Krups XP320050 Manuel utilisateur

XP3200 www.krups.com

www.krups.com

8000828507-02

EN . . . . . . . . . . . . . . . . . p.5

FR . . . . . . . . . . . . . . . p. 23

ES . . . . . . . . . . . . . . . p. 41

Réalisation : Espace Graphique

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:42 PageC1

Fig.1 Fig.2 Fig.3

Fig.4 Fig.5 Fig.6

Fig.7 Fig.8 Fig.9

Fig.10 Fig.11 Fig.12

Fig.13 Fig.14 Fig.15

Fig.16 Fig.17 Fig.18

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:42 PageC4

English

TABLE OF CONTENTS

1. DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 9

2. TECHNICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . p. 9

3. TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 10

4. BEFORE FIRST USE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 10

5. MAKING AN ESPRESSO. . . . . . . . . . . . . . . . . . . . . . . . . p. 11

6. MILK FROTHING FUNCTION . . . . . . . . . . . . . . . . . . . . . p. 12

7. CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . p. 14

8. DESCALING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 15

9. PROBLEMS, PROBABLE CAUSES

AND CORRECTIVE ACTIONS. . . . . . . . . . . . . . . . . . . . . p. 16

10. DISPOSING OF YOUR MACHINE. . . . . . . . . . . . . . . . p. 19

11. KRUPS MANUFACTURER WARRANTY . . . . . . . . . . . p. 20

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page5

English

IMPORTANT

SAFEGUARDS

When using electrical appliances, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock, and/or injury to persons including the following :

1. Read all instructions prior to first use.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against fire, electric shock and injury to

persons, do not immerse cord, plugs or machine in water

or other liquid.

4. Not intented for use by children.

5. Close supervision is necessary when any machine is used

near children. Keep machine out of reach of children.

6. This appliance is not designed to be used by people

(including children) without prior knowledge or experience

with the machine, unless they are supervised or given prior

instructions concerning the use of the appliance by

someone responsible for their safety.

7. Children must be supervised to ensure that they do not

play with the appliance.

8. Burns can occur from touching the hot plate, hot water or

steam. Exercise caution.

9. Exercise caution when using the steam nozzle as steam

can cause scalding.

10. Unplug machine from outlet when not in use and when

cleaning. Allow to cool before putting on or taking off

parts, before cleaning the machine, and before storing.

11. All machines are subject to stringent quality control.

Practical tests using machines taken at random are

conducted and this may explain any slight marks or coffee

residue prior to use.

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page6

English

12. Do not operate any machine with a damaged cord or plug

or after the machine malfunctions, or has been damaged

in any manner. Return machine to the nearest Krups

Service Center for examination, repair or adjustment or

your respective countries Consumer Service Department.

13. To reduce the risk of injury do not drape cord over the

counter top or table top where it can be pulled on by

children or tripped over accidentally.

14. Do not let cord hang over edge of table or counter, or

touch hot surfaces.

15. The use of accessory attachments not recommended by

Krups may result in fire, electric shock or injury to persons.

16. Do not use outdoors.

17. Do not place on or near a hot gas or electric burner, or in

a heated oven.

18. To disconnect the machine, turn the control to “off” then

remove plug from wall outlet. Do not yank cord, instead

grasp plug and pull to disconnect.

19. Do not use the machine for other than intended use.

20. Do not pour liquids other than water and descaling

solutions specified in this manual into the water tank.

21. Protect the machine against humidity and freezing.

22. This machine is for household use only.

SAVE THESE

INSTRUCTIONS

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page7

English

CAUTION

This machine is intended for household use only. Any servicing

other than cleaning and user maintenance should be

performed by the nearest authorized Krups Service Center.

Visit our website at www.krupsusa.com in the USA or

www.krups.ca in Canada or contact your respective country's

Consumer Service department for the service center nearest to

you, or contact your respective country’s Consumer Service

department.

To reduce the risk of fire or electric shock, do not attempt to

disassemble the machine. Repair should be done by an

authorized Krups Service Center only.

SHORT CORD INSTRUCTIONS

A. We do not recommend using an extension cord with

this device.

B. If an extension cord is absolutely necessary,

1) the marked electrical rating of the extension cord

should be at least as great as the electrical rating

of the machine,

2) the longer cord should be arranged so that it will

not drape over the counter top or table top where

it can be pulled on by children or tripped over.

