Kontron CG1200 Manuel utilisateur

CG1200 Carrier Grade Server

Document Revision 1.1

Revision History

Revision

Date

Comments

0.1

12/13/2012

Initial Release

1.1

01/13/2014

Adding Intel® Xeon® processor E5-2400 v2 product

family

3 www.kontron.com

Table of Contents

I. INTRODUCTION.....................................................................................................4

II. ORDERING CG1200 SYSTEMS.............................................................................6

III. ORDERING CG1200 SERVICEABLE ITEMS.......................................................18

APPENDIX A. RACK MOUNTING OPTIONS FOR 1U AND 2U COMMUNICATIONS

RACK MOUNT SERVERS............................................................................................21

4 www.kontron.com

I. Introduction

Product Description:

The CG1200 Carrier Grade Server is the 4th generation of Kontron’s 1U Carrier Grade

Server products. The CG1200 supports Intel® Xeon® processor E5-2400 v2 product

family, coupling high performance with power efficiency to provide improved

performance-per-watt over previous-generation rack-mount servers.

The CG1200 is a NEBS-3 and ETSI compliant product which is suited for a host of

applications in the telecom Central Office and industrial environment. The server is

targeted to OSS (Operations System and Support), Billing, Provisioning, Softswitch,

Media Server, Wireless and Unified Messaging, Call Center and many other

applications. It can also support manufacturing, industrial, oil & gas, utility and even

military applications where a rugged, highly reliable server is required for harsh

environments such as dust, high altitude, fire hazard, earthquake propensity, and high

ambient temperatures.

To add to the many recognized benefits of Kontron’s Carrier Grade Server family, the

CG1200 introduces several new important features such as support of PCI-E Gen3,

Power Management Bus, DDR3 memory, SD flash storage, and increased memory

capacity.

More detailed product information on the CG1200 is available on Kontron’s website at:

http://us.kontron.com/products/systems+and+platforms/communication+rackmount+servers/carr

ier+grade+servers/cg1200+carrier+grade+server.html

Purpose of this Document:

This document serves as an ordering reference guide, providing details on what parts

are available from Kontron for the CG1200 Carrier Grade Server and its associated

accessories and spares. Included are the necessary order codes and other important

configuration information related to the ordering of the product.

Supported third-party components are not covered by this document, and may be found

in the Tested Hardware and Operating System List (THOL) for this product.

5 www.kontron.com

General Flow for Configuring a CG1200 System

Step

Implication

Reference info

A. Select Base System

AC or DC base System

B. Select Redundant

power supply

Redundant or non-redundant

Non-redundant as shipped

C. Select Number and

Type of CPUs

Impacts Performance

Technical Product Specification

C.2. Memory

DIMM slots depend on number

of CPUs

Technical Product

Specification,

Refer to Tested Memory

List for list of validated

DIMMs

Refer to Installation &

Maintenance Guide for

installation instructions

D. Heatsink

Required for each CPU

E. Select RAID

RAID Choices

RAID 0/1/10 included

Additional offerings

F. Select Hard Drives

Refer to Installation & THOL

for tested Hard Drives

G. Select Remote

Management

Dedicated server management

NIC port

H. Personality Modules

I. Select system mounting

Rack mount kits

Appendix A

Section III. Serviceable

Items

List of spare items used for

repair

Section III.

6 www.kontron.com

II. Ordering CG1200 Systems

This section includes important information regarding how to order CG1200 systems.

Please be familiar with each of these areas before placing an order.

A. Select CG1200 Base System

The CG1200 Base System SKUs are listed in the table below:

Product Code

Description

Min. Order

Qty.

CG1200A-00

CG1200 Carrier Grade Server

Base Model 0 with AC Power Supply

CG1200D-00

CG1200 Carrier Grade Server

Base Model 0 with DC Power Supply

The CG1200 system SKUs are ordered using the Product Code as the order number.

The CG1200 is offered as either an AC or DC version—as indicated by the 7th digit of

the product code (“A” for AC or “D” for DC).

The above SKUs are “Base Model 0”SKUs—meaning they do not include processors,

heat sinks, memory, hard drives, power cord, operating system, or plug-in adapters.

Those components should be ordered separately as Accessories from Kontron or from

third party vendors listed in the Tested Hardware and Operating System List (THOL).

7 www.kontron.com

See the CG1200 Base Model 0 Configuration table below for a list of components

included in each base model 0 SKU. Notice that there are a number of optional

accessory items which must be ordered separately.

Component Description

AC Model 0

Configuration

DC Model 0

Configuration

Chassis (sheet metal, top cover, PCI cages, air duct,

interconnection cables, misc. parts)

1 included

Baseboard S2400EP (Eagle Pass), power distribution

board, system boards, fans, interconnect cables

Included

AC power supply (650W)

1 included

DC power supply (650 W)

1 included

Power Distribution Board

1 included

Filler Panel in 2nd power supply bay

1 included

Bezel (unpainted)

1 included

RDIMM/UDIMM memory slots (memory not included)

8 included

Bays for hot-swap 2.5” Hard Disk Drives and drive carriers

4 included

Rear Panel GbE NIC (Cu) ports (via Server Board)

4 included

Power Cable

Purchase separately1

SAS RAID 5 Key

Purchase separately4

IOC/ROC Adapter

Purchase separately4

IOC/ROC RAID cable kit

Optional Accessories2

ROC Maintenance-free back-up kit (optional)

Purchase separately4

Remote Management Module 4

Purchase separately4

CG1200 Single slot PCI-e x16 Gen 3 passive riser

1 included

Rack Mount Kits

Optional Accessory3

SD Flash Module

Included

Kontron Deployment Assistant on SD Flash media

Included

Rail Enabling Kit (enables AXXBASRAIL13 and

AXXHERAIL2)

Optional Accessory3

Processor (refer to “Details on Ordering Processors”)

Purchase separately4

Heatsink

Accessory or purchase separately

RDIMM/UDIMM Memory

Purchase separately4

Hard Disk Drives (SAS or SATA SSD)

Purchase separately4

eUSB Flash Drive

Purchase separately4

1Refer to AC power cord accessory in this section

2Refer to “Production Spares/Accessories List” in section III

3Refer to “Rack Mounting Options” in the Appendix

4Should be purchased separately (parts not listed in this document)

8 www.kontron.com

B. Select the Redundant Power supply

The CG1200 System accommodates a 2nd power supply which enables redundancy. Order

the 2nd power supply to agree with either AC or DC base system. Order AC power cords to

agree with the number of power supplies in the final system. Example: One CG1200A-00

base system + the 2nd power supply require 2 AC Power Cords.

Because DC power input cabling is usually custom, no DC power cord is offered. The

CG1200D-00 does contain a DC input terminal block for terminating DC input power.

Product Code

Description

Products

Supported

Included in

Base Model

(Y/N)

Min.

Order

Qty

CG2200-ACPSU

AC Power Supply

CG1200 and

CG2200

Y (one in AC

SKU)

CG2200-DCPSU

DC Power Supply

Includes input power connector

CG1200 and

CG2200

Y (one in DC

SKU)

1-340000-0

AC Power Cord

Should be ordered by North America

customers. International customers should

procure their specific power cords directly.

All CRMS

servers

Power cords are not included with the Mod 0 system. For AC Power cords, order the

above North American power cable using the provided product code. This power cable

is RoHS-compliant.

9 www.kontron.com

C. Select Number and Type of CPUs

The CG1200 is designed to support the following processor SKUs from the Intel®Xeon®

processor E5-2400 and E5-2400 v2 series. The Base Model 0 CG1200 includes Zero

CPUs. Customer must separately purchase CPU 1 and 2.

Intel®Xeon®Processors Supported by the CG1200:

Processor

Number

Cores

Speed

TDP

Memory Speed

Support

Intel P/N (tray)

E5-2448L

8 cores

1.8 GHz

70W

DDR3-1600

CM8062007187409

E5-2428L

6 cores

1.8 GHz

60W

DDR3-1333

CM8062007187509

E5-2418L

4 cores

2.0 GHz

50W

DDR3-1333

CM8062000911406

E5-2448Lv2

10 cores

1.8 GHz

70W

DDR3-1600

CM8063401293802

E5-2428Lv2

8 cores

1.8 GHz

60W

DDR3-1600

CM8063401293902

E5-2418Lv2

6 cores

2.0 GHz

50W

DDR3-1333

CM8063401294008

Notes:

The above processors are on Intel’s long life roadmap and are recommended with

the CG1200 for highest performance and long availability and support.

These processors are orderable from Intel using the indicated part numbers.

Use of the above processors requires the purchase of a passive heatsink. See its

order code below.

D. Heat Sink

Please order the number of heatsinks to agree with the number of CPUs in the system.

Use the order code below.

Product Code

Description

Products

Supported

Included in

Base Model

(Y/N)

Min.

Order

Qty

CG1200-HEATSNK

Heatsink (passive)

Contents: 25.5mm Tall Passive Heatsink

(copper base with aluminum fins)

CG1200

10 www.kontron.com
