarm clock. Next, remove the Insulation Tab from the
Battery Compartment.
A greeting will appear on the LCD display and then your clock will move into the
Settings Menu. The Color Cycle Light Mode will also begin.
Language • Hour • Minutes • Year • Month • Date • Fahrenheit/Celsius
BASICS
Press the button on
the back of the clock to
confirm selection and
move to next step.
You may exit the Settings
Menu at any time by
tapping the button.
Note: To enter the Settings Menu after the initial setup, hold the button on the
back of the clock.
Note: Weekday will set automatically after year, month, & date settings are adjusted.
03
Buttons & Ports
BASICS
1. DISPLAY ( )
Tap to adjust backlight
intensity or hold to enter
Auto-Dim settings
4. LIGHT ( )
Tap to toggle through light
modes. Tap to confirm
light mode selection
2. PLUS/MINUS (+/-)
Tap to control glow light
intensity or hold to
adjust quickly
5. USB CHARGING PORT
Connect USB charging
cable (not included)
3. SNOOZE ( )
Tap to snooze the sound
alarm, exit menus, or to
turn the light o
9. FACTORY RESET
Press to restore factory
settings
10.
Connect AC adapter
AC JACK
11.
Saves settings and
alarm function during
power outages
BACKUP BATTERY
1 4 5 10 11
9
678
3
2
6. SOUND ALARM ( )
Press to activate or hold
to enter alarm settings
8. LIGHT ALARM ( )
Press to activate or hold
to enter alarm settings
7. SET ( )
Hold to enter Settings
Menu
04
LCD Display
BASICS
Notes: Only one light and one sound alarm can be programmed. These can be set to
go o together or at separate times.
AM/PM
Indicator
1.3-Inch
Time Digits
Auto-Dim
Indicator Weekday
Indoor
Temperature
(°F/°C)
Indoor
Humidity
Low Battery
Indicator
Light Alarm Indicator
and Alarm Frequency Month & Date Sound Alarm Indicator
and Alarm Frequency
Daily
Weekday (Monday-Friday)
Weekend (Saturday & Sunday)
Set a Daily, Weekday,
or Weekend Alarm
Daily
Weekday (Monday-Friday)
Weekend (Saturday & Sunday)
Light and Sound Alarm Frequencies
05
LCD Display Brightness
The icon will appear on the LCD when activated.
BASICS
Adjusting the LCD Display Brightness
Tap the button to adjust the backlight intensity.
There are 4 brightness levels, plus an o option.
Auto-Dim Settings
1.
2.
3.
4.
Hold the button to enter
the Auto-Dim Settings Menu.
Program your LCD display to automatically dim during preselected times.
Tap the +/- buttons to turn
the Auto-Dim feature on or
o. Tap to confirm.
Tap the +/- buttons to adjust
the start time. Tap to
confirm.
Tap the +/- buttons to adjust
the stop time. Tap to
confirm and exit.
06
USB Charging Port
Temperature & Humidity
There is a 1 Amp USB Charging Port located on
the right side of your alarm clock.
Connect your external device’s USB charging
cable (not included) into the USB Charging Port.
Charging times will vary.
USB Power Output: 1 Amp Maximum Current
View real-time indoor temperature & humidity data on your alarm clock.
CelsiusFahrenheit
BASICS
You can select Fahrenheit or Celsius in the main Settings Menu.
07
Natural Light Alarm
ALARMS
Gradual Wake Up
The Light Alarm will begin 30 minutes before your set alarm time. The light will
gradually increase in intensity until reaching full brightness at your set alarm time.
The light will remain on and at full power until a button is pressed.
Example:
The Soluna Light Alarm Clock is
equipped with a glowing Light Alarm
that simulates the sunrise. Use the
Light Alarm to wake up peacefully
and help reset your circadian rhythm.
Note: If you set an alarm for less than 30 minutes from the current time,
the Light Alarm will accelerate the brightness accordingly.
6:30 7:307:00
Based on 7:00am alarm time
ALARM FREQUENCIES
08
Setting the Light Alarm
ALARMS
Setting the Light Alarm
1. Hold the button on the back of the clock
to enter the Light Alarm Settings Menu.
DAILY ALARM will appear on the LCD.
Activating & Deactivating the Light Alarm
2.
3.
4.
Use the +/- buttons to select your alarm
frequency. Choose from Daily (1-7),
Weekday (1-5), or Weekend (6-7) options.
Press to confirm.
Next, Use the +/- buttons to set your desired
time. Press to confirm.
Your Light Alarm is now activated, indicated
by icon and alarm frequency (1-5, 1-7, or
6-7) on the LCD.
1-7 Daily Alarm
(MondaySunday)
1-5 Weekday Alarm
(MondayFriday)
6-7 Weekend Alarm
(SaturdaySunday)
1.
2.
Press the button on the back of the
clock to view your Light Alarm time and
activate/deactivate the alarm.
The icon and alarm frequency will appear
on the LCD when the alarm is active.
Notes: The 17 Daily Alarm is the default alarm frequency. There is no sound with
the Light Alarm. If a sound alarm is wanted, you will need to activate the Melody
Sound Alarm.
Only one light and one sound
alarm can be programmed.
These can be set to go o
together or at separate times.
09
ALARMS
ALARM FREQUENCIES
1-7 Daily Alarm
(MondaySunday)
1-5 Weekday Alarm
(MondayFriday)
6-7 Weekend Alarm
(SaturdaySunday)
Only one light and one sound
alarm can be programmed.
These can be set to go o
together or at separate times.
Setting the Melody Sound Alarm
1. Hold the button on the back of the clock
to enter the Sound Alarm Settings Menu.
DAILY ALARM will appear on the LCD.
2.
4.
3.
Use the +/- buttons to select your alarm
frequency. Choose from Daily (1-7), Weekday
(1-5), or Weekend (6-7) options. Press to
confirm.
Next, use the +/- buttons to set your desired
snooze duration (5 to 120 minutes).
Press to confirm and to exit the Sound
Alarm Settings Menu.
Next, Use the +/- buttons to set your desired
time. Press to confirm.
Activating & Deactivating the Sound Alarm
1.
2.
Press the button on the back of the clock
to view your Sound Alarm time and activate/
deactivate the alarm.
The icon and alarm frequency will appear
on the LCD when the alarm is active.
Note: The 17 Daily Alarm is
the default alarm frequency.
Setting the Sound Alarm
5. Your Sound Alarm is now activated, indicated
by icon and alarm frequency (1-7, 1-5, or
6-7) on the LCD.
