KVM-TEC Matrixline MX Manuel de l'opérateur

kvm-tec

First Aid

Video error

(stripes in the

picture)

USB is not

working

No Power

(No LED)

Check the

powerplug

Is the power

supply ok? Try

another Unit.

Try reprogramming

the Unit by using a

JTAG programmer

Contact kvm-tec

support

Are the USB

Devices plugged

in correctly?

Is the USB cable

on the Local side

plugged into the

PC?

Are the USB

Devices working

directly on the

PC?

Check if local

and remote Unit

have the same

ﬁ rmware

Replace the USB

cable from PC to

the Local

Extender

Check if the local

or the remote

Unit is causing

the problem by

swaping ﬁ rst the

local and than the

remote Unit to

another Unit

Contact kvm-tec

support

Check if all

cables are plug-

ged in correctly

Check if the PC is

sending a Image by

plugging in a

monitor on the

local out of the

local Unit

Check if the DDC is

set correctly (in menu

under point „O“)

Check if both

Units have the

correct ﬁ rmware

No Video

Contact kvm-tec

support

Check if all

cables are plug-

ged in correctly

Check if the PC is

sending a Image

by plugging in a

monitor on the

local out of the

local Unit

Check if local and re-

mote Unit have the

correct ﬁ rmware

Check if the DDC

is set correctly (in

the menu under

point „o“)

Check if the

network switch

is setup correctly

and has enough

bandwidth

Contact kvm-tec

support

Check if other units

have the same

behaviour

We are here for you to answer

your questions about installation?

Manual download www.kvm-tec.com

kvm-tec Installationchannel on our homepage

personally +43 2253 81912

kvm-tec Support

[email protected]

Phone: +43 2253 81912 - 30

Check out

our Installation Channel:

www.kvm-tec.com

line

matrix

kvm-tec

Quick

Instruction

Matrixline

6711 SET

6711L CPU/LOCAL

6711R CON/REMOTE

connect collaborate communicate control

kvm-tec = C 4

Power plug

12V 1A

DVI in

from PC

USB to PC

DVI out

to Monitor

Audio

from PC

Audio to PC

USB from

Keyboard and mouse

Audio from

Microphone

Audio to

Speaker

Network cable CAT5e/6 up to 150m/492ft

matrixline

RS232

matrixline

RS232

DVI to Monitor

Quick Installation MX2000 MATRIXLINE local / CPU – remote / CON

1. Connect the CON / Remote and the CPU / Local Unit to the included 12V 1A power supply.

2. Now connect the USB cable to a USB port on your PC and connect the other end of the USB cable to the CPU /

Local Unit. Connect keyboard and mouse to the CON / Remote Unit.

3. Connect the CPU / Local and the CON / Remote Unit with a network cable.

4. Now connect the DVI cable to the DVI socket of the PC and the other end to the DVI socket of the CPU Local

Unit (PC-in). Then connect the monitor with the DVI cable to the CON / Remote Unit.

5. Then connect PC audio/out with the audio cable to Local audio/in. Then connect audio/out via the audio cable

6. Almost done! Now connect the audio cable Local audio/out to the PC audio/in and Remote audio/out with the

audio cable to the microphone

HAVE FUN - your kvm-tec Extender is now in use for many years (MTBF approx 10 years)
