KSF BD400 Manuel utilisateur

MATERIAL LIFTER

INSTRUCTION BOOK

MODEL : BD400

SAFETY

To operate this machine safely, this

INSTRUCTION BOOK must be read

and understood BEFORE operating

this machine.

Important

Read, understand and obey these safety rules and

operating instructions before operating this machine.

Only trained and authorized personnel shall be

permitted to operate this machine. If you have any

questions, call Kou Sheng Feng O., LTD.

INDEX

-----------------------------------------------------------------------------------

1. Safety Rules - 2 -

2. Specifications - 7 -

3. Optional Accessories - 8 -

4. Products feature - 9 -

5. Overall Dimensions - 10 -

6. Assembly Instructions-Option A /

Option B - 15 -

6. Assembly Instruction - 25 -

7. Inspecting the machine before

starting - 28 -

8. Function Tests - 29 -

9. Disassemble - 31 -

10. Transport Instructions - 32 -

11. Responsibility Statement - 33 -

12. Explosion View - 34 -

-2-

1. Safety Rules

------------------------------------------------------------------

Important

It is of paramount importance that these

instructions have been read and

understood before operating this machine.

Only authorized and trained personnel

should operate this machine.

This manual must be placed in an easily

accessible location for authorized

operators to use as required. Failure to

obey the instructions and safety rules in

this INSTRUCTION BOOK may result in

death or serious injury.

------------------------------------------------------------------

A. Do Not Operate Unless

•

Instructions have been read and understood

•

Machine is in a fixed position on even terrain

•

Machine has been checked for any faults

•

Accessories have been installed correctly

•

Machine has all necessary parts present and

only official parts from the manufacturer are

installed.

As well as this, users must ensure that:

•The machine is stored properly

•

The machine is checked regularly

•

Repairs to the machine are only made by a

qualified service technician. At the completion of

these repairs, the operator must perform a

pe-

operation inspection before using.

- 3 -

Instructions have been read and understood

Machine is in a fixed position on even terrain

Machine has been checked for any faults

Accessories have been installed correctly

Machine has all necessary parts present and

only official parts from the manufacturer are

As well as this, users must ensure that:

The machine is checked regularly

Repairs to the machine are only made by a

qualified service technician. At the completion of

these repairs, the operator must perform a

operation inspection before using.

B. Qualified personnel

Only qualified personnel are allowed to install

and operate this equipment. Qualified personnel

are authorized to move, install and operate the

machinery in accordance with safe practice and

this INSTRU TION BOOK.

familiar with this machine and capable of

operating it properly and m

trained.

C. Correct usage

This equipment can only be used within the

constraints described in this INSTRU TION BOOK.

This machine must be operated correctly and

safely under careful and correct operation and

maintenance.

B. Qualified personnel

Only qualified personnel are allowed to install

and operate this equipment. Qualified personnel

are authorized to move, install and operate the

machinery in accordance with safe practice and

this INSTRU TION BOOK.

– Operators must be

familiar with this machine and capable of

operating it properly and m

ust be correctly

This equipment can only be used within the

constraints described in this INSTRU TION BOOK.

This machine must be operated correctly and

safely under careful and correct operation and

D. Fall Hazards

1. Do not exceed the rated load capacity. The maximum

capacity is 250kgs. Ensure the load is centered on the

platform.

2. Do not use to lift persons.

3. Do not stand or sit on the load platform.

4. Do not climb on the machine.

5. Tip Over Hazards – Due to

the weight of the BD400

and possible additional weight the operator has added,

it can be unstable. Precautions must be used to avoid

unsteadiness in the machine.

- 4 -

1. Do not exceed the rated load capacity. The maximum

capacity is 250kgs. Ensure the load is centered on the

3. Do not stand or sit on the load platform.

the weight of the BD400

and possible additional weight the operator has added,

it can be unstable. Precautions must be used to avoid

E. Tip-

over Hazards

1. Do not move the machine if it contains a raised

or is on a slope.

2. Do not tilt the machine back with a raised load.

3. Do not use blocks to level the machine.

4. Do not raise the load unless the legs have been fully

locked.

5. Do not place ladders or scaffolding against any part

of the machine.

. Do not replace machine parts critical to stability or

structure with items of different weight or specification.

