USER MANUAL

Models:

VS-44AV, 4x4 Video Audio Matrix Switcher

VS-81AV, 8x1 Video/Audio-Stereo Switcher

VS-81AYC, 8x1 s-Video/Audio-Stereo Switcher

VS-81V, 8x1 Video Switcher

VS-81X, 8x1 Balanced Audio Switcher

Contents

1Introduction 1

2Getting Started 1

3Kramer Mechanical Switchers 2

3.1 Your VS-44AV 4x4 Video Audio Matrix Switcher 2

3.2 Your VS-81AV 8x1 Video/Audio-Stereo Switcher 3

3.3 Your VS-81AYC 8x1 s-Video/Audio-Stereo Switcher 4

3.4 Your VS-81V 8x1 Video Switcher 5

3.5 Your VS-81X 8x1 Balanced Audio Switcher 7

4Connecting Kramer Mechanical Switchers 8

4.1 Connecting a VS-81V 8x1 Video Switcher 8

4.2 Connecting a VS-81X Balanced Audio Switcher 9

4.3 Connecting a VS-81AV 8x1 Video/Audio-Stereo Switcher 10

Figures

Figure 1: VS-44AV 4x4 Video Audio Matrix Switcher 2

Figure 2: VS-81AV 8x1 Video/Audio-Stereo Switcher 3

Figure 3: VS-81AYC 8x1 s-Video/Audio-Stereo Switcher 5

Figure 4: VS-81V 8x1 Video Switcher 6

Figure 5: VS-81X 8x1 Balanced Audio Switcher 7

Figure 6: Connecting a VS-81V 8x1 Video Switcher 8

Figure 7: Connecting a VS-81X Balanced Audio Switcher 9

Figure 8: Connecting a VS-81AV 8x1 Video/Audio-Stereo Switcher 10

Tables

Table 1: VS-44AV Functions 2

Table 2: VS-44AV Technical Specifications 3

Table 3: VS-81AV Functions 4

Table 4: VS-81AV Technical Specifications 4

Table 5: VS-81AYC Functions 5

Table 6: VS-81AYC Technical Specifications 5

Table 7: VS-81V Functions 6

Table 8: VS-81V Technical Specifications 6

Table 9: VS-81X Functions 7

Table 10: VS-81X Technical Specifications 7

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups1

Thank you for purchasing your Kramer mechanical switcher, which is ideal

for a system in which a passive, hard-wired signal path is preferred.

that are clearly

defined by function.

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance high-resolution cables2

Each package includes the following items:

•The one or more Kramer mechanical switchers

•This user manual3

To achieve the best performance:

•Use only good quality connection cables to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables).

•Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your Kramer

switcher away from moisture, excessive sunlight and dust

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Kramer Mechanical Switchers

3 Kramer Mechanical Switchers

This user manual describes the following Kramer mechanical switchers:

•VS-44AV, 4x4 Video Audio Matrix (see section 3.1)

•VS-81AV, 8x1 Video/Audio-Stereo Switcher (see section 3.2)

•VS-81AYC, 8x1 s-Video/Audio-Stereo Switcher (see section 3.3)

•VS-81V, 8x1 Video Switcher (see section 3.4)

•VS-81X, 8x1 Balanced Audio Switcher (see section 3.5)

3.1 Your VS-44AV 4x4 Video Audio Matrix Switcher

The Kramer VS-44AV 4x4 Video Audio Matrix Switcher is a high-quality

mechanical 4x4 matrix switcher for composite video and stereo audio

signals. The VS-44AV is designed to simultaneously route up to 4 sources

each to any one of 4 available outputs. The VS-44AV is unique in allowing

4 different cross points of video and stereo audio to operate at the same

time. However, it cannot simultaneously distribute an input signal to

multiple outputs. The high-quality input selector buttons are color coded for

easy identification and unselected inputs are terminated via 75Ωresistors.

Figure 1and Table 1define the VS-44AV 4x4 Video Audio Matrix

Switcher. Table 2gives the technical specifications for the VS-44AV.

