Konica Minolta Magicolor 8650DN Manuel utilisateur

4343-PS361-10 C M BK

2011.7

User’s Guide

Device Set-Up

Device Set-Up i

Contents

About this Product .......................................................................................... iii

Trademarks ..................................................................................................... iv

1 Getting Started

1.1 System Requirements ...................................................................... 1-1

1.2 Overview of Functions ...................................................................... 1-2

2 Software Installation

2.1 OpenAPI settings .............................................................................. 2-1

Installation procedure .................................................................... 2-1

2.2 Installation of Device Set-Up ........................................................... 2-2

Installation ...................................................................................... 2-2

2.3 Uninstalling ........................................................................................ 2-6

3 How to Use the Device Set-Up

3.1 Specifying automatic protection settings ...................................... 3-1

Installation procedure .................................................................... 3-1

To change settings ......................................................................... 3-3

3.2 Main Window ..................................................................................... 3-4

Menu Bar ........................................................................................ 3-5

Icon / Tab in main window ............................................................. 3-6

4 Device Registration

4.1 Search for a supported device ........................................................ 4-1

Registration with the IP address specified .................................... 4-4

Registration from the Function access restriction file .................... 4-6

Registration of the local file ............................................................ 4-9

Set the search range .................................................................... 4-11

Edit of the device registered ........................................................ 4-14

Delete of the device registered .................................................... 4-16

5 Other Functions

5.1 Network Initial Setting ...................................................................... 5-1

Initialize the network of the Device ................................................ 5-1

Device Set-Up ii

5.2 Export/Import of the Device list ...................................................... 5-5

Export of the device list ................................................................. 5-5

Import of the device list ................................................................. 5-7

Import of the Device list from the previous version ....................... 5-9

5.3 Function Access Restriction File Settings ................................... 5-11

Create a New Function Access Restriction File ........................... 5-11

Add a Device to a Function Access Restriction File .................... 5-14

Edit the Function Access Restriction File .................................... 5-16

Delete the device information from a

Function Access Restriction File .................................................. 5-17

5.4 Group Settings ................................................................................ 5-18

Create a New Group .................................................................... 5-18

Edit a Group ................................................................................. 5-19

Delete a Group ............................................................................. 5-20

Set the Default Group .................................................................. 5-21

5.5 LDAP Server Access Settings ....................................................... 5-22

Add LDAP Server Access Settings .............................................. 5-22

Edit LDAP Server Access Settings .............................................. 5-25

Delete LDAP Server Access Settings .......................................... 5-25

5.6 Display Option Settings .................................................................. 5-26

Set Display Options ..................................................................... 5-26

5.7 Displaying the Help ......................................................................... 5-29

Displaying the Help ...................................................................... 5-29

5.8 Displaying the version information ............................................... 5-30

Procedure ..................................................................................... 5-30

Device Set-Up iii

About this Product

For The Device Set-up, installing the plug-ins allows you to obtain the infor-

mation of a copier on the network and/or change its settings.

Device Set-Up iv

Trademarks

KONICA MINOLTA and the KONICA MINOLTA logo are trademarks of KONI-

CA MINOLTA HOLDINGS, INC.

PageScope is a trademark of KONICA MINOLTA BUSINESS TECHNOLO-

GIES, INC.

Active Directory, Microsoft and Windows are either registered trademarks or

trademarks of Microsoft Corporation in the United States and/or other coun-

tries.

Intel and Pentium are trademarks or registered trademarks of Intel Corpora-

tion or its subsidiaries in the United States and other countries.

Microsoft®and Windows®are either registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries.

All other product names are trademarks or registered trademarks of their re-

spective companies.

Dialog boxes

The dialog boxes shown in this manual are those that appear in Windows XP.

Note

Please be aware that devices and settings may result in the content of

screens being different to as shown in this document.

Note

Unauthorized reproduction, translation or duplication of this document,

whether in its entirety or in part, is strictly prohibited.

The content of this document is subject to change without notice.

Getting Started 1

Device Set-Up 1-1

1 Getting Started

1.1 System Requirements

Systems must have the following specifications in order to use this software.

-Operating System

Windows XP Professional (SP3 or later)

Windows XP Professional x64 Edition (SP2 or later)

Windows Vista Enterprise (SP2 or later)*

Windows Vista Business (SP2 or later)*

Windows Vista Ultimate (SP2 or later)*

Windows 7 Enterprise (SP1 or later)*

Windows 7 Professional (SP1 or later)*

Windows 7 Ultimate (SP1 or later)*

* 32-bit(x86) and 64-bit(x64) editions are supported.

-Computer

According to the recommended system requirements of your operating

system.

-Memory (RAM)

According to the recommended system requirements of your operating

system.

-Unused hard drive capacity

100 MB or more

-Display

800 × 600 pixel, 16 bit - color or better

-Network

TCP/IP protocol

-Applications

Microsoft Internet Explorer 6.0 (SP1) or later

Microsoft .NET Framework 2.0 (SP2 or later) <Windows XP>

Microsoft .NET Framework 3.5 (SP1 or later) <Windows Vista>

* The edition of .NET Framework required for this software is pre-installed

on Windows 7.

