KVM-TEC SmartLINE SVX Manuel utilisateur

Check out

our Installation Channel:

www.kvm-tec.com

6501 SET SMARTLINE SVX IN

COPPER

6501L CPU/LOCAL

6501R CON/REMOTE

6502 SET SMARTLINE DUAL

SVX2 IN COPPER

6502L CPU/LOCAL

6502R CON/REMOTE

CHECK YOUR EXTENDER

line

smart

kvm-tec

First

Aid

connect collaborate communicate control

kvm-tec = C 4

First

Aid

kvm-tec

line

smart

1. First check your delivery content SVX1....

1. power plug

12V 1A

4. DVI

in from PC

2. USB to PC

4. DVI out

to Monitor

power plug

12-24 VDC

2. USB from

Keyboard and Mouse

3. Network cable CAT 5e/6/7 up to 150m/492ft

4. DVI to Monitor

Quick Installation SVX1 SMARTLINE local / CPU – remote / CON

1. Connect the CON / Remote and the CPU / Local Unit to the included 12V 1A power supply.

2. Now connect the USB cable to a USB port on your PC and connect the other end of the USB cable to the CPU /

Local Unit. Connect keyboard and mouse to the CON / Remote Unit.

3. Connect the CPU / Local and the CON / Remote Unit with a network cable.

4. Now connect the DVI cable to the DVI socket of the PC and the other end to the DVI socket of the CPU / Local

Unit (PC-in). Then connect the monitor with the DVI cable to the CON / Remote Unit.

HAVE FUN - your kvm-tec Extender is now in use for many years (MTBF approx 10 years)

3. Than check your installation....

LOCAL/CPU Unit SVX1

o 1 x SVX 1 local (CPU)

o 1 x wall power supply 12V 1A

o EU-plug or INT Plug

o 1 x DVI - cable 1,8m/5,9ft

o 1 x USB cable 1,8m/ 5,9 ft

o 4 x rubber feet

REMOTE/CON Unit

o 1 x SVX1 remote (CON)

o 1 x wall power supply 12V 1A (EUplug) or

INT plug

o 1 x DVI - cable 1,8m/5,9ft

o 4 x rubber feet

2. Are your upgrades for SMART-

LINE SVX1 unlocked

possible upgrades for SMARTLINE SVX1

Matrix Switching System up to 48 endpoints

(First Aid Switching System for questions)

USB Memory

to unlock upgrades, please send an email or give us a

call. Please have your ID code ready. (you ﬁ nd your ID in

the OSD menu by pressing the button „M“ - Device ID)

You´ll get a code from our support team.

Please, enter the code

First

Aid

kvm-tec

smart line

DC USB USB KVM-Link

Monitor

Out

KVM-TEC Smartline Remote / Mon

DC USB USB KVM-Link

Monitor

Out

Remote / Mon

14 1613 15

19 2118 20

LOCAL/CPU Unit SVX2

o 1 x SVX 2 local (CPU)

o 1 x wall power supply 12V 1A

o EU-plug or INT Plug

o 2 x DVI - cable 1,8m/5,9ft

o 2 x USB cable 1,8m/ 5,9 ft

o 4 x rubber feet

REMOTE/CON Unit

o 1 x SVX2 remote (CON)

o 1 x wall power supply12V 1A (EUplug)

o or INT plug

o 2 x DVI - cable1,8m/5,9ft

o 4 x rubber feet

1. power plug

12V 1A

4. DVI in

from PC

2. USB to PC

4. DVI out

to Monitor

1. power plug

12-24 VDC

2. USB from

Keyboard and Mouse

KVM-TEC Smartline Local / PC

DC PC

USB

KVM-Link

Monitor

Out

KVM-TEC Smartline Local / PC

DC PC

USB

KVM-Link

Monitor

Out

3. Network cable CAT 5e/6/7 up to 150m/492ft

1. power plug

12V 1A

2. USB from

Kayboard and Mouse

Quick Installation SVX2 SMARTLINE local / CPU – remote / CON

1. Connect the CON / Remote and the CPU / Local Unit with the included 12V 2A power supply.

2. Now connect the USB cable to a USB port on your PC and connect the other end of the USB cable to the CPU /

Local Unit. Connect keyboard and mouse to the CON / Remote Unit.