C. This machine has a polarized plug (one blade is

wider than the other). To reduce the risk of electric

shock, this plug is intended to fit into a polarized

outlet only one way. If the plug does not fit fully into

the outlet, reverse the plug. If it still does not fit,

contact a qualified electrician. Do not attempt to

modify the plug in any way.

In the interest of improving products, Krups reserves the

right to change specifications without prior notice.

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page8

English

1. DESCRIPTION

2. TECHNICAL CHARACTERISTICS

nPump: 15 bars

nFilter holder 1 cup, 2 cups.

nSteam function

nRemovable water tank (capacity: 0,8 litres)

nPower: 1250 W

nVoltage:120 V – 60 Hz

nAnti overheating safety mechanisms

nDimensions: H 11.2 in., L 8.1 in., W 15.9 in.

IMPORTANT!

Operating voltage: This device is designed to work only at

alternating current 120V.

Type of use: This machine is designed EXCLUSIVELY for

household use only. Any non-residential use including

commercial purposes will void the warranty.

a. Water compartment lid

b. Detachable water compartment

c. Filter storage

c1. Filter for ground coffee

(1 cup) and soft pod.

c2. Filter for ground coffee

(2 cups)

d. Measuring spoon

e. Cup tray

f. On/off switch

g. On / off indicator light (red)

h. Coffee function switch

h1. Espresso reheating

position

h2. Espresso position

h3. Coffee indicator light

(green)

i. Steam function selector switch

i1. Position O

i2. Steam reheating

position

i3. Steam position

i4. Steam indicator light

(green)

j. Filter holder

k. Steam nozzle

l. Drip tray grid

m. Drip tray

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page9

English

3. TIPS

nTo extract the fullest flavor from your beans, we recommend using

whole coffee beans that have been freshly ground each time espresso

is prepared. Take care to make sure your coffee is ground to the proper

size for espresso. Too fine a grind will result in espresso that is over-

extracted and bitter. Too coarse a grind will result in espresso that is

under-extracted and weak in flavor. The perfect espresso grind will feel

like fine grains that do not clump when pressed together.

nStore your espresso grounds in an airtight container, and in a cool, dry

place to retain the flavor. Grounds should not be kept for long periods

of time as the flavor will be reduced over time.

nDo not fill your filter holder to the brim. Using the measuring spoon

included, use 1 level spoon of grounds per shot of espresso.

nIf you do not use the machine for more than 5 consecutive days, rinse

and drain the water tank.

nBefore removing the water tank to fill or empty it, always turn the

machine off.

nAlways place the unit on a flat, stable, heat-resistant work surface.

nTo obtain an espresso at exactly the right temperature, we recommend

that you preheat your cups.

IMPORTANT!

Before using for the first time, after a prolonged period

of inactivity or after descaling, the machine must be

cleaned as described in Section 4: “BEFORE FIRST

USE”.

4. BEFORE USING FOR THE FIRST TIME

Before using your espresso machine for the first time, clean all the

accessories in soapy water and dry them.

Rinse them as follows:

nOpen the lid (a) and remove the water tank using the handle (fig. 1).

nFill the tank (b) with cold water and place it firmly on the machine,

making sure it is firmly in place, and close the lid (fig. 2 and 3).

nInsert and turn the filter holder to the right (fig 7).

nPlace a container of sufficient volume under the filter holder.

nPlug the appliance in and turn it on (fig. 4).

nWait for the green light to turn on (h3).

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page10

English

nTurn the Coffee function selector (h) to the position (h2) and let

all the water in the tank drain out (Fig. 5). During this first use, the

system must fill up and the water does not flow immediately.

nIf necessary, to empty the water from the container, you can interrupt

the flow by turning the coffee function selector switch (h) to the

position (h1). Once all of the water from the tank has emptied into

the container, turn the coffee function selector to the (h1) position.

5. MAKING AN ESPRESSO

IMPORTANT : Always check before starting a cycle to see

that there is sufficient water in the water tank. Avoid

allowing the tank to run dry when operating the machine.

WITH ESPRESSO GROUND COFFEE:

nFill the tank with cold water and place it firmly on the machine,

making sure it is firmly in place, (fig. 1, 2 and 3).

nPlace the filter (c.1) for 1 cup or the filter (c.2) for 2 cups in the filter

holder (j) (fig. 6).

nusing the measuring spoon (d), fill the filter with ground coffee.