Figure 1: VS-44AV 4x4 Video Audio Matrix Switcher

Table 1: VS-44AV Functions

Feature

Function

1 OUTPUT/INPUT Selector Buttons Select the video and audio source (from A to D) to route to

each video/audio acceptor (from 1 to 4)

2 VIDEO OUTPUT BNC connectors Connect to the video acceptors (from 1 to 4)

3 AUDIO OUTPUT RCA connectors Connect to the right and left audio acceptors (from 1 to 4)

4 VIDEO INPUT BNC connectors Connect to the video sources (from A to D)

5 AUDIO INPUT RCA connectors Connect to the right and left audio sources (from A to D)

Kramer Mechanical Switchers

Table 2: VS-44AV Technical Specifications

INPUTS: 4 video, 1Vpp/75Ωon BNC connectors

4 audio stereo, 1Vpp nominal on RCA connectors

OUTPUTS: 4 video, 1Vpp/75Ωon BNC connectors

4 audio stereo, 1Vpp nominal on RCA connectors

SWITCHING SYSTEM: Mechanical, break-before-make

CROSSPOINTS: 16 for video, 16x2 for audio, 4 active at any given time

CROSSTALK: -42dB @5MHz

BANDWIDTH (-3dB): 220MHz (video), 100kHz (audio)

SIGNAL LEVELS: Up to 3Vpp video, 36Vpp audio

DIMENSIONS: 19" x 7" x 1U W, D, H rack mountable

WEIGHT: 1.6kg (3.5lbs) approx.

3.2 Your VS-81AV 8x1 Video/Audio-Stereo Switcher

The Kramer VS-81AV, 8x1 Video/Audio-Stereo Switcher is a high-quality

mechanical 8x1 switcher for composite video and stereo audio signals.

The VS-81AV is designed for applications requiring an unpowered rack-

mountable unit for routing of video and stereo audio signals. Audio is

always switched together with the corresponding video signal and

unselected video inputs are terminated via 75Ωresistors. High-quality

switching components provide excellent isolation between inputs. Its

unpowered passive design is advantageous for applications in which various

regulatory compliances would otherwise be required. The "hard-wired"

signal path offers excellent bandwidth, and can even switch other signal

formats.

Figure 2and Table 3define the VS-81AV 8x1 Video/Audio-Stereo

Switcher. Table 4gives the technical specifications for the VS-81AV.

Figure 2: VS-81AV 8x1 Video/Audio-Stereo Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Kramer Mechanical Switchers

Table 3: VS-81AV Functions

Feature

Function

1 INPUT Selector Buttons Select the video/audio source (from 1 to 8) to route to the output

2 VIDEO OUT BNC connector Connects to the video acceptor

3 AUDIO OUT RCA connectors Connect to the left and right audio acceptor

4 VIDEO input BNC connectors Connect to the video sources (from 1 to 8)

5 AUDIO input RCA connectors Connect to the left and right audio sources (from 1 to 8)

Table 4: VS-81AV Technical Specifications

INPUTS: 8 video, 1Vpp/75Ωnom. on BNC connectors

8 audio stereo, 1Vpp nom. on RCA connectors

OUTPUT: 1 video, 1Vpp/75Ωnom. on a BNC connector

1 audio stereo, 1Vpp nom. on an RCA connector

SWITCHING SYSTEM: Mechanical, break-before-make

CROSSPOINTS: 1 of 8

SIGNAL LEVELS: Up to 3Vpp video, 36Vpp audio

BANDWIDTH (-3dB): Video: 400MHz; Audio: 100kHz

DIMENSIONS: 19" x 7" x 1U W, D, H rack mountable

WEIGHT: 1.5kg (3.3lbs) approx.

