2.4G WIRELESS KEYBOARD &
MOUSE COMBO
KAWSKBMSCBA
Step 1:
Open the battery case and turn the power switch to “ON”.
Insert the battery, ensuring to correctly align the positive and negative terminals.
Step 2:
Remove the USB receiver from the mouse.
INSTALLATION
Step 3:
Insert the receiver into your computer’s USB port.
USB
Note:
It may take a few minutes for the mouse to be usable as required drivers may
automatically install to facilitate usage.
1x Wireless keyboard 1x Wireless
mouse 1x Nano
receiver 2x AA alkaline
battery User Guide
1. Check the battery. If it is drained, replace it.
2. Disconnect and reconnect the USB dongle to establish a new connection.
3. Move to mouse closer to the receiver if it is out of the optimum range.
Reconnecting the USB dongle
1. Insert the battery and turn on the power
2. Press the left, middle, and right mouse buttons at the same time.
3. Let go of the buttons, then insert the dongle to the computer’s USB port.
4. Place the mouse near the computer when the dongle is inserted.
IN THE BOX
TROUBLESHOOTING
Mouse
Mouse size 100x 60x 40mm
Mouse weight 50g
Functions 2 standard buttons and 1 scroll wheel
Sensitivity 1600dpi
Mouse return rate 250Hz
Mouse button life ~3 million presses
Transmission distance ≥20m
Power saving mode Mode 1: ≈0.5±0.2mA
Mode 2: 1min≈50μA
Mode 3: 30min≈30μA
Keyboard
Keyboard size 447.7 x 135.75 x 22.1mm
Keyboard weight 467g
Functions 104 keys + Multimedia keys
Keyboard key life ~10 million presses
Power saving mode Mode 1: ≈1.5mA
Mode 2: 1min≈50μA
Mode 3: 30min≈20μA
System requirements
IBM or compatible computer
Windows: 2000/ME/XP(x64)/Vista/7/8/10
Mac OS X V10.4 or later
Usable USB port
SPECIFICATIONS
NOTES
Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
