Kogan XP8 Manuel utilisateur

XP8 WATERPROOF PORTABLE

WIRELESS BLUETOOTH SPEAKER

KAXP8SPKBKA

•Read all warnings and instructions in this user guide prior to using the device.

•Do not charge the speaker with voltage above 5V as this may cause

overcharging and damage to the battery and device.

•Keep the product away from direct heat sources, such as radiators, hot air

regulators, stoves or other heat generating instruments as it may cause damage

to the device.

•Do not insert foreign items into the ports of the speaker as this may damage

their use.

•It is not recommended to have the speaker play at maximum volume for

extended periods of time due to potential hearing damage for the listener and

damage to the speaker unit itself.

•Do not attempt to repair the speaker yourself. If you need help, contact

help.Kogan.com for assistance.

SAFETY & WARNINGS

ABluetooth Speaker (x1)

B Charging Cable (x1)

C Audio Cable (x1)

D User Guide (x1)

COMPONENTS

Speaker Grille

Next/Vol +

Power LED indicator

Mode switching button

Power switch

LED status indicator

Previous/Vol -

AUX in

Microphone

microSD card slot

Multi-function button (MFB)

USB Type-C charging port

OVERVIEW

Power ON/OFF

1. Press and hold the power switch for 2 seconds to turn the speaker on. The LED status

indicator will be flashing blue, and the power LED indicator will be flashing white.

2. Press and hold the power switch for 2 seconds to turn the speaker off. The LED status

indicator will turn off.

Sources

The speaker can play audio output from 3 different sources/modes:

•Bluetooth

•microSD card

•AUX

Mode switching

To switch between any of the 3 modes, press the mode switching button repeatedly until

you reach the desired mode.

Bluetooth Mode

This mode allows you to connect to any Bluetooth device to the speaker for audio output.

1. Power the speaker on. If this is your first time using the speaker the LED status

indicator will then be flashing blue, signalling the speaker is ready to pair with your

device.

If the device has been used before in a different mode, press the mode switching

button to switch between the modes until you see the LED status indicator

flashing blue.

2. Switch on the Bluetooth on your device. Ensure your device is set to be visible to all

nearby Bluetooth devices.

3. Search for "KAXP8SPKBKA" on your device and tap to connect. If you are unable

to find the speaker, try refreshing the list of available devices on your device. If the

connection is successful, the LED status indicator will stop flashing and turn to a

solid blue. Any media you play from your device now will have its audio emit from

the speaker via Bluetooth.

4. To disconnect your device, press and hold the MFB button for 2 seconds.

OPERATION

If you do not wish the speaker to automatically pair to your device when the Bluetooth

mode is turned on, the pairing record can be erased by pressing and holding mode

switching button down for 5 seconds. The speaker will power off when the pairing record

has been erased successfully.

microSD card mode

This mode allows you to play the audio output of files from a microSD card.

1. Lift the protective covering located on the side of the speaker to reveal the

microSD card slot.

2. Insert a microSD card, chip side facing down into the microSD card slot located on

the side of the speaker.

3. If successfully inserted and recognised, the speaker will then sound a voice prompt

and start playing MP3 files from the microSD card.

If no voice prompt is heard and files do not start playing, eject the microSD card

and try re-inserting it into the speaker.

AUX mode

This mode allows you to play audio output from a device via the 3.5mm audio cable.

1. Connect one end of the included 3.5mm audio cable into the 3.5mm headphone

jack of your device.

2. Connect the other end into the AUX in port. Any media you play from your device

now will have its audio emit from the speaker.

Notes:

•When reconnecting your device in the future, switch on the Bluetooth on your

device then power the speaker on. It will automatically reconnect to its last

paired device.

•If the speaker stops playing, press and hold the MFB button to reset, power

off and restart the speaker.

Note:

The speaker is compatible with microSD cards up to 64GB in storage.

Button Controls

•Press the MFB button to pause or play.

•Press the “-” to decrease volume.

•Press the “+” to increase volume.

•Press and hold the “-’’ to play the previous track.

•Press and hold the “+” to play the next track.

Calls

The speaker features an in-built microphone and has the capability to answer, reject, end,

and redial calls.

•To answer an incoming call, press the MFB button.

•To reject an incoming call, press and hold the MFB button for 2 seconds.

•To end a call, press the MFB button again.

•To redial the most recent number in your call log, press the MFB button twice.

Charging

Charging is required if the power LED indicator lights up red.

The speaker can be charged by connecting the USB Type-C end of the charging cable into

the USB Type-C charging port, with the other end plugged into a powered device with a

USB port.

Once the power LED indicator turns off, the speaker is fully charged.

•The charging voltage and current is 5V/2.4A. Ensure any adapter used with this

charger is correctly rated to match.

•The battery performance may decrease after extended use. This is normal for all

devices powered by rechargeable batteries.

Note:

Some mobile phones default to answering calls via their own device speaker. Refer to

the instructions of your phone to enable calls to be answered using external devices.

True Wireless Stereo (TWS) using two speakers

You can connect to two XP8 speakers simultaneously for a stronger stereo and surround

sound effect.

1. Ensure Bluetooth is turned off on your connecting device.

2. Place the speakers side by side and power them both on.

3. Press and hold the mode switching button down on either one of the speakers for 2

seconds. A sound prompt will play to confirm both speakers are preparing to enter

TWS pairing mode.

4. Wait for the LED status indicator on the left channel speaker flashes, and the LED

status indicator on the right channel speaker turns a solid blue. Once this happens,

the TWS connection is successful.

5. Switch on the Bluetooth on your device. Ensure your device is set to be visible to all

nearby Bluetooth devices.

6. Search for "KAXP8SPKBKA" on your device and tap to connect. If you are unable

to find the speaker, try refreshing the list of available devices on your device. The

LED status indicators on both speakers will turn a solid blue if the connection is

successful.

7. To disconnect, press and hold the mode switching button down for 2 seconds.

If previously connected, the two speakers can automatically re-connect to each other with

TWS for future use. If you do not wish for both speakers to automatically re-connect, press

and hold the mode switching button down for 5 seconds. This will reset and restart the

speaker.

Notes:

•The speakers must enter TWS pairing mode prior to connecting to any

Bluetooth device. The TWS function will not work otherwise.

•When using the TWS connection between speakers, only the left channel

speaker will have the function of the calling controls.

Waterproof rating

IPX7

Bluetooth version

V5.0

Product size

186 x 50 x 62mm

Net weight

530g

Wireless working range

18m (without obstacles)

Input voltage

DC5V/2.4A

Rated power

8W x 2

Battery

3600mAh

Speaker

48mm

Profiles supported

A2DP, AVRCP, HFP & HSP

Signal to noise ratio

Greater than or equal to 80dB

Frequency response

115Hz-15kHz

Play time

15 hours

Talk time

15 hours

Charge time

3 hours

Voice chat

Supported

SPECIFICATIONS