Only official parts are to be used on the machine at all

time

7. Do not introduce a horizontal force or side load to

the machine by raising o

r lowering a fixed or

overhanging load.

8. Do not use the machine on a moving or mobile

surface or vehicle.

9. Do not operate the machine in strong or gusty winds.

10. MAKE SURE the area is level when raising a load.

over Hazards

1. Do not move the machine if it contains a raised

load

2. Do not tilt the machine back with a raised load.

3. Do not use blocks to level the machine.

4. Do not raise the load unless the legs have been fully

5. Do not place ladders or scaffolding against any part

. Do not replace machine parts critical to stability or

structure with items of different weight or specification.

Only official parts are to be used on the machine at all

7. Do not introduce a horizontal force or side load to

r lowering a fixed or

8. Do not use the machine on a moving or mobile

9. Do not operate the machine in strong or gusty winds.

10. MAKE SURE the area is level when raising a load.

F. Collision Hazards

1. Do not rise a

load unless the load is properly

centered on the load platform.

2. Use common sense and planning when

transporting the machine on an incline, slope or

stairs.

3. Do not move the machine when the load is

raised.

4. Once the machine has been positioned and

load has been raised safely, ensure:

•

The area below the lifter is clear of any

personnel and/or obstructions.

•

Ensure any mobile objects nearby do not pose

any threat of interference with the lifter.

•

The area in which the load will be raised is cl

of any obstructions.

- 5 -

load unless the load is properly

2. Use common sense and planning when

transporting the machine on an incline, slope or

3. Do not move the machine when the load is

4. Once the machine has been positioned and

the

load has been raised safely, ensure:

The area below the lifter is clear of any

Ensure any mobile objects nearby do not pose

any threat of interference with the lifter.

The area in which the load will be raised is cl

ear

G. Lifting Hazard

Use proper lifting techniques when loading or

moving the machine.

Improper Use Hazard

Never leave a machine unattended with a load.

Unauthorized personnel may attempt to operate

the machine without proper instruction, violating

safety precautions

and creating an unsafe

environment.

Use proper lifting techniques when loading or

moving the machine.

Improper Use Hazard

Never leave a machine unattended with a load.

Unauthorized personnel may attempt to operate

the machine without proper instruction, violating

and creating an unsafe

- 6 -

------------------------------------------------------------------

I. Bodily Harm

1. Do not touch the steel wire.

2. Do not allow the platform to drop during setup.

3. Keep hands and fingers away from folding legs,

pulleys, the carriage and other potential pinching

points.

4. Do not place arms, hands or fingers through the

frame.

------------------------------------------------------------------

- 7 -

2. Specifications

Spec / Model BD400

Lifting Height 415 cm

Basic Height 130 cm

Max. Load capacity 250 kg, 3 m

250 kg, 4 m

Machine Weight ( without

accessories )

100kg

Package size 138 X 81 X 88cm

- 8 -

3. Optional Accessories

Hook & Jib (Accessory)

Weight :5.1kg/set

Capacity: 250 kg (551 lb)

Fork (Accessory)

Weight: 8.0kg/set

Capacity: 250 kg (551 lb)

Pipe Cradle (Accessory)

Weight: 9.3kg/set

Capacity: 180 kg (396 lbs )

2 Vacuum cups Hanging Crane

(Accessory)

Weight: 17.7kg/set

Capacity: 90 kg (198lbs )

- 9 -

4. Products feature

he BD400 is perfect for lifting

heavy loads, with a maximum

load capacity of up to 250kg with

Fork, lifting from ground level to

4163mm.

The BD400 is a multi-purpose

lifting device with a range of

accessories, including the pipe

cradle, fork or hook jib, that can

be used anywhere where

traditional bending, transporting

and lifting is required.

It offers a safer working

environment and a reduction in

potential muscle strain such as

back.

The BD400 offers

1 Aluminum lifting rails; compact

and very strong.

2. Universal lift and multipurpose

abilities thanks to the variety of

accessories that can be used

for beam installation, shutters,

blinds, air conditioners etc.

3. Compact and removable

construction for easy transport in

vehicles and storage in a

workshop

4. Virtually immediate use once out

of the vehicle.