3. Connect the CPU / Local and the CON / Remote Unit with two network cables.

4. Now connect the DVI cable to the DVI socket of the PC and the other end to the DVI socket of the CPU / Local

Unit (PC-in). Then connect the monitor with the DVI cable to the CON / Remote Unit.

HAVE FUN - your kvm-tec Extender is now in use for many years (MTBF approx 10 years)

2. USB to PC

4. DVI out

to Monitor

4. DVI out

to Monitor

4. DVI out

to Monitor

4. DVI in

from PC

3. Network cable CAT5e/6/7 up to 150m/492ft

1. First check your delivery content SVX2....

2. Are your upgrades for SMARTLINE

SVX2 unlocked

possible upgrades for SMARTLINE SVX2

Matrix Switching System up to 48 endpoints

(First Aid Switching System for questions)

USB Memory

3. Than check your installation....

to unlock upgrades, please send an email or give us a

call. Please have your ID code ready. (you ﬁ nd your ID in

the OSD menu by pressing the button „M“ - Device ID)

You´ll get a code from our support team.

Please, enter the code

First

Aid

kvm-tec

line

smart

4. Check the LEDS to get more information....

Error Cause Solution

LED is not

lighting

The devices get no power Is the power supply connected? (white box)

LED is lighting

in red

No connection between

Loc and Rem

Check if the RJ45/network cable is connected well. (Clicking noise when

plugging in)

Control both, if it does not work please send an e-mail to support@kvm-

tec.com

LED is lighting

in orange

No picture on the monitor Check if the local/CPU (PC) cable is connected well.

Check if the remote/CON (monitor) cable is connected well.

If everything is connected well but no function appears, reconnect

power supply again.

If the menu is visible, press the Okey and choose the resolution of the

monitor. Then press the assigned number on your keyboard.

LED is lighting

green

Screen occurs but the

keyboard is not working

Plug out/in USB of keyboard and wait until driver is installed (after few

seconds).

Check all USB connections on both sides (Local and Remote)

If it is still not working, plug out/in DC once more

LED is lighting

green

No audio Establish audio connection:

plug stereo-jack to the audio output of the PC (green) connection with

local: IN

remote: headset OUT

Establish microphone connection:

plug stereo-jack to the microphone input of the PC (pink)

connection with local OUT

LED is lighting

green

The screen ﬂ ickers, has

an incorrect display

Install current ﬁ rmware from our homepage www.kvm-tec.com/

support/ﬁ rmware-download

LED is blinking

green

Diﬀ erent ﬁ rmware or

USB is not compatible

e-mail to [email protected]

LED are

lighting

diﬀ erently

Diﬀ erent ﬁ rmware To enter on screen menu/check ﬁ rmware version:

To enter the On screen menu, press the Scroll Lock key ﬁ ve times in

quick succession. The currently installed ﬁ rmware version is displayed

below the menu

If ﬁ rmware update does not work, please send an e-mail to support@

kvm-tec.com

First

Aid

kvm-tec

smart line

5. Your Extender....

Video error

(stripes in the

picture)

USB is not

working

No Power

(No LED)

Check the

powerplug

Is the power

supply ok? Try

another Unit.

Try reprogramming

the Unit by using a

JTAG programmer

Contact kvm-tec

support

Are the USB

Devices plugged

in correctly?

Is the USB cable

on the Local side

plugged into the

PC?

Are the USB

Devices working

directly on the

PC?

Check if local and

remote Unit have

the same ﬁ rm-

ware

Replace the USB

cable from PC to

the Local Exten-

der

Check if the local

or the remote

Unit is causing

the problem by

swaping ﬁ rst the

local and than the

remote Unit to

another Unit

Contact kvm-tec

support

Check if all

cables are plug-

ged in correctly

Check if the PC is

sending a Image by

plugging in a

monitor on the

local out of the

local Unit

Check if the DDC is

set correctly (in menu

under point „O“)

Check if both

Units have the

correct ﬁ rmware

No Video

Contact kvm-tec

support

Check if all

cables are plug-

ged in correctly

Check if the PC is

sending a Image

by plugging in a

monitor on the

local out of the

local Unit

Check if local and re-

mote Unit have the

correct ﬁ rmware

Check if the DDC

is set correctly (in

the menu under

point „o“)

Check if the net-

work switch is

setup correctly

and has enough

bandwidth

Contact kvm-tec

support

Check if other units

have the same

behaviour

We are here for you to answer

your questions about installation?

