KH 5522/23

CV_KH5522_23_V23384_LB3 16.07.2008 16:48 Uhr Seite 4

- 3 -

CONTENT PAGE

Safety Instructions 4

Technical Data 4

Device Description 4

Purpose 5

Included in delivery 5

Commissioning 5

Use 6

Warning Displays 6

Replacing the Batteries 7

Use and Storage 7

Cleaning 8

Troubleshooting 8

Disposal 8

Warranty & Service 9

Importer 9

Read the operating instructions carefully before using the appliance for the first time and preserve this

booklet for later reference. Hand over the manual to anyone, whom you pass on the appliance to.

IB_KH5522_23_V23384_LB3 10.07.2008 13:21 Uhr Seite 3

- 4 -

DIGITAL BATHROOM

SCALE

Safety Instructions



Hazard!

Ensure that no liquid gets into the scale or into the

display. This can cause an electrical shock hazard!

Do not allow individuals (including children) to use

the appliance whose physical, sensorial or mental

abilities or lack of experience and knowledge hin-

der their safe usage of it if they have not previously

been supervised or instructed in its correct usage.

Tell children about the appliance and its potential

dangers so that they do not play with it.



Warning!

Do not place the scale in the direct vicinity of heat

sources. Scale and display may only be operated

at temperatures between 10° and 40°C. At higher

or lower temperatures malfunctions or permanent

damage can occur.

Do not charge the scale with weight in excess of

180 kg / 396 lb! This can irreparably damage the

scale



Caution!

Old batteries can leak battery acid. In the event of

the batteries leaking acids, wear protective gloves.

Clean the battery compartment with a dry cloth.

Remove the batteries if you will not be using the sca-

le for a longer period of time.



Please note!

Avoid electrostatic charging and discharging. Elec-

trostatic charging or discharging can cause incor-

rect displays or suddenly switch-off the scale.

No liability/guarantee is assumed for damages

caused by…

• opening the scale housing

• repair work that is not performed by qualified

personnel

• improper user of the scale

Technical Data

Maximum load bearing

capacity: 180 kg/396 lb

Tolerance Range: +/- (1% + 0.1kg/0.2lb)

(at 30 kg - 180 kg )

Minimum measurable

weight: 3 kg/6.6 lb

Selectable measurement

units: kg/lb

Scaling: 0.1 kg/0.2 lb

Operating temperature: 10 °C - 40 °C

Display for low battery power

Overload display

Fault display

Battery operation: 2 x CR2032 / 3V

(Lithium batteries)

Device Description

qDisplay

wBattery compartment

eSafety glass

rSelector switch (kg / lb)

IB_KH5522_23_V23384_LB3 10.07.2008 13:21 Uhr Seite 4

- 5 -

Purpose

These digital glass scale is exclusively intended

• as personal scale

• for use in private households

Included in delivery

Digital glass scale

2 x CR2032 / 3V lithium batteries

Operating instructions

Before using the appliance for the first time, check

to ensure that the contents are complete and

undamaged.

Commissioning

1. Remove the cover of the battery compartment.

Remove the insulation strip from the battery com-

partment and insert the batteries back into the

battery compartment with the correct polarity.

2. Place the cover back on the battery compart-

ment and press it down until you hear it snap

into place.

3. Set the desired unit of weight (kg or lb) by

pressing the selector switch.

IB_KH5522_23_V23384_LB3 10.07.2008 13:21 Uhr Seite 5

- 6 -

• Place your glass scale on a flat, solid surface.

Please ensure that both the floor where the

weigh scales are set up and the surface of the

weigh scales are not wet to ensure that

nobody slips.



Please note!

The glass scale contains sensitive electronic compo-

nents and must therefore not be installed

• close to heat sources

• in environments that are exposed to extreme

humidity

Use

Attention: Never burden the scales one-sidedly. Al-

ways step onto the scales in the middle and with

both feet. If you do not, the digital glass scale could

tip to one side and be irreparably damaged.

Additionally, there is the risk of falling over!

1. Tap your foot lightly on the centre of the scale

until “HI” appears on the LCD display.

2. Stand with both feet on the scale once “0.0”

appears on the LCD display. Stand calmly and

without shifting your weight.

3. During weighing, the “kg/lb” LCD display flas-

hes and the displayed value rises until your

weight has been determined.

4. The “kg/lb” display now stops flashing and your

weight is displayed in grades of 0.1 kg/0.2 lb.

Attention: never jump on to the scale as this may

cause damage.

Warning Displays

“0_Ld” appears in the LCD display if the weight ex-

ceeds the maximum weighing capacity of 180

kg/396 lb. Step off the scale immediately as you

may otherwise cause damage.

Replace the batteries if “Lo” appears in the display.

The scale is unable to measure the weight if “Err”

appears in the display. Step off the scale in this

case, wait for a few seconds and then try again.

Make sure you stand calmly and do not interrupt

the weighing process.

IB_KH5522_23_V23384_LB3 10.07.2008 13:21 Uhr Seite 6

- 7 -

Replacing the Batteries

1. Remove the lid on the battery compartment.

2. Remove the old batteries from the battery

compartment. Insert two new batteries of type

CR2032 into the battery compartment. Be sure

to orient the batteries with the correct polarity.

3. Place the cover back on the battery compart-

ment and press it down until you hear it snap

into place.

Use and Storage

• Please take note that the measurement results of

different scales may differ slightly.

• Avoid using the batteries unnecessarily. Therefo-

re, do not store any items on the scale if it is not

being used. Remove the batteries if you will not

use the scale for a longer period.

• Keep the scale in a clean and dry environment.

• Avoid electrostatic charging.