3.3 Your VS-81AYC 8x1 s-Video/Audio-Stereo Switcher

The Kramer VS-81AYC, 8x1 s-Video/Audio-Stereo Switcher is a high

quality mechanical 8x1 switcher for s-Video (Y/C) and stereo audio

signals using 4-pin and RCA connectors. The VS-81AYC is designed for

applications requiring an unpowered rack mountable unit for the routing

of s-Video (Y/C) and stereo audio signals. Audio is always switched

together with the corresponding s-Video (Y/C) signal and unselected

video inputs are terminated via 75Ωresistors. High quality switching

components provide excellent isolation between inputs. Its unpowered

passive design is advantageous for applications in which various

regulatory compliances would otherwise be required. The "hard-wired"

signal path offers excellent bandwidth, and can switch other signal

formats.

Figure 3and Table 5define the VS-81AYC, 8x1 s-Video/Audio-Stereo

Switcher. Table 6gives the technical specifications for the VS-81AYC.

Kramer Mechanical Switchers

Figure 3: VS-81AYC 8x1 s-Video/Audio-Stereo Switcher

Table 5: VS-81AYC Functions

Feature

Function

1 INPUT Selector Buttons Select the s-Video/audio source (from 1 to 8) to route to the output

2 s-VIDEO OUT 4-pin connector Connects to the s-VIDEO acceptor

3 AUDIO OUT RCA connectors Connect to the left and right audio acceptor

4 s-VIDEO input 4-pin connector Connect to the s-VIDEO sources (from 1 to 8)

5 AUDIO input RCA connectors Connect to the left and right audio sources (from 1 to 8)

Table 6: VS-81AYC Technical Specifications

INPUTS: 8 s-Video, 1Vpp/75Ω(Y), 0.3 Vpp/75Ω(C) nom. on 4-pin

connectors

8 audio stereo, Vpp nom. on RCA connectors

OUTPUTS: 1 s-Video, 1Vpp/75Ω(Y), 0.3 Vpp/75Ω(C) nom on a 4-pin

connector

1 audio stereo, Vpp nom on RCA connectors

SWITCHING SYSTEM: Mechanical, break-before-make

CROSSPOINTS: 1 of 8

SIGNAL LEVELS: Up to 3Vpp video, 36Vpp audio

BANDWIDTH (-3dB): Video: 350MHz (Y); Audio: 100kHz

DIMENSIONS: 19" x 7" x 1U W, D, H rack mountable

WEIGHT: 1.4kg (3.1lbs) approx.

3.4 Your VS-81V 8x1 Video Switcher

The Kramer VS-81V, 8x1 Video Switcher is a high quality mechanical 8x1

switcher for composite video using BNC connectors. The VS-81V is

designed for applications requiring a compact desktop unit for routing

composite video signals. High quality switching components and carefully

designed circuits provide excellent isolation between inputs and unselected

inputs are terminated via 75Ωresistors. Its unpowered design is

advantageous for applications in which various regulatory compliances

would otherwise be required. The passive "hard-wired" signal path offers

very high bandwidth and can also switch other signal formats.

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Kramer Mechanical Switchers

Figure 4and Table 7define the VS-81V, 8x1 Video Switcher. Table 8gives

the technical specifications for the VS-81V.

Figure 4: VS-81V 8x1 Video Switcher

Table 7: VS-81V Functions

Feature

Function

1 INPUT Selector Buttons Select the video source (from 1 to 8) to route to the output

2 VIDEO OUTPUT BNC connector Connect to the video acceptor

3 VIDEO input BNC connectors Connect to the video sources (from 1 to 8)

Table 8: VS-81V Technical Specifications

INPUTS: 8 video, 1Vpp/75Ωnom. on BNC connectors

OUTPUTS: 1 video, 1 Vpp/75Ωnom. on a BNC connector

SWITCHING SYSTEM: Mechanical, break-before-make

CROSSPOINTS: 1 of 8

VIDEO CROSSTALK: -47dB @5MHz

BANDWIDTH (-3dB): 400 MHz

DIMENSIONS: 18.8cm x 10.2cm x 4.4cm (7.4" x 4" x 1.7") W, D, H.

WEIGHT: 0.72kg (1.6lbs) approx.