Manual download www.kvm-tec.com

kvm-tec Installationchannel on our homepage

personally +43 2253 81912

kvm-tec Support

[email protected]

Phone: +43 2253 81912 - 30

First

Aid

kvm-tec

line

smart

6. Check the ﬁ rmware version ....

To view the ﬁ rmware version

Make sure the main menu is open. The currently installed ﬁ rmware version of the remote and local units are

displayed (e.g. ‘4267’) and check that you have the same ﬁ rmware on both units.

Ways to update the ﬁ rmware version ....

There are four ways to perform an update:

1. update via a bitmap image

2. automatic update

3. network update

how to update the ﬁ rmware version ....

To perform a ﬁ rmware update:

1. Make sure the main menu is open.

2. Press the Nkey to do a network update.

3. Press the Akey to do an automatic update.

4. Press the Ukey to do a direct update.

5. Press the Skey to do a USB Update.

Update service with kvm-tec Switching Manager....

For all our devices of the SVX and MVX series we deliver a free demo version of the kvm-tec Switching Manager Software

(Item No. 4004) for a comfortable update of all units in the switching system. For our devices of the MX and UVX series

the Switching Manager is included.

This is a comfortable update management for your switching system.

You can update all extenders at the same time. The update is performed in the background and in a second step the

units are rebooting with the new ﬁ rmware.

Only a short time is needed for the second step.

ATTENTION ! Only when the bar is grey, the update is ﬁ nished.

First

Aid

kvm-tec

smart line

o identify your extender

o ﬁ rst check your delivery content

o are all needed upgrades are unlocked

o all cables are connected and all units are switched on

o check the LED status

o Video - check if the DDC is set correctly (in menu under point „O“ )

o USB - are all cables connected

o in case of issues check the ﬁ rmware version (download for the newest ﬁ rmware kvm-tec.com/support )

if everything is working ﬁ ne - perfect

Tipps from our engineers for engineers

• reduce the setting of your system and set up only one local and one remote at the same place

• connect the monitor directly to the PC - does the monitor display an image ? (follow the mentioned steps

from above)

• LED status is red or blinking - this can be a cable problem - try to get a short patchcable and to connect

the units and be sure that it´s not a cross - over cable

• USB problems with mouse and keyboard - please try a diﬀ erent type of mouse and keyboard

Further expert tipps for issues

• Adapter - our units are transmitting DVI signals. If you are using adapters try a PC with DVI signal

• PC - please try another machine

• If you have more sets please make a cross check and change of the units

Further steps

Please, ﬁ ll out the support form

and contact our support team +43 2253 81912 - 30

7. Checklist ....

First

Aid

kvm-tec

line

smart

If the shoe pinches, then we are there for you!

Support Form

Support - request

If the shoe pinches, then we are there for you!

Contact Information

Company

Contact person

phone number

customer from

device type

SVX1

MVX1 Fiber copper

MX48 Fiber copper

MX2000 Fiber copper

UVX Fiber copper

Switching Manager

copper SVX2

MVX2 Fiber copper

copper

Firmware & Upgrade

Firmware Nr.:

Memory Option

RS232

VGA

Sound

Switching

Other connected devices

(Switches, HUBs, Touch-

screens, Webcams,.....)

To support your case as quickly as possible

and to be able to process and track your data,

we ask you to provide us with

the following information.

After we have received your mail, a sup-

port ticket is automatically created in

our ticket system, where all informati-

on about your support case is stored.

and are traceable at any time.

This way the support team has all the infor-

mation about your system in a direct con-

versation and your advantage is that the

questions can be answered in a targeted and

faster way.