• Your glass scale represent a sensitive electronic

instrument. As such, high-frequency devices may

sometimes cause disturbance when used in the

immediate vicinity (e.g. mobile telephones, CB

radio stations, remote controls and microwave

ovens).

If there are faults such as irregular or faulty displays

in the LCD display, remove the scale from the source

of disturbance or deactivate the source of disturban-

ce when you are using the product.

IB_KH5522_23_V23384_LB3 10.07.2008 13:21 Uhr Seite 7

- 8 -

Cleaning

Only use neutral detergent and a soft cloth to clean

the glass scale.

Troubleshooting

Do not attempt to dismantle the scale to repair any

defects yourself. You may otherwise damage the

sensitive electronic components.

Only qualified service personnel are authorised to

repair the glass scale!

No liability will be accepted for damage resulting

from improper use and/or opening of the

appliance!

In the event of faulty operation or if the display is in-

correct, please check the following conditions:

• Are the batteries positioned within the battery

compartment with the correct polarity?

• Is the selector switch (kg/lb) set to the correct

position?

Perform a reset on the scale:

• To do this, remove the batteries from the battery

compartment.

• Wait a few seconds, then insert the batteries

back into the battery compartment.

If these measures do not correct the problem, plea-

se contact the appropriate service partner for your

country.

Disposal

Do not dispose of the appliance in your

normal domestic waste. This product is

subject to the European guideline

2002/96/EC.

Dispose of the appliance through an approved dis-

posal centre or at your community waste facility.

Observe the currently applicable regulations.

In case of doubt, please contact your waste disposal

centre.

Battery disposal!

Batteries may not be disposed of with normal

domestic waste. All consumers are statutorily obli-

ged to dispose of batteries at the collection point in

their community/district or with the original supplier.

The purpose of this obligation is to ensure that

batteries can be disposed of in an environmentally

friendly manner. Only dispose of batteries when

they are fully discharged.

Dispose of all packaging materials in an

environmentally friendly manner.

IB_KH5522_23_V23384_LB3 10.07.2008 13:21 Uhr Seite 8

- 9 -

Warranty & Service

The warranty for this appliance is for 3 years from

the date of purchase. The appliance has been

manu-factured with care and meticulously examined

before delivery. Please retain your receipt as proof

of purchase. In the case of a warranty claim, please

make contact by telephone with our service depart-

ment. Only in this way can a post-free despatch for

your goods be assured.

The warranty covers only claims for material and

maufacturing defects, not for wearing parts or for

damage to fragile components. This product is for

private use only and is not intended for commercial

use.

The warranty is void in the case of abusive and im-

proper handling, use of force and internal tampe-

ring not carried out by our authorized service

branch. Your statutory rights are not restricted in

any way by this warranty.

DES Ltd

Units 14-15

Bilston Industrial Estate

Oxford Street

Bilston

WV14 7EG

Tel.: 0870/787-6177

Fax: 0870/787-6168

e-mail: support.uk@kompernass.com

Irish Connection

Harbour view

Howth

Co. Dublin

Tel: 00353 (0) 87 99 62 077

Fax: 00353 18398056

e-mail: support.ie@kompernass.com

Importer

KOMPERNASS GMBH

BURGSTRASSE 21

44867 BOCHUM, GERMANY

www.kompernass.com

IB_KH5522_23_V23384_LB3 10.07.2008 13:21 Uhr Seite 9

Autres manuels pour KH 5522

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Kompernass Échelle

Kompernass

Kompernass KH 808 Manuel utilisateur

Kompernass

Kompernass KH 804 Manuel utilisateur

Kompernass

Kompernass KH 5519 Manuel utilisateur

Kompernass

Kompernass KH 5516 Manuel utilisateur

Kompernass

Kompernass KH 808 Manuel utilisateur

Kompernass

Kompernass KH 5518 Manuel utilisateur

Kompernass

Kompernass KH 1157 Manuel utilisateur

Kompernass

Kompernass KH 1156 Manuel utilisateur

Kompernass

Kompernass KH 5522 Manuel utilisateur

Kompernass

Kompernass KH 1156 Manuel utilisateur

Kompernass

Kompernass KH 1159 Manuel utilisateur

Kompernass

Kompernass KH 5516 Manuel utilisateur

Kompernass

Kompernass KH 807 Manuel utilisateur

Kompernass

Kompernass KH 5518 Manuel utilisateur

Kompernass

Kompernass KH 804 Manuel utilisateur

Kompernass

Kompernass KH809 Manuel utilisateur

Kompernass

Kompernass KH 1157 Manuel utilisateur

Kompernass

Kompernass KH 1156 Manuel utilisateur

Kompernass

Kompernass KH 5524 Manuel utilisateur

Manuels Échelle populaires d'autres marques

AWS

AWS ZEO-50 Manuel utilisateur

Gima

Gima Glass Body Fat Analyzer Manuel de la liste des pièces

Seca

Seca 374 Manuel utilisateur

TEC

TEC TEC SL59 SERIES Manuel utilisateur

Axis

Axis B/E Series Manuel utilisateur

Alecto

Alecto ACW-40 Manuel utilisateur

Rice Lake

Rice Lake MSI-4260 IS Manuel utilisateur

IKA

IKA RCT basic safety control Manuel utilisateur

ADE

ADE M20011 Manuel utilisateur

Duronic

Duronic KS3000 Manuel utilisateur

Digi

Digi SM-720 Manuel utilisateur

Cardinal

Cardinal CS Series Manuel utilisateur

Korona

Korona Kastella Manuel utilisateur

A&D

A&D FC-50Ki Manuel utilisateur

BDA

BDA CAMARGUE Manuel utilisateur

Tanita

Tanita HD-357 Manuel utilisateur

Leifheit

Leifheit 03173 Manuel utilisateur

Lumme

Lumme LU-1340 Manuel utilisateur