-Supported Devices

For details of the copier and the printer (supported device of the plug-in

application) of KONICA MINOLTA, see the Readme of each plug-in ap-

plication.

Refer to the Readme file for the latest information about service packs and

so on.

Getting Started 1

Device Set-Up 1-2

Note

In order to use this software, it is necessary to enable OpenAPI from the

device panel by selecting Administration Settings, then System.

1.2 Overview of Functions

For The Device Set-up, installing the following plug-ins allows you to obtain

the information of a copier on the network and/or change its settings.

Plug-in Description

PageScope

Data Administrator

PageScope Data Administrator is an administration tool with

which authentication data and addresses that are registered in

the control panel of supported devices (multifunctional OA

equipment) can be edited and changed from other computers

on the network.

HDD Backup Utility HDD Backup Utility is used to back up (save) and restore (re-

cover) information on media installed in multifunctional prod-

ucts (MFP) on the network.

Log Management Utility Log Management Utility accesses MFP products on the net-

work, and displays log files (operations and processing

records that include monitoring logs and communications his-

tory) stored on these devices. These can be used in manage-

ment of device usage status, and in troubleshooting.

Font Management Utility Font Management Utility is a utility that allows you to add and

delete the fonts and the forms for printing of the supported de-

vices (MFPs) that are on a network.

Copy Protection Utility Copy Protection Utility is used to program multifunctional

products with copy protection and stamp information.

Device Set-Up

Data Administrator

Copy Protection Utility

Log Management Utility

HDD Backup Utility

Font Management Utility

Software Installation 2

Device Set-Up 2-1

2 Software Installation

2.1 OpenAPI settings

Some plug-in applications use OpenAPI. On an occasion like this, it is nec-

essary to make a write setting in advance on the device side.

Installation procedure

Before installing the Device Set-Up, specify the OpenAPI settings on the de-

vice.

%Specify the OpenAPI Login Name and password from the control panel

of the device as necessary.

– For details on the procedure for specifying the OpenAPI settings

from the control panel of the device, refer to the device’s User’s

Guide.

Note

Follow the instructions in the User’s Guide for the device to specify the

settings for SSL transmission.

Software Installation 2

Device Set-Up 2-2

2.2 Installation of Device Set-Up

Install the Device Set-Up as follows:

Note

When installing the Device Set-Up, the Microsoft .NET Framework is re-

quired to have been installed in advance.

The version of Microsoft .NET Framework is based on the OS to be used.

Refer to page 1-1 for details.

Before installing the utility, be sure to log in with Administrator privileges.

Quit all applications (including virus detection programs) that are running.

Installation

1Double-click the Setup.exe of the plug-in application you want to in-

stall.

2Select language and click [OK].

3Before installing the plug-in application, a message is displayed in-

forming that the Device Set-Up will be installed. When the message is

displayed, click [OK].

Software Installation 2

Device Set-Up 2-3

4Click [Next].

5When you consent to the Software End User License Agreement, se-

lect [I accept the terms in the license agreement] and then click [Next].

– When you do not consent to the Software End User License Agree-

ment, you cannot use this software.

Autres manuels pour magicolor 8650DN

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Konica Minolta Logiciel

Konica Minolta

Konica Minolta bizhub PRESS C6000 Manuel utilisateur

Konica Minolta

Konica Minolta bizhub PRO 1051 Series Manuel utilisateur

Konica Minolta

Konica Minolta DiMAGE Master Lite Manuel utilisateur

Konica Minolta

Konica Minolta PageScope Manuel utilisateur

Konica Minolta

Konica Minolta bizhub PRO 1051 Series Manuel utilisateur

Konica Minolta

Konica Minolta DiMAGE Viewer Manuel utilisateur

Konica Minolta

Konica Minolta SPECTRAMAGIC NX - Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C654 Manuel utilisateur

Konica Minolta

Konica Minolta Konica Print Utility KP Fiche d'information produit

Konica Minolta

Konica Minolta CM-SA Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C654 Manuel utilisateur

Konica Minolta

Konica Minolta magicolor 8650DN Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C654 Manuel utilisateur

Konica Minolta

Konica Minolta magicolor 8650DN Manuel utilisateur

Konica Minolta

Konica Minolta PageScope Manuel utilisateur

Konica Minolta

Konica Minolta COLIBRI Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C650 Series Manuel utilisateur

Konica Minolta

Konica Minolta bizhub C364e Manuel utilisateur

Konica Minolta

Konica Minolta bizhub 25 Manuel utilisateur

Konica Minolta

Konica Minolta DiMAGE Transfer Guide de démarrage rapide

Konica Minolta

Konica Minolta bizhub 181 Manuel utilisateur

Konica Minolta

Konica Minolta bizhub 652 Guide d'installation

Konica Minolta

Konica Minolta ScanDIVA Manuel utilisateur

Konica Minolta

Konica Minolta TWIN Driver Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur
