Kuppersbusch KSG882 Manuel utilisateur

Instruction Manual

Bedienungsanleitung

Notice d'Utilisation

KSG882

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future references.

This manual

• Will help you use your appliance in a fast and safe way.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

This product bears the selective sorting symbol for waste electrical and

electronic equipment (WEEE).

This means that this product must be handled pursuant to European Directive

2002/96/EC in order to be recycled or dismantled to minimise its impact on

the environment. For further information, please contact your local or regional

authorities.

Electronic products not included in the selective sorting process are potentially

dangerous for the environment and human health due to the presence of

hazardous substances.

Recycling

2EN

CONTENTS

1 Your refrigerator 3

2 Important Safety

Warnings 4

Intended use .....................................4

General safety ...................................4

Child safety........................................6

HCA Warning ....................................7

Things to be done for energy saving ..7

3 Installation 8

Points to be considered when re-

transporting your refrigerator .............8

Before operating your refrigerator ......8

Disposing of the packaging ...............9

Disposing of your old refrigerator .......9

Placing and Installation ......................9

Replacing the interior light bulb .......10

Reversing the freezer door...............11

4 Preparation 12

5 Using your refrigerator 13

Thermostat setting button................13

Cooling............................................14

Freezing...........................................14

Defrost ............................................14

Stopping your product.....................15

6 Maintenance and

cleaning 16

Protection of plastic surfaces ..........16

7 Recommended solutions

for the problems 17

C Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1. Dairy compartment

2. Egg tray (1 pcs.)

3. Door shelves

4. Bottle shelf

5. Bottle gripper

6. Air grill

7. Crisper

8. Crisper cover

9. Defrost water collection

channel - Drain tube

10. Movable shelves

11. Interior light & Thermostat knob

12. a.) Freezing compartment & ice

tray (for models)

13. b.) Frozen food compartment &

ice tray (for models)

1Your refrigerator

4EN

Please review the following

information. If these are not followed,

personal injury or material damage

may occur. Otherwise, all warranty and

reliability commitments will become

invalid.

The usage life of the unit you

purchased is 10 years. This is the period

for keeping the spare parts required for

the unit to operate as described.

Intended use

• This product is designed for domestic

use.

• It should not be used outdoors. It is

not appropriate to use it outdoor even

if the place is covered with a roof.

General safety

• When you want to dispose/scrap

the product, we recommend you to

consult the authorized service in order

to learn the required information and

authorized bodies.

• Consult your authorized service for

all your questions and problems

related to the refrigerator. Do not

intervene or let someone intervene to

the refrigerator without notifying the

authorized services.

• Do not eat cone ice cream and ice

cubes immediately after you take

them out of the freezer compartment!

(This may cause frostbite in your

mouth.)

• Do not put bottled and canned

liquid beverages in the freezer

compartment. Otherwise, these may

burst.

• Do not touch frozen food by hand;

they may stick to your hand.

• Vapor and vaporized cleaning

materials should never be used in

cleaning and defrosting processes of

your refrigerator. In such cases, the

vapor might get in contact with the

electrical parts and cause short circuit

or electric shock.

• Never use the parts on your

refrigerator such as the door as a

means of support or step.

• Do not use electrical devices inside

the refrigerator.

• Do not damage the cooling circuit,

where the refrigerant is circulating,

with drilling or cutting tools. The

refrigerant that might blow out when

the gas channels of the evaporator,

pipe extensions or surface coatings

are punctured may cause skin

irritations and eye injuries.

• Do not cover or block the ventilation

holes on your refrigerator with any

material.

• Repairs of the electrical appliances

must only be made by qualified

persons. Repairs performed by

incompetent persons may create a

risk for the user.

• In case of any failure or during

a maintenance or repair work,

disconnect your refrigerator’s mains

supply by either turning off the

relevant fuse or unplugging your

appliance.

• Do not pull by the cable when pulling

off the plug.

2Important Safety Warnings

• Place the beverage with higher proofs

tightly closed and vertically.

• Flammable items or products that

contain flammable gases (e.g. spray)

as well as the explosive materials

should never be kept in the appliance.

• Do not use mechanical devices

or other means to accelerate the

defrosting process, others than those

recommended by the manufacturer.

• This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

• Do not operate a damaged

refrigerator. Consult your service if you

have any doubts.

• Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

• Exposing the product to rain, snow,

sun and wind is dangerous with

respect to electrical safety.

• Contact the authorized service when

there is a power cable damage and

etc. so that it will not create a danger

for you.

• Never plug the refrigerator into

the wall outlet during installation.

Otherwise, risk of death or serious

injury may arise.

• This refrigerator is designed solely for

storing food. It should not be used for

any other purposes.

• The label that describes the technical

specification of the product is located

on the inner left part of the refrigerator.

• Do not hook up the refrigerator to

electronic energy saving systems as it

may damage the product.

• If the refrigerator has blue light do not

look at the blue light through optical

devices.

• If the power supply is disconnected

in manually controlled refrigerators

please wait for at least 5 minutes

before reconnecting the power.

• This product manual should be

passed to the next owner of the

refrigerator if the owner changes.

• When moving the refrigerator make

sure that you do not damage the

power cord. In order to prevent

fire the power cord should not be

twisted. Heavy objects should not

be placed on the power cord. When

the refrigerator is being plugged do

not handle the power outlet with wet

hands.

• Do not plug the refrigerator if the

electric outlet is loose.

• Do not splash water directly on the

outer or inner parts of the refrigerator

due to safety.

• Do not spray inflammable materials

such as propane gas etc near

refrigerator due to the risk of fire and

explosion.

6EN

• Do not place objects filled with water

on top of the refrigerator as it may

result in electric shock or fire.

• Do not overload the refrigerator with

excess food. The excess food may

fall when the door is opened resulting

in injuring you or damaging the

refrigerator. Do not place objects on

top of the refrigerator as the objects

may fall when opening or closing the

refrigerator door.

• Materials that require certain

temperature conditions such as

vaccine, temperature sensitive

medicines, scientific materials etc

should not be kept in refrigerator.

• If refrigerator will not be operated for

an extended period of time it should

be unplugged. A problem in electrical

cable insulation may result in fire.

• The tip of the electric plug should be

cleaned regularly otherwise it may

cause fire.

• The refrigerator may move when the

adjustable feet is not positioned firmly

on the floor. Using the adjustable feet

you can unsure that the refrigerator is

positioned firmly on the floor.

• If the refrigerator has door handle

do not pull the refrigerator via door

handles when moving the product as

it may disconnect the handle from the

refrigerator.

• If you must operate your appliance

adjacent to another refrigerator or

freezer, the distance between the

appliances must be at least 8 cm.

Otherwise condensation may occur

on the side walls facing each other.

• Water mains pressure must not be

below 1 bar. Water mains pressure

must not be above 8 bars.

• Use only drinkable potable water.

Child safety

• If the door has a lock, the key should

be kept away from reach of children.

• Children should be supervised to

ensure that they do not play with the

appliance

HCA Warning

If your product is equipped with

a cooling system that contains

R600a:

This gas is flammable. Therefore, pay

attention to not damaging the cooling

system and piping during usage and

transportation. In the event of damage,

keep your product away from potential

fire sources that can cause the product

catch a fire and ventilate the room in

which the unit is placed.

Ignore the warning if your product

is equipped with a cooling system

that contains R134a.

You can see the gas used in production

of your product on the rating plate that

is located on the left inner part of it.

Never dispose the product in fire.

Things to be done for energy

saving

• Do not leave the doors of your

refrigerator open for a long time.

• Do not put hot food or drinks in your

refrigerator.

• Do not overload your refrigerator so

that the air circulation inside of it is not

prevented.

• Do not install your refrigerator

under direct sunlight or near heat

emitting appliances such as ovens,

dishwashers or radiators.

• Pay attention to keep your food in

closed containers.

• Maximum amount of food can be

put in your refrigerator’s freezer

compartment when the freezer

compartment shelf or drawer

is removed.Declared energy

consumption value of your refrigerator

was determined when the freezer

compartment shelf or drawer was

removed and under maximum

amount of food load.There is no risk

in using a shelf or drawer according to

the shapes and sizes of the foods to

be frozen.

8EN

3Installation

BPlease remember that the

manufacturer shall not be held liable if

the information given in the instruction

manual is not observed.