OPTIONS: RK-81 19" rack adapter

Kramer Mechanical Switchers

3.5 Your VS-81X 8x1 Balanced Audio Switcher

The Kramer VS-81X, 8x1 Balanced Audio Switcher is a high quality

mechanical 8x1 switcher for mono balanced audio using XLR connectors.

The VS-81X is designed for applications requiring a compact desktop unit

for routing audio signals. High quality switching components provide

excellent isolation between inputs. Its unpowered passive design is

advantageous for applications in which various regulatory compliances

would otherwise be required. The "hard-wired" signal path can also switch

other signal formats.

Figure 5and Table 9define the VS-81X, 8x1 Balanced Audio Switcher.

Table 10 gives the technical specifications for the VS-81X.

Figure 5: VS-81X 8x1 Balanced Audio Switcher

Table 9: VS-81X Functions

# Feature Function

1 INPUT Selector Buttons Select the audio source (from 1 to 8) to route to the output

2 AUDIO OUTPUT XLR connector Connect to the audio acceptor

3 AUDIO input XLR connectors Connect to the audio sources (from 1 to 8)

Table 10: VS-81X Technical Specifications

INPUTS: 8 balanced audio, line or mic level, on XLR connectors

OUTPUT: 1 balanced audio, line or mic level, on an XLR connector

SWITCHING SYSTEM: Mechanical, break-before-make

CROSSPOINTS: 1 of 8

SIGNAL LEVELS: Up to 36Vpp

BANDWIDTH (-3dB): 25kHz

DIMENSIONS: 25.5cm x 10.2cm x 4.5cm (10" x 4" x 1.7") W, D, H.

WEIGHT: 0.82kg (1.8lbs) approx.

OPTIONS: RK-81X 19" rack adapter

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting Kramer Mechanical Switchers

4 Connecting Kramer Mechanical Switchers

This section gives examples of how to connect Kramer mechanical

switchers.

•To connect a mechanical video switcher, see the example in section 4.1

•To connect a mechanical audio switcher, see the example in section 4.2

•To connect a mechanical audio/video switcher, see the example in

section 4.3

4.1 Connecting a VS-81V 8x1 Video Switcher

To connect your VS-81V 8x1 Video Switcher, as the example in Figure 6

illustrates:

1. Connect up to 8 composite video sources to the appropriate BNC input

connectors.

2. Connect the BNC OUTPUT connector to the composite video acceptor.

Pushing a front panel INPUT selector button routes that composite video

source to the composite video acceptor.

Figure 6: Connecting a VS-81V 8x1 Video Switcher

Autres manuels pour VS-44AV

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer VP-27 Manuel utilisateur

Kramer

Kramer VS-42HN Manuel utilisateur

Kramer

Kramer AFM-20DSP Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1616V5 Manuel utilisateur

Kramer

Kramer MV-4X Manuel utilisateur

Kramer

Kramer VS-88H Manuel utilisateur

Kramer

Kramer VS-42HN Manuel utilisateur

Kramer

Kramer Sierra Video 1204V5 Manuel utilisateur

Kramer

Kramer VS-606xl Manuel utilisateur

Kramer

Kramer ASPEN-32UFX Manuel utilisateur

Kramer

Kramer VS-88DVI Manuel utilisateur

Kramer

Kramer Sierra Video 4864V5Sxl Manuel utilisateur

Kramer

Kramer VS-6464DN-EM Manuel utilisateur

Kramer

Kramer Sierra Video 1616V3 Manuel utilisateur

Kramer

Kramer Sierra Video 3216V5S Manuel utilisateur

Kramer

Kramer VP-1608 Manuel utilisateur

Kramer

Kramer Sierra Video 1608V3S Manuel utilisateur

Kramer

Kramer VS-88UHD Manuel utilisateur

Kramer

Kramer Sierra Video 1204V3S Manuel utilisateur

Kramer

Kramer VS-44UHDA Manuel utilisateur

Kramer

Kramer VP-772T Manuel utilisateur

Kramer

Kramer VS-162AV Manuel utilisateur

Kramer

Kramer VS-48HDxl Manuel utilisateur

Kramer

Kramer VS-3232DN Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