Problem description

Almost done! If you want to be even faster on the phone, the following data would be helpful:

No power

No Link

VGA problem

No connection

DOA (dead on

arrival)

Stripy screen

No Video

No USB

Mouse/ Key-

board doesn´t

work

LED Status local/CPU

LED Status remote/CON

red orange green

glowing ﬂ ashing

red orange green

glowing ﬂ ashing

Please send the form to [email protected].

Thank you very much! As soon as we have received your mail, it will be tracked in our system as a support case and we will

contact you immediately!

Resolution:

Fix

kvm-tec electronic gmbh

Gewerbepark Mitterfeld 1A, 2523 Tattendorf, Austria

+43 2253 81912-30 - support@kvm-tec.com

copper

First

Aid

kvm-tec

smart line

RMA Form

If the shoe pinches, then we are there for you!

RMA - request

If the shoe pinches, then we are there for you!

Contact Information

Company

Contact person

phone number

customer from

device type

SVX1

MVX1 Fiber copper

MX48 Fiber copper

MX2000 Fiber copper

UVX Fiber copper

Switching Manager

copper SVX2

MVX2 Fiber copper

copper

Firmware & Upgrade

Firmware Nr.:

Memory Option

RS232

VGA

Sound

Switching

Other connected devices

(Switches, HUBs, Touch-

screens, Webcams,.....)

Problem description

Almost done! If you want to be even faster on the phone, the following data would be helpful:

No power

No Link

VGA problem

No connection

DOA (dead on

arrival)

Stripy screen

No Video

No USB

Mouse/ Key-

board doesn´t

work

LED Status local/CPU

LED Status remote/CON

red orange green

glowing ﬂ ashing

red orange green

glowing ﬂ ashing

Please send your RMA to Heidi Brosig email [email protected]

Resolution:

Fix

kvm-tec electronic gmbh

Gewerbepark Mitterfeld 1A, 2523 Tattendorf, Austria

+43 2253 81912-30 - support@kvm-tec.com

copper

RMA Number

Autres manuels pour SmartLINE SVX

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels KVM-TEC Extenseur

KVM-TEC

KVM-TEC Ultraline UVX1 Manuel utilisateur

KVM-TEC

KVM-TEC INDUSTRYFLEXline Manuel utilisateur

KVM-TEC

KVM-TEC Master Line MVX Series Manuel utilisateur

KVM-TEC

KVM-TEC ECOsmart KT-6035 Manuel utilisateur

KVM-TEC

KVM-TEC Smartline SVX Series Manuel utilisateur

KVM-TEC

KVM-TEC media4Kconnect Manuel utilisateur

KVM-TEC

KVM-TEC USBflex Instructions d'utilisation d'origine

KVM-TEC

KVM-TEC USBflex Manuel utilisateur

KVM-TEC

KVM-TEC ScalableLine KT-6990L Manuel utilisateur

KVM-TEC

KVM-TEC USBflex Instructions d'utilisation d'origine

KVM-TEC

KVM-TEC Matrixline 2000 Series Manuel utilisateur

KVM-TEC

KVM-TEC media4Kconnect 6930 DP1.2 Manuel utilisateur

KVM-TEC

KVM-TEC masterEASY Manuel de l'opérateur

KVM-TEC

KVM-TEC MASTERflex KT-6012 Manuel utilisateur

KVM-TEC

KVM-TEC masterEASY Manuel utilisateur

KVM-TEC

KVM-TEC USBflex Instructions d'utilisation d'origine

KVM-TEC

KVM-TEC FLEXLINE KT-6011 Manuel utilisateur

KVM-TEC

KVM-TEC Smartline Dual SVX2 Series Manuel de l'opérateur

KVM-TEC

KVM-TEC USBflex Instructions d'utilisation d'origine

KVM-TEC

KVM-TEC smartEasy Manuel de l'opérateur

KVM-TEC

KVM-TEC SMARTflex Manuel utilisateur

KVM-TEC

KVM-TEC USBflex Instructions d'utilisation d'origine

KVM-TEC

KVM-TEC Smartline Dual SVX2 Series Manuel utilisateur

KVM-TEC

KVM-TEC 6935 Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
