Konica Minolta FAX 2900 Manuel utilisateur

Contents

1 Introduction ................................................................... 1

2 Making a basic operation ............................................. 1

3 Specifying the Zoom Ratio........................................... 3

4 Adjusting the Image Density........................................ 4

5 Making 2in1 Copies ...................................................... 6

6 Specifying Sorting ........................................................ 7

7 Basic Faxing.................................................................. 8

A4S quick guide.book Page i Wednesday, September 15, 2004 11:00 AM

A4S quick guide.book Page ii Wednesday, September 15, 2004 11:00 AM

Introduction 1

1 Introduction

This manual provides information on the basic copy and fax operation.



Note

Please refer to CD manual for the details information and advanced function.

Store this manual and the enclosed CD-ROM in a safe location for future reference.

2 Making a basic operation

1Position the original.

2Make the other necessary

settings.

HZoom ( page 3)

HImage density (page 4)



Note

If you do not wish to specify the other

settings,continue with step 3.

Paper

Zoom

Auto/Photo

Chapter01.fm Page 1 Monday, September 20, 2004 11:56 AM

2Making a basic operation

3Using the 10-Key Pad, enter the

number of copies to be made. Any

number from 1 to 99 can be

entered.

4Press the [Start] key.

This will start the print cycle.

HTo stop the print cycle in mid-

operation, press the [Stop]

key.

HTo cancel the print job, press

the [No] key or the [Panel Reset] key.

HTo restart the print cycle, press the [Start] key.

HIJ

QPST

BCD

KLM

UVW

EFG

NOP

XYZ[

234

Chapter01.fm Page 2 Monday, September 20, 2004 11:56 AM

Specifying the Zoom Ratio 3

3 Specifying the Zoom Ratio

By specifying a zoom ratio, the copy can be enlarged or reduced.

Zoom Ratio Settings

Setting the Zoom Ratio

1Position the original.

2Press the [Zoom] key until the

desired fixed ratio is selected.

HTo specify a zoom ratio other

than a fixed ratio, press the

[ ] and [ ] keys until the

desired zoom ratio is specified.

Pressing these keys change the ratio in x 0.01 increments.

3Using the 10-Key Pad, enter the

number of copies to be made, and

then press the [Start] key.

Zoom Ratio Settings Description

Fixed ratios • The following optimum zoom ratios are available for making copies

from commonly used original sizes to standard paper sizes.

•×0.50

•×0.64 (LT →HL)

•×0.78 (LG →LT)

•×1.29 (HL →LT)

•×1.54 (HL →LG)

•×2.00

Ratios set using the Zoom [▼]

and [▲] keys

Pressing the [▼] or [▲] key increases or decreases the zoom ratio in

×0.01 increments.

The ratio can range from ×0.50 to ×2.00.

Full Size This setting makes a copy the same size as the original (×1.00).

Zoom

Chapter01.fm Page 3 Monday, September 20, 2004 11:56 AM

4Adjusting the Image Density

4 Adjusting the Image Density

The image density setting can be adjusted in two broad modes, “Text” and “Photo”.

Image Density Setting

GText mode:

The image density can be adjusted either automatically (Auto) or manually in

nine steps.

HThe image density is adjusted automatically according to the original from

which a copy is to be made.

HManual image density adjustment:

The image density can be adjusted to one of nine levels.

To reduce bleed-throughs when copying newspapers and magazines, press

the [ ] key to select a lighter setting. To reproduce faint colors in brighter

parts of the image, press the [ ] key to select a darker setting.

Selecting a darker setting could result in a background image being

reproduced on the copy, while selecting a lighter setting could make the copy

image itself too light. Select the appropriate level according to your original.

GPhoto mode:

Select “Photo” when making a copy from an original having large halftone

images, such as photos.

Setting the Image Density

1Position the original.

2Press the [Auto/Photo] key on the

control panel to select the desired

mode.



Note

In the Photo mode, the Auto

setting cannot be selected.

Auto/Photo

Chapter01.fm Page 4 Monday, September 20, 2004 11:56 AM

Adjusting the Image Density 4

3If you want to adjust the image density manually, press the [ ] and [ ] keys

to select the desired setting.

4Make the other necessary settings

HZoom ratio (page 3)

5Using the 10-Key Pad, enter the

number of copies to be made, and

then press the [Start] key.

Chapter01.fm Page 5 Monday, September 20, 2004 11:56 AM

5Making 2in1 Copies

5 Making 2in1 Copies



This function isavailable only with FAX3900

Two sheets of single-sided documents can be copied onto one double-sided sheet.

Specifying Settings for 2in1 Copies

1Position the original.

2Press the [2in1] key, and then

check that the indicator lights up.

3Make the other necessary settings.

HImage density ( page 4)

4Using the 10-Key Pad, enter the

number of copies to be made, and

then press the [Start] key.

2in1

Chapter01.fm Page 6 Monday, September 20, 2004 11:56 AM

Specifying Sorting 6

6 Specifying Sorting

1Position the originals.

2Press the [Sort] key, and then

check that the indicator lights up.



Note

If the Sort indicator is not lit, the Non-

Sort setting is selected.

3Make the other necessary settings.

HZoom Ratio (page 3)

HImage density (page 4 )

4Using the 10-Key Pad, enter the

number of print to be made, and

then press the [Start] key.

Sort

Chapter01.fm Page 7 Monday, September 20, 2004 11:56 AM