Points to be considered

when re-transporting your

refrigerator

1. Your refrigerator must be emptied and

cleaned prior to any transportation.

2. Shelves, accessories, crisper and etc.

in your refrigerator must be fastened

securely by adhesive tape against any

jolt before repackaging.

3. Packaging must be tied with thick

tapes and strong ropes and the

rules of transportation printed on the

package must be followed.

Please do not forget…

Every recycled material is an

indispensable source for the nature and

for our national resources.

If you wish to contribute to recycling the

packaging materials, you can get further

information from the environmental

bodies or local authorities.

Before operating your

refrigerator

Before starting to use your refrigerator

check the following:

1. Is the interior of the refrigerator dry

and can the air circulate freely in the

rear of it?

2. Clean the interior of the refrigerator as

recommended in the “Maintenance

and cleaning” section.

3. Plug the refrigerator into the wall

outlet. When the fridge door is open

the fridge compartment interior light

will come on.

4. You will hear a noise as the

compressor starts up. The liquid and

gases sealed within the refrigeration

system may also give rise to noise,

even if the compressor is not running

and this is quite normal.

5. Front edges of the refrigerator may

feel warm. This is normal. These areas

are designed to be warm to avoid

condensation.

Electric connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

• The connection must be in

compliance with national regulations.

• The power cable plug must be easily

accessible after installation.

• The specified voltage must be equal

to your mains voltage.

• Extension cables and multiway plugs

must not be used for connection.

BA damaged power cable must be

replaced by a qualified electrician.

BProduct must not be operated before

it is repaired! There is danger of

electric shock!

Disposing of the packaging

The packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose them of by

classifying them in accordance

with the waste instructions. Do not

dispose them of along with the normal

household waste.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old machine without

giving any harm to the environment.

• You may consult your authorized

dealer or waste collection center of

your municipality about the disposal of

your refrigerator.

Before disposing of your refrigerator,

cut out the electric plug and, if there

are any locks on the door, make them

inoperable in order to protect children

against any danger.

Placing and Installation

AIf the entrance door of the room

where the refrigerator will be installed is

not wide enough for the refrigerator to

pass through, than call the authorized

service to have them remove the doors

of your refrigerator and pass it sideways

through the door.

1. Install your refrigerator to a place

that allows ease of use.

2. Keep your refrigerator away from

heat sources, humid places and direct

sunlight.

3. There must be appropriate air

ventilation around your refrigerator in

order to achieve an efficient operation.

If the refrigerator is to be placed in

a recess in the wall, there must be at

least 5 cm distance with the ceiling and

at least 5 cm with the wall.

If the floor is covered with a carpet,

your product must be elevated 2.5 cm

from the floor.

4. Place your refrigerator on an even

floor surface to prevent jolts.

5. Do not keep your refrigerator in

ambient temperatures under 10°C.

Table des matières

Autres manuels Kuppersbusch Réfrigérateur

Kuppersbusch

Kuppersbusch IKE 2380-1 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE248-7 Manuel utilisateur

Kuppersbusch

Kuppersbusch KS 882 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE 318-4-2T Manuel utilisateur

Kuppersbusch

Kuppersbusch IKEF2380-0 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE 328-4-2T Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE1660-2 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE2360-1 Manuel utilisateur

Kuppersbusch

Kuppersbusch KE 360-1-2T Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE2460-1 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE 188-4 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE 188-5 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE1660-1 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE 179-5 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE2460-2 Manuel d'utilisation

Kuppersbusch

Kuppersbusch ? ???KE9600-0-2T Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE3260-1-2T Manuel utilisateur

Kuppersbusch

Kuppersbusch KEL 580 series Manuel utilisateur

Kuppersbusch

Kuppersbusch EKWL 1220Z2 Manuel utilisateur

Kuppersbusch

Kuppersbusch ITE 109 series Manuel utilisateur

Kuppersbusch

Kuppersbusch FKGF8800 0i Series Manuel d'utilisation

Kuppersbusch

Kuppersbusch IKE 157-6 Manuel utilisateur

Kuppersbusch

Kuppersbusch IKE328022T Manuel utilisateur

Kuppersbusch

Kuppersbusch FKF8800.0i Manuel d'utilisation

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
