Kove Commuter Manuel utilisateur

COMMUTER

PORTABLE BLUETOOTH SPEAKER

WITH X-BASS SUB-WOOFER

KOVEAUDIO.COM

The Kove Commuter Portable Wireless

Bluetooth Speaker packs a lot of sound

in a compact package. A single charge

of the 4000mAH battery gets you up to 8

hours of superior sound quality thanks to

the powerful X-bass subwoofer – yes, a

subwoofer in a portable speaker! Connect

to your computer or mobile device via

Bluetooth 4.1 and feel free to walk up to 30

feet away without interrupting your music.

Before using your commuter, please read this manual

and keep is for future reference.

COMMUTER

PORTABLE BLUETOOTH SPEAKER

WITH X-BASS SUB-WOOFER

BLUETOOTH CONNECTION

Turn the Commuter on by pressing and holding the power for several seconds, the

blue LED light will pulse quickly, letting you know that the speaker is now entered

Bluetooth pairing mode.

CONNECT TO MOBILE PHONES/TABLET PCS/COMPUTERS

1. Activate your phone's Bluetooth.

2. Go to your phone's Bluetooth settings and scan for a new Bluetooth device.

3. Once the device is found (Commuter), click the device name and pair with it.

4. If your phone ask for a pairing code, please enter ”0000” and conﬁrm it.

5. After the pairing is successful, the speaker will make a prompting sound and

the LED light will turn solid blue.

BLUETOOTH SPECIFICATIONS

• Pairing time varies with different devices. The Commuter only needs to be

paired for the ﬁrst use and will auto connect to devices which have already

been paired from then on (only the last 8 paired device names)

• In Bluetooth mode, when the 3.5mm audio plug is inserted, the speaker will

switch to line in status automatically;

• Bluetooth Compatibility: It is compatible with Bluetooth 4.2 Class II and

supports A2DP V1.2, AVRCP V1.4 proﬁles agreement.

• Transmission distance: up to 10 m

AUX AUDIO-IN CONNECTOR

The Commuter also features an AUX audio in port. Connect the speaker with your

to any audio device with the 3.5mm jack audio cable. Once the orange light shows,

you will be able to play music through the wired connection.

LOW POWER INDICATION

The Commuter will beep to indicate low battery (10%). The indicator light will also

pulse orange or red. Charge the speaker as soon as possible.

CHARGING

Connect the micro USB charging cable to a computer or USB charger. You will see

a red LED light indicating that the device is charging. The light will turn green when

charging is complete, after approximately 4 to 5 hours of charging.

NFC FUNCTION

The Commuter is equipped with an NFC chip. Activate the NFC Chip using on your

phone and position the phone close to the NFC position on the speaker. Follow the

instructions on your phone to quickly connect with the Commuter via the NFC function.

Notes:

• Turn off the speaker when not in use to conserve battery power.

• Don’t try to disassemble the speaker as it may get damaged if you are not

professional.

• Don’t use intensive chemical products or detergent to clean the speaker.

• Don’t scratch the surface with sharp tips.

YOUR COMMUTER

Front Back* Left Right

MODE

OUTDOOR

INDOOR

Top Bottom

FOR BEST SOUND QUALITY, LAY THE SPEAKER ON IT'S BACK

TO EXPOSE THE SUBWOOFER.

MODE

OUTDOOR

INDOOR

Play / Pause &

Calls Handsfree

Slide Next / Previous

USB Charging

LINE IN

Power ON/OFF

Mode Change Button

(OUTDOOR / INDOOR)

Rotary Volume +/-

Power ON / OFF Press for 2 seconds to power on / off.

Volume – or + Turn clockwise to turn up the Volume and

counterclockwise to turn the Volume down.

Next / Previous

In Bluetooth mode, slide to the right to get to the

next track and to the left to get to the previous

track .

Play / Pause When playing music, press quickly to Pause /

Play.

Answering a call When a call comes in, press quickly to pick up

the call and press it again to hang up.

Refusing a call When a call comes in, quickly double tap to

refuse the call.

EQ mode Press

MODE

to select the mode to OUTDOOR or

INDOOR, the icon will illuminate accordingly.

Working Temp. Temperature: 0º C - 40º C

Humidity: 0% - 85% RH

Storage Temp Temperature: -30º C - 60º C

Humidity: 0% -90% RH

YOUR COMMUTER

SPECIFICATIONS

• Sound track: dual track

• Water Resistant: IPX4

• Signal to noise ratio S / N: ≥80dB

• Frequency Range: 68Hz-20KHz

• Distortion THD: ≤1%

• Speaker unit: outer diameter 45mm,

inner magnet, 4Ω, 12W x 2

• Audio input connector:

3.5mm

• AUX cable:

supports external audio input.

• Charging interface:

Micro USB; Input 5V

POWER

• Battery: built-in lithium battery,

4000mAh

• Charging Voltage / Current:

±0.25V / 1.5A

• Charging time: 4-5 hours

• Playing time: 6-8 hours

ACCESSORIES

• 1x Commuter Portable Speaker

• 1x User Manual

• 1x USB Charging Cable

• 1x AUX 3.5mm Audio Cable

MY MOBILE PHONE CAN'T FIND ANY NEW BLUETOOTH DEVICES.

Make sure the Bluetooth speaker has entered pairing mode; and that the speaker

is within the effective working range of your phone.

BLUETOOTH DEVICES CAN'T PAIR UP.

Make sure your mobile phone allows a new connection and has not reached the

maximum amount of connections allowed—please refer to your bluetooth device’s

user manual for more information

MY COMMUTER DOES NOT PLAY MUSIC OR ANSWER CALLS WHEN IT'S CONNECTED TO A

BLUETOOTH MOBILE PHONE.

Make sure your Bluetooth mobile phone supports A2DPand HSF (hands-free) proﬁle;

and ensure that your Bluetooth cell phone is within its effective working range.

WHEN PAIRED WITH MY COMPUTER, WINDOWS ASK FOR NEW DRIVER. DO YOU PROVIDE THIS?

We do not. The Bluetooth A2DP/HSF drivers may require playing stereo sound via

Bluetooth Connection, but the driver is actually needed for the Bluetooth module on

your PC, instead of the speaker. Different Bluetooth modules may require different

drivers. Please contact your PC or Bluetooth module’s manufacturer for a driver update.

MY CONNECTION IS NOT STABLE, IT CUTS IN AND OUT, OR THERE IS A LOT OF WHITE NOISE.

Check for nearby radio or wiﬁ interference, also check to see that there are no

objects between your Commuter and Bluetooth device that would impede the signal.

FREQUENTLY ASKED QUESTIONS

WHY CAN’T I REMOTELY CONTROL THE PAUSE, PLAY, PREVIOUS SONG AND SKIP TRACK

FUNCTIONS WITH THE SPEAKER WHEN PLAYING MUSIC?

When you are using 3.5mm AUX audio in connection, you can’t pause, change

volume or skip tracks with the buttons on the speaker; This feature needs

the Bluetooth devices paired with the speaker to support AVRCP (Audio/Video

Remote Control Proﬁle). Please make sure your Bluetooth device supports AVRCP.

I’VE CONNECTED MY DEVICE, BUT I’M NOT HEARING SOUND.

Make certain that the volume is up on both the commuter and your device. Some

smart phones require you to setup the Commuter as an audio output device

before sound is transmitted. Please see the pairing instructions on your smart

phone for details. If you are using a music player or other Bluetooth device,

please make sure it supports an A2DP/HSF stereo music proﬁle.

THERE ARE A LOT OF LIGHTS ON MY COMMUTER. WHAT DO THEY ALL MEAN?

Solid Green / Blue Your Commuter is fully charged

Flashing Red / Orange This is the low battery indicator. Your Commuter only

has 10% battery left, time to plug in.

Pulsing Blue Your Commuter is in Bluetooth Pairing Mode.

Solid Orange Your commuter is plugged into an audio source

through the auxillary port.

Solid Red The Commuter is Charging.
