Kyla KCTR-610-WR Instructions d'utilisation
SMART CURTAIN
EASY START GUIDE
3
Thank you for using Kyla product(s)! Please keep this Easy Start Guide for future reference. For support or help, visit kylas.aztech.com
DISCLAIMER
AztechTechnologiesPteLtd,itsholdingcompanyanditsassociatedcompanies(hereinafterreferredtocollectivelyas“Aztech”)doesnotguaranteethatadequate
warning or protection will be given, and disclaims all warranties and representations, whether expressed, implied or otherwise statutory, concerning the product,
including without limitation any warranty of merchantability or tness for a particular purpose. Aztech shall not be liable in any event for any consequential,
indirect, incidental, special, exemplary, punitive or enhanced damages resulting from the use, maintenance or operation of the product.
The manufacturer makes no warranty or representation that the product constitutes a re alarm system or is compliant with any requirements prescribed by
any applicable state or laws, codes, regulations and/or other specications that may be set out by relevant authorities having jurisdiction (collectively referred
to as “regulations”). You shall be solely responsible for compliance with all regulations.
To the maximum extent permitted by applicable law, you agree to hold harmless and indemnify, including legal fees, the manufacturer and their personnel
against any third party claims or nes by authorities that arise or are alleged to have arisen as a result of negligent or intentional act or omission by you or
breach by you of any the terms herein or any violation of any regulations.
4
ATTENTION
This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of this product by a person responsible for their safety.
Children should be supervised to ensure that they do not play with this product.
The instruction concerning persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge is not
applicable.
If the supplied cable is damaged, contact Aztech, its service agent or similarly qualied persons for replacement, in order to avoid a hazard.
Important safety instructions for users to strictly follow:
• The minimum installation distance from the bottom of the Smart Curtain to the oor is 2.5m.
• Do not allow children to play with xed controls. Keep remote controls away from children.
• Frequently examine the installation for imbalance and signs of wear and damage to cables and moving parts. Do not use if repair or adjustment is necessary.
Follow these important safety installation instructions to prevent severe injury:
• Before installing the motor, remove any unnecessary cables and remove any equipment that is not needed for powered operation.
5
PACKAGE CONTENTS
• Smart Curtain X 1
• Easy Start Guide X 1
• Warranty Card X 1
PRODUCT DESCRIPTION
The Smart Curtain Motor, controllable via the Kyla app on a mobile device or the curtain remote control, provides improved flexibility over traditional manual curtains. The curtain can
be adjusted to open or close based on different scene settings, in accordance to the comfort and environment of the user.
PRODUCT FEATURES
Wide-range power supply: 100–240 VAC for global compatibility
Various controls: Through the app, Light Touch function, external wired switch, or the Curtain Remote Control (optional accessory)
Light Touch function: After powering on, pull the curtain slightly about 15cm, the curtain will open/close automatically
Low-noise operation: High-precision drive for smooth and gentle operation
Multiple limit points: Automatically remember the window width to determine limit points such as fully open, half-open, and quarter-open, reducing conguration time.
App control: Control and manage the device via the app.
Scene control: Preset the Smart Curtain and other Kyla devices into one scene and control them simultaneously.
Automation control:
Operates the Smart Curtain automatically when the sensor (separate smart device) is triggered, e.g. draws the curtain close when someone opens the door.
6
SPECIFICATIONS
Model: KCTR-610-WR
Input: 100–240 VAC, 50–60 Hz
Maximum Current: 0.2 A
Maximum Power: 45 W
Operating Temperature: -20–70°C
Operating Humidity: ≤ 85% RH
Connectivity: 2.4 GHz WiFi, RF 433 MHz
Track Length: 1/2/4 m
Maximum Load: 50 kg (Curtain with 4m Track)
Rated Torque: 1.5 N.m
Working Speed: 10 cm/s
Material of Housing: PC, White
Mounting Type: Wall/Ceiling Mount
Product Dimensions: L50 x W65 x H247 mm
Certificate(s): FCC, CE, IMDA
7
STRUCTURE AND INSTALLATION KIT
Hook
Master box
Lock
Curtain
motor
Master box Sub box Pulley Ceiling bracket Belt Track
Hanger Lock Splice Connector Single track bracket Double track bracket
Track
Belt
Pulley Hanger
Sub box
Lock
8
INSTALLATION GUIDELINES
ATTENTION: The minimum installation distance from the bottom of the Smart Curtain to the oor is 2.5m
Distance between two brackets ≤ 500mm Ceiling bracket Single track Double track (two curtains) Duel tracks (fabric and silk curtains)
9
INSTALLING THE CURTAIN TRACK
1. Attach the buckle and clip at the end
of the belt. 2. Attach the pulley on the buckle. 3. Slide the pulley through the track. 4. Detach both the buckle and pulley
from the belt.
10
INSTALLING THE CURTAIN TRACK
5. Place the gear into the end cap. 6. Insert the belt into the end cap
through the gear. 7. Place the buckle and pulley at the end
of the belt. Then slide the pulley until it
reaches the tip of the track.
8. Attach the end cap to the track.
