Kohler K-99696-NA Instructions de montage
Installation and Care Guide
Amplifier
K-99696-NA
Français, page ″Français-1″
Español, página ″Español-1″
1232038-2-C
IMPORTANT INSTRUCTIONS
WARNING: When using electrical products, basic
precautions should always be followed, including the
following:
WARNING: Risk of electric shock. A qualified electrician
should route all electrical wiring.
WARNING: Risk of electric shock. Disconnect power before
servicing.
CAUTION: Risk of product damage. The amplifier is rated to
operate in temperatures up to 104°F (40°C). Do not install near heat
sources (such as radiators or heat registers) or in any location where
the temperature may exceed 104°F (40°C).
NOTICE: This product is not water-resistant. Do not install in a
location where excessive moisture, high humidity levels, or
condensation are present.
NOTICE: Follow all electrical and building codes.
NOTICE: Provide unrestricted service access to the amplifier.
NOTICE: Provide a minimum of 6″(152 mm) of space around the
amplifier for proper air flow.
NOTE: This amplifier can be operated as a stand-alone unit, or can
be installed with the DTV+ showering system.
_________________________________________________________________
Operation with DTV+
To connect the amplifier to the DTV+ system, the K-99695 system
controller is required.
The provided data cable is used to connect the amplifier to the
system controller.
Refer to the ″DTV+ System Layout″section in this guide.
Before Operating the System For the First Time:
Download and install the latest software for connected components.
This may take an hour or more to complete based on system
configuration and internet connection speed. Do not disconnect the
power from any components during software download and
installation.
1232038-2-C 2 Kohler Co.
FCC, IC, and CE Compliance
Contains: Kohler Company, Model: K-99696-NA, FCC ID:
N82-KOHLER010, IC: 4554A-KOHLER010, CE: CE2200
IFT Certification Number: 201801A02469
FCC Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that
Kohler Co. 3 1232038-2-C
FCC, IC, and CE Compliance (cont.)
may cause undesired operation of the device.
CAN ICES-3(B) /NMB-3(B)
CE2200
Range and Function Disclaimer
BLUETOOTH
®
is the name for a short-range radio frequency (RF)
technology that operates at 2.4 GHz. The effective range of most
BLUETOOTH mobile devices is 10 meters. BLUETOOTH is designed
for very low power use. The compatibility of the BLUETOOTH
amplifier interface to mobile/portable devices differs according to the
various individual devices and, in particular, may vary with different
software versions for a device. The normal mobile device
BLUETOOTH range can be up to 10 meters, however, placement of
your mobile device and the BLUETOOTH amplifier’s installation
environment will impact your reception range.
Water and walls can act as blocking agents to the BLUETOOTH signal
that your mobile device is using to broadcast to your BLUETOOTH
amplifier. Therefore, selecting an installation location that removes
these range blocking obstacles will increase the effective range and
performance of your BLUETOOTH amplifier.
You can test your BLUETOOTH reception by performing simple range
tests using your mobile device prior to performing a permanent
installation. The best way to make use of the short BLUETOOTH range
is to make sure your BLUETOOTH amplifier is as close to the
BLUETOOTH transmitter (mobile phone, tablet, etc.) as possible. The
less distance between the two devices, the greater will be the reliability
of your BLUETOOTH audio signal, and the less distance means less
obstacles in the medium through which the transmission is passing, so
there is a reduced chance of audio signal loss.
The compatibility of the BLUETOOTH amplifier to mobile/portable
devices differs according to the various individual devices and, in
particular, may vary with different software versions for a device. All
functions are based on industry-wide communications standards.
Compatibility between the BLUETOOTH amplifier and mobile device
is therefore largely dependent upon the software version of the mobile
device. Other factors (e.g. installation location, walls, distance) mean
that in individual cases, sporadic impairment of functions may occur in
devices that otherwise function reliably. Not all functions are
supported in all countries.
Because of these reasons, Kohler Co. can assume no guarantee for the
1232038-2-C 4 Kohler Co.
Range and Function Disclaimer (cont.)
unlimited compatibility and functionality of your mobile device in
conjunction with the BLUETOOTH amplifier.
_________________________________________________________________
The BLUETOOTH
®
word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Kohler
Co. approved suppliers is under license. Other trademarks and trade
names are those of their respective owners.
