Kogan KASDA5123HA Manuel utilisateur
KOGAN 5.1.2 CHANNEL 320W
DOLBY ATMOS SOUNDBAR
WITH SUBWOOFER & REAR SPEAKERS
KASDA5123HA
•Do not expose this product to high temperatures and wet environments.
•To reduce the risk of electronic shock or fire, do not remove the cabinet cover.
•Do not attempt to repair the product yourself. If the product shows any signs of
damage, cease use immediately and contact help.Kogan.com for support.
•Do not place the product where it may come into contact with water, moisture or other
liquids. If the product is exposed to liquid, cease use immediately and contact
help.Kogan.com for support.
•Soundbar
•Wireless subwoofer
•Wireless rear speakers
•Remote control
•Power cord for the soundbar
•Power cord for the subwoofer
•AC adaptor for rear speakers
•AUX cable
•Rear speaker connecting cable
•User guide
COMPONENTS
SAFETY & WARNINGS
Control panel (soundbar)
No. Name Description
1 Power button Power the soundbar.
2 Mode button Switch between modes.
3 Play/pause button Play/pause tracks.
4 Previous/Volume decrease
button
•Short press the button to decrease volume.
•Long press the button to play the previous track.
5 Next/Volume increase button •Short press the button to increase volume.
•Long press the button to play the next track.
OVERVIEW
1
2
3
4
5
Ports (soundbar)
Back view (subwoofer)
6 HDMI OUT (ARC) port 10 Coaxial port
7 HDMI IN port 11 Optical port
8 USB port 12 Power switch
9 AUX port 13 AC IN port
14 Pair button
15 Indicator light
16 Power switch
17 AC IN port
6
10
11
12
9
8
7
13
Rear speakers
18 RS IN port
19 RS OUT port
20 DC IN port
21 Pair button
22 Indicator light
18
19
20
21
22
System overview
Rear speaker
RS IN port RS output
Rear speaker
Power
input (Rear
Speaker)
AC adapter
(Rear Speaker)
Subwoofer
Soundbar
Remote control
Power button
Volume increase button
Previous button
EQ button
Mode button
Bluetooth button
Bass increase button
Bass decrease button
3D button
Mute button
Play/pause button
Next button
Volume decrease button
Track control button
Treble increase button
Treble decrease button
Remote control
Name Icon Description
Power button
Press this button to turn the soundbar on/off
Mute button
Press this button to mute/unmute the
soundbar.
Volume increase button VOL+ Press this button to increase the volume.
Volume decrease
button VOL- Press this button to decrease the volume.
Play/pause button
Press this button to play/pause tracks.
Previous button
Press this button to play the previous track.
Next button
Press this button to play the next track.
Mode button MODE
Press this button to switch between the
connection modes (HDMI ARC, Optical,
AUX, Coaxial, USB, Bluetooth, HDMI IN)
EQ button EQ Press this button to switch between the
equaliser modes (Music, Movie, News).
Track control button
When in USB mode, press this button to
switch between the track controls.
Bass increase button BASS + Press this button to increase the bass
(up to +5).
Bass decrease button BASS – Press this button to decrease the bass
(up to –5).
Bluetooth button BT Press this button to activate Bluetooth
mode on the soundbar.
3D button 3D Press this button to activate the 3D audio
mode.
Treble increase button TREBLE + Press this button to increase the treble
(up to +5).
Treble decrease button TREBLE – Press this button to decrease the treble
(up to –5).
OPERATION
Powering
1. Plug one end of the power cords for the soundbar and subwoofer into the AC IN ports
on both devices, then plug the other end into two power sockets. Switch the power
sockets on.
2. Place the power switch in the ON position on both the subwoofer and soundbar.
3. Plug one end of the provided AC adapter into the DC IN port of the left speaker, then
plug the other end into a power socket. Switch the power socket on.
4. Press the power button on the soundbar or remote control to turn the soundbar on.
5. Press the power button again to turn the soundbar off.
Connection modes
This soundbar features seven connection modes. The display on the front of the soundbar
will change when switching between modes.
HDMI ARC mode
This soundbar supports HDMI with an audio return channel (ARC). Many standard HDMI
ports support ARC but if unsure, check with the TV’s manufacturer. This allows the sound
from a TV to emit through the soundbar rather than the TV’s inbuilt speakers.
1. Connect one end of an HDMI cable (not supplied) into the HDMI OUT (ARC) port of the
soundbar. Connect the other end of the cable into your TV’s HDMI (ARC) port.
2. Press the mode button on the soundbar or remote control and change the soundbar to
HDMI ARC mode.
3. Ensure ‘HDMI ARC’ is selected as the TV’s audio output and the sound of media from
the TV should emit from the soundbar.
4. Use the remote control/soundbar to make audio adjustments.
Connection mode Display shows
HDMI ARC ARC/EARC
Optical OPT
AUX AUX
Coaxial COA
USB USB
Bluetooth BT
HDMI IN HDMI
