KV2 Audio VHD5000 Manuel utilisateur
User Guide
VHD5000 GUI
Touchscreen Control,
Web Control
This User Guide shows how to Control the VHD5 system using
the VHD5000 amplier Touchscreen control system, and/or Web
control using a web browser.
Contents
VHD5000 GUI · Contents
VHD5000 GUI
Introduction 2
Touchscreen Control System 3
Amplier Settings 4 - 9
Flybar 10
Diagnostics 11
Generator 12
Ethernet 13
Basic controls · Keyboard window 14
Bottom menu 15 - 17
K-NET 18 - 22
VHD5000 GUI · Web Control 23
Remote Control System 24 - 26
Settings 27 - 32
Preset 33
Diagnostics 34
Network 35
Keyboard 36
Ethernet 37
Device Setup 38 - 39
K-NET 40 - 41
Notes 42 - 44
VHD5000 GUI · Introduction
This page has a side menu (A) and a bottom menu (B).
To navigate in the application you can use the touch screen or the encoder. Turn the encoder left or right to focus,
(C) - focused button) and then press the encoder to select the button (D) - selected button) or to produce a specic
action depending on the button type, (which will be explained below).
VHD5000 Introduction
On the front panel of the VHD5000 amplier is a 3.7"Color Transreective LCD touch display, a standby button
and a rotary encoder with a push-button function for controlling the system. After powering on, the VHD5000 will
display the KV2 logo until it has completed booting up.
Once the amp has booted, it will then change to the system overview screen. (Pic 1)
Pic 1
Pic 2
B
D
2
VHD5000 GUI · Introduction
A
C
VHD5000 GUI · Touchscreen Control System
Touchscreen Control System
Use the side menu to switch between the four main tabs.
Pic 3: LIST - System settings overview Pic 4: SET - Amplier settings, ybar control
Pic 5: DIA - diagnostics, signal generator, software version Pic 6: NET - network connection
(A) Home
(B) "AMP" - device setup
(C) PRESET - presets management
(D) K-NET - remote control of ampliers and group management
The bottom menu of the overview page contains four button options (see page 17):
Pic 7
A B C D
3
VHD5000 GUI · Touchscreen Control Systems
VHD5000 GUI · Amplier Settings
Amplier Settings
Setting
The LIST tab provides a view of the whole amplier setup. Each amplier channel has a box with its settings.
On Pic 8 you can see the system default values. Pic 9 shows a custom user setting. Muted channels are
shown with a red line through the band, and the text is grayed out.
wSUB-INT/EXT = Internal or external sub input, LD EQ = long distance equalizer for HF band.
When cardioid SUB mode is set, there is only one row for the SUBS - SUB CARDIOID
This screen also shows all of the other system settings; PHASE, GAIN, INPUT IMPEDANCE, SYSTEM DELAY, etc.
The SIGNAL METER (Pic 3) shows input level from -21 to +9dB with a 1sec peak as well as the SIGnal and LIMiter
indicators. The SIGNAL METER is included in the LIST, SETting and DIAgnostic tabs.
In the SETting tab (Pic 11) you can manage the amplier settings.
INPUT, LOW, MID, HI, SUB A, SUB B (or one button for SUB CARDIOID) and FILL buttons represent individual channels.
Press the channel button to open a window showing the advanced settings (except the MID channel which can only
be muted. This is because the MID band is treated as the baseline for the system and the other bands are gained
against the MIDS). Press and hold the channel button to mute or unmute each channel. A Red cross-hatch indicates
that the channel is muted (Pic 12). The LOW and HI bands have A and B channels which can be muted in the advanced
settings window. The MUTE button opens a window where you can mute output channels or unmute all channels.
The RESET button opens a window where you can conrm if you want to reset amplier settings to default. The Button
for controlling the FLYBAR is enabled when the VHD5.0 speaker multi-cable & ybar POWER UNIT is connected.
Pic 8 Pic 9
Pic 11 Pic 12
Pic 10
4
VHD5000 GUI · Amplier Settings
VHD5000 GUI · Amplier Settings
Input
Press the INPUT button to open the advanced settings window (Pic 13)
Press X, or touch anywhere outside the window (gray zone) to close the window.
Specication table
UNMUTE/MUTE
LEVEL: -20, -19, -18, -17, -16, -15, -14, -13, -12, -11, -10, -9, -8.5,
-8, -7.5, -7, -6.5, -6, -5.5, -5, -4.5, -4, -3.5, -3, -2.5, -2, -1.5, -1, -0.5,
0, 0.5, 1, 1.5, 2, 2.5, 3 dB
PHASE: 0°, 180°
IMPEDANCE: 120Ω, 10kΩ
FULL RANGE: ON/OFF
SUB INPUT: INTERNAL, EXTERNAL
CARDIOID: ON/OFF
INSERT: ON/OFF
enabled if SUB INPUT: INTERNAL DELAY - TIME: 0 - 379ms,
0.05ms step;
DISTANCE: 0 - 130m, cca 0.02m step
Buttons description:
UNMUTE/MUTE
Press to toggle
Enabled button
Toggle buttons:
Disabled button
Focused button
When using the encoder to navigate in the interface,
the focused button is highlighted in a white box. Use
the touch screen, or press encoder to select function.
