Projection Clock with Radio KH
2201/02
Projection Clock with Radio
KH 2201 / KH 2202
Operating Instructions
KH2201
KH2202
KH2201_02_IB_UK.qxd 14.11.2006 9:12 Uhr Seite 3
KH2201_02_IB_UK.qxd 14.11.2006 9:12 Uhr Seite 4
rewq
t
y
u
i
a
s
d
f
g
h
j
k
l
;
o
KH 2201
KH2201_02_IB_UK.qxd 14.11.2006 9:12 Uhr Seite 5
KH 2202 wui
e
r
a
2)
j
h
yt
fg
;
q
olk
d
s
KH2201_02_IB_UK.qxd 14.11.2006 9:13 Uhr Seite 8
- 3 -
Projection Clock with Radio
Safety instructions 4
Intended Use 5
Items supplied 6
Operating Elements 6
Technical data 6
Setup 7
Operation 7
Connect the external mains adaptor 7
Radio operation 8
Setting up the telescope aerial 8
Setting the time 9
Setting the alarm time 9
Snooze Function 10
Projection 10
Background lighting for the display and projection 11
Cleaning 11
Disposal 12
Warranty and Service 12
Read the operating instructions carefully before using the appliance for
the first time and preserve this booklet for later reference. Pass the
manual on to whomsoever might acquire the appliance at a later
date.
KH2201_02_IB_UK.qxd 14.11.2006 9:13 Uhr Seite 3
- 4 -
Projection clock with
radio
Safety instructions
To avoid fatal injury
through electric shock:
• Use the appliance only in
dry rooms.
• Ensure that fluids or
other objects can never
enter into the appliance.
• Do not place objects con-
taining fluids, e.g. flower
vases, on the appliance.
To avoid burn and
other injuries:
• Place the appliance in an
open and well-ventilated
area so that heat pockets
cannot be created within
it. Never cover the venti-
lation openings!
• Do not place open fire
sources, e.g. candles, on
the appliance.
• Avoid close proximity to
heat sources, e.g. direct
solar radiation, heaters
and other appliances
etc.!
• Do not allow children or
persons in need of atten-
tion to use the appliance
unsupervised, they are
not always able to cor-
rectly assess the potential
dangers.
Electro-magnetic fields
This appliance lies below
the maximum legal limits
for electric smog, even within
the casing! However, should
you still have doubts about
installing it in the bedroom:
• Place the appliance about
half a meter from the
bed.
KH2201_02_IB_UK.qxd 14.11.2006 9:13 Uhr Seite 4
- 5 -
From this distance the electro
magnetic fields are no longer
effective, even for electro
sensitive people.
Note:
This appliance is equipped
with non-slip rubber feet.
As furniture upper surfaces
comprise of various materials
and are cleaned with various
types of polishes and/or
cleaning agents, it cannot
be completely excluded that
some of these substances
contain components that
could attack the rubber
pads and soften them. If
necessary, place an anti-slip
mat under the rubber pads
of the appliance.
Note:
In certain countries there
could be exceptional regula-
tions for the allocated radio
frequency ranges.
Take note that you may not
exploit possibly received
radio services, pass them
on to third parties or im-
properly misuse them.
Intended Use
The equipment is intended
for employment as an
alarm clock, using a tone
signal, and for receiving
radio transmissions. All
other usages or modifications
to the appliance are deemed
to be improper use and may
result in serious injury.
The manufacturer accepts
no liability for damages that
result from improper use of
the appliance or are caused
by incorrect operation of it.
The appliance is not intended
for commercial use.
KH2201_02_IB_UK.qxd 14.11.2006 9:13 Uhr Seite 5
- 6 -
Items supplied
After unpacking the appli-
ance, immediately check to
determine that all listed
items are present and that
the appliance is in a faultless
condition.
1 Projection Clock Radio
1 Operating instructions /
Guarantee documentation
The batteries and a 3V-
mains adaptor (accessories),
required for operation, are
not included in the supply.
Operating Elements
Projection lens
Telescope aerial
Button SNOOZE
Projection, Display
illumination
Display
Frequency scale
Button ALARM
Button HOUR
Button TIME
Button MIN
Loudspeaker
Projection focus
Tuning wheel
Volume controller
VOLUME / BUZZ
External 3V DC connector
Battery compartment
Switch - Projection
ON/OFF
Switch - Alarm ON/OFF
Waveband selector
FM/AM
Stand-up support (only
Model KH 2202)
Technical data
Rated voltage:
Direct current (DC): 3 V
Rated current: 300 mA
Frequency range :
FM (USW) 87.5 - 108 MHz
AM (MW) 530 - 1600 kHz