Specifications
Ambient Temperature Max 104°F (40°C)
Maximum Relative Humidity 90% non-condensing
Electrical Service 100-240 VAC, 50-60 Hz, 1.2 A Max
Power Cable Length 69″(1753 mm)
Data Cable Length 6’ (1.83 m)
Output Power 20 Watts x 2 into 4 Ohms
Frequency Response 20 Hz - 18 kHz +/- 3dB
Signal/Noise Ratio >75 dB
Total Harmonic Distortion <0.1% at 1 Watt, <1% at full output
power
Tools and Materials
• Wire Cutter/Stripper
Plus:
Kohler Co. 5 1232038-2-C
Before You Begin
Determine amplifier and speaker locations before beginning
installation. Test the BLUETOOTH
®
range between the amplifier
and your wireless device when determining amplifier location.
The amplifier can be mounted in any orientation. Use the
supplied brackets or rubber feet to accommodate your mounting
configuration.
Locate the amplifier within close proximity to a 15 A, 120 V
electrical outlet. A GFCI outlet may be required in certain
applications.
A qualified electrician should install any electrical outlet.
If possible, install the electrical outlet prior to installing the
amplifier.
This amplifier complies with CE, FCC, and IC.
1232038-2-C 6 Kohler Co.
1. Preparation
Plan the location of the amplifier to allow access to the front and
back ports.
To play your personal music files, you need a wireless
BLUETOOTH device, or a device with a 3.5 mm stereo cable
connection.
The speaker terminal connections on the amplifier will accept a
12-24 AWG wire. Follow local codes for speaker wire type and
routing.
Allow adequate reach for wires between the amplifier and
speaker locations.
Make sure the LED light will be visible after installation.
For DTV+: Allow adequate reach for the data cable between the
amplifier and the system controller, or obtain a longer
Ethernet-style cable or extension cable.
LED
Front Back
Power
Cable
Speaker
Terminal
3.5 mm
Line-Out
DTV+ Data
Cable
3.5 mm
Line-In (1)
3.5 mm
Line-In (2)
Kohler Co. 7 1232038-2-C
2. Installation
CAUTION: Risk of product damage. The amplifier is rated to
operate in temperatures up to 104°F (40°C). Do not install near heat
sources (such as radiators or heat registers) or in any location where
the temperature may exceed 104°F (40°C).
NOTICE: Mount the amplifier in a dry location, and provide a
minimum of 6″(152 mm) of space for proper air flow.
Mounting Options
Surface-mount: Attach the four rubber feet to the underside of
the amplifier to protect against scratching your shelf or
countertop surface.
Cabinet-mount: Install the amplifier using the mounting brackets
and short screws.
Under-mount: Flip the orientation of the brackets on the amplifier
to install it in an upright position.
Wall-mount: Secure the amplifier using the mounting brackets,
long screws, and wall anchors (if needed).
Surface-Mount
Wall-Mount
Under-Mount
Anchor
Foot
Cabinet-Mount
1232038-2-C 8 Kohler Co.
Installation (cont.)
Bracket Installation
Position the amplifier with attached brackets in the desired
location.
Mark the bracket hole locations with a pencil.
Drill pilot holes or insert anchors as needed at the marked
locations.
Secure the brackets using the four screws provided.
Kohler Co. 9 1232038-2-C
3. DTV+ System Layout
The amplifier can be controlled digitally when connected to the
K-99695 system controller. The controller powers the interface(s) and
controls the amplifier and other system components.
NOTE: A data cable is provided to connect the amplifier to the
controller. If the amplifier is not within 6’ (1.83 m) of the controller,
obtain a longer Ethernet-style cable or add an extension cable.
Disconnect the power from the amplifier and the controller.
Connect one end of the data cable into the port on the back of the
amplifier.
Connect the other end of the cable into one of the eight grouped
component ports on the controller.
Reconnect the power to the amplifier and the controller.
Before Operating the DTV+ System For the First Time:
Download and install the latest software for connected components.
This may take an hour or more to complete based on system
configuration and internet connection speed. Do not disconnect the
power from any components during software download and
installation.
For more information on system setup and operation, refer to the
guide on the controller product page at www.us.kohler.com.
Controller
Digital
Valve(s)
Speakers
AC Power
Component
Cable
Connections
Amplifier
6' (1.83 m) Data Cable
Router
Interface
(Up to Three)
AC
Power
1232038-2-C 10 Kohler Co.
Table des matières
Langues :
Autres manuels Kohler Amplificateur