(1 dose = 1 cup, 2 doses = 2 cups) in the filter. (fig 8, 9)

nRemove the coffee which remains around the filter.

nInsert and turn the filter holder to the right (fig 7).

nPlace one or two espresso cups under the filter holder.

As soon as the device reaches the required temperature, the green light

(h3) will turn on.

nTurn the coffee function selector switch (h) to the position (h2).

nWhen the cups are filled to your liking, turn the switch to the

position (h1).

nRemove the filter holder by turning it to the left .

nTo eject the spent coffee, turn the filter holder over, holding the filter

by the tab so that the spent coffee falls out (fig 11).

For the best results, we recommend that you preheat the accessories

(filter holder, filter and cups) following the steps above without using

ground coffee.

Warning! Do not remove the Filter holder when the Cof-

fee function selector switch (h) is in the position (h2),

and the coffee is flowing. 11

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page11

English

WITH SOFT PODS:

Besides coffee, this machine can also work with espresso ground cof-

fee pods.

nPlace the espresso pod in the filter (c1).

nBe sure to place all the paper inside the filter holder, to avoid

leaks and get a good result in the cup.

nInsert and turn the filter holder to the right (fig.7).

nThen follow the procedure for preparing an espresso with espresso

ground coffee.

6. MILK FROTHING FUNCTION

nSteam can be used to froth milk for cappuccinos and latte.

nAs the machine produces steam, the operating pump will make a

sound.

nAfter using the steam function, the machine purges

automatically and cools down by pumping cold water through the

heating system. During the purging cycles of cold water, the excess

steam in the heating system is released with hot water into the drip

tray.

nThe steam and noise that accompany this phase is important for

cooling the machine.

Caution: During and after using the steam wand, the

metal parts of the steam wand can become very hot.

Take care when handling the steam wand to avoid injury.

SYSTEMATIC PURGE OF THE STEAM CIRCUIT:

Each time before you make frothy milk, you must purge the steam

circuit:

nPlace an empty container under the steam nozzle (k).

nTurn the steam function selector switch (i) to the position (i2)

(fig. 12). The steam light (i4) lights up.

nTurn the steam function selector switch (i) to the position (i3)

(fig. 13) in order to purge the circuit.

nWhen all the water inside the circuit has been emitted, turn the steam

function selector switch (i) back to the to the position (i2). (fig. 12)

(i2).

IFU_KR_COFFEE_MAKER_XP3200_Mise en page 1 06/06/11 13:35 Page12

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Krups Cafetière

Krups

Krups Orchestro 889 Manuel utilisateur

Krups

Krups Nespresso Maestria XN800 Manuel utilisateur

Krups

Krups F054 Manuel utilisateur

Krups

Krups COCOON Manuel utilisateur

Krups

Krups KM600 Manuel utilisateur

Krups

Krups Nescafe Dolce Gusto Genio 2 Series Fiche technique

Krups

Krups C Z2 Manuel utilisateur

Krups

Krups Crystal Arome Plus Manuel utilisateur

Krups

Krups Nescafe Dolce Gusto Piccolo KP100B Manuel utilisateur

Krups

Krups Simply Brew KM209D50 Manuel utilisateur

Krups

Krups xp3200 Manuel utilisateur

Krups

Krups CafePresso Crematic 874 Manuel utilisateur

Krups

Krups Evidence+ EA894T Manuel utilisateur

Krups

Krups SAVOY EC414 Manuel utilisateur

Krups

Krups Espresseria Automatic EA82 Series Guide de l'utilisateur

Krups

Krups NESPRESSO MY MACHINE XN810510 Manuel utilisateur

Krups

Krups Espresso Automatic EA88 Series Manuel utilisateur

Krups

Krups Nespresso Prodigio XN410T10 Manuel utilisateur

Krups

Krups Nescafe Dolce Gusto Genio S Touch Fiche technique

Krups

Krups Espresso Novo Plus FNC1 Manuel utilisateur

Krups

Krups KM7005 Manuel utilisateur

Krups

Krups KM468950 Manuel utilisateur

Krups

Krups CONTROL KM442D50 Manuel utilisateur

Krups

Krups Evidence ECO-Design Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur

LAVAZZA

LAVAZZA CLASSY PLUS Manuel utilisateur