Selected button
(See Specications Table above for step
values).
When the eld is selected, you can rotate
encoder to change its value. Rotate clockwise
to increase, and counter-clockwise to decrease
value.
Pic 13
PHASE button
Press to toggle
Pic 14 Pic 15
Pic 16 Pic 17
Pic 18
Pic 19
Pic 20
Pic 21
Pic 22
5
VHD5000 GUI · Amplier Settings
VHD5000 GUI · Amplier Settings
Delay Setting
Pic 23: Delay (TIME DISTANCE box) can be set in meters or milliseconds.
Pic 24: Touch box or use encoder to focus on the rst number.
Pic 25: Focus on specic range using encoder.
Pic 26: Press encoder to select range.
Pic 27: Rotate encoder to set value. This will change the value in 0.05ms steps which is approximately 0.02m.
For that reason, when setting meters, it adds or subtracts approximately 0.02, 0.1, 1, 10, or 100 meters depending
on the selected range.
Pic 28: When the maximum allowable delay is reached, MAX will appear at the top of the display
6
VHD5000 GUI · Amplier Settings
VHD5000 GUI · Amplier Settings
Hi
UNMUTE/MUTE
LEVEL: -6, -5, -4, -3, -2, -1, 0, 1, 2, 3, 4 dB
A: UNMUTE/MUTE
B: UNMUTE/MUTE
HF RECOVERY: ON/OFF
GAIN: -60, -57, -54, -51, -48, -45, -42, -39, -36, -34, -32, -30,
-28, -26, -24, -22, -20, -18, -16, -14, -12, -11, -10, -9, -8, -7, -6,
-5, -4, -3, -2, -1, 0 dB
If HF RECOVERY is enabled:
HI-PASS FILTER: 7.2, 3.3, 2.2, 1.5kHz
GAIN
LONG DISTANCE EQ: ON/OFF
This setting increases gain to increase long throw
characteristics of HF in larger venues.
UNMUTE/MUTE
LEVEL: -6, -4, -2, -1, 0, 1, 2, 3, 4, 5, 6 dB
A: UNMUTE/MUTE
B: UNMUTE/MUTE
LOW MID MODULE COUNT: 1, 2, 3 VHD8.10
You can individually mute the A or B channels when
a VHD5000S is connected. Otherwise these two buttons are
disabled.
LOW MID MODULES COUNT
This function is used to tell the controller how many
VHD8.10 are connected to the system.
A drop down list is displayed where you can select how
many VHD8.10 cabinets are being deployed in the system
using the touch screen or with the push button function of
the encoder.
Low
Pic 29
Pic 30
Pic 30
7
VHD5000 GUI · Amplier Settings
VHD5000 GUI · Amplier Settings
Sub A, B
Sub Cardioid
Fill
UNMUTE/MUTE
LEVEL: -20, -18, -16, -14, -12, -10, -8, -6, -4, -2, -1, 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, 10 dB
PHASE: 0°, 180°
DELAY - TIME: 0 - 109.2ms, 0.05ms step;
DISTANCE: 0 - 37.46m, cca 0.02m steps
FULLRANGE label is visible when LOW FULLRANGE
is selected to ON
UNMUTE/MUTE
LEVEL: -20, -18, -16, -14, -12, -10, -8, -6, -4, -2, -1, 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, 10 dB
PHASE: 0°, 180°
PREQUENCY: 35, 40, 45, 50, 55, 60, 65, 70, 75 Hz
DELAY - TIME: 0 -102.1ms, 0.05ms step;
DISTANCE: 0 - 35.2m, cca 0.02m steps
Set sub channels mode in input window
UNMUTE/MUTE
LEVEL: -54, -51, -48, -45, -42, -39, -36, -33, -30, -28, -26, -24,
-22, -20, -18, -16, -14, -12, -10, -8, -6, -5, -4, -3, -2, -1, 0, 1, 2, 3,
4, 5, 6 dB
PHASE: 0°, 180°
HI-PASS FILTER: 800Hz, 400Hz, 100Hz,
OFF DELAY - TIME: 0 - 379ms, 0.05ms step;
DISTANCE: 0 - 130m, cca 0.02m step
Pic 31
Pic 32
Pic 33
8
VHD5000 GUI · Amplier Settings
