KOGAN SMARTERHOME™ FULL HD SLIM WIRELESS
SMART VIDEO DOORBELL WITH CHIME
KAFHDSLDBELA
Component
Description
Speaker
Audio output
Lens
Video capture
Infrared LED
Additional light in low-light conditions
Light Sensor
Light sensor
Indicator light
Status Indicator light shows the doorbell’s status
Doorbell button
You will receive notification from the mobile app when it’s pressed
Microphone
Detects sound for the mobile App
OVERVIEW
Microphone
Lens
Light sensor
Motion sensor (PIR)
Ring button
Component
Description
CE Label
Product label
Reset
By pressing the reset button on the back of the device for more than 3
seconds, you will hear a sound and see the indicator light blinking red.
(Be advised that all your data on the device will be reset to default)
Alarm button Tamper alarm
USB Port
Connect to charge the doorbell
Power Switch Power OFF/ON
ON/OFF
Reset
USB slot
TF card
Method 1
Step 1: Stick the double-sided 3m stickers on the bracket.
Ac Plug
Volume Control
Back Button
Forward Button
Speaker
INSTALLATION
Step 2: Tear off the protective film on the 3m stickers, apply it on a smooth wall surface at
the appropriate height. Hang the device on the bracket from the top-down lining up the hole
at the back of the device. Tighten the screw on the bottom of the unit to the bracket.
Method 2
If you want to install the device on a rough wall (such as concrete, brick or a wooden
surface), use screws to fix the bracket.
❶Set the bracket on the wall according to the required height by screws.
❷Hang the device on the bracket from the top-down lining up the hole at the back of the
device. Tighten the screw on the bottom of the unit to the bracket.
Install App
Download the “Kogan SmarterHome” app from the Play Store (Android) or App Store (iOS).
Register
If you do not have a Kogan SmarterHome™ account, register or sign in with a verification
code sent by SMS.
To register:
1. Tap to enter registration page.
The system automatically recognises your country/area. You can also select your
country code manually. Enter your email address and tap ‘Next.’
Alternatively, you can select ‘Register by mobile number’ and enter the verification code
sent to you by SMS.
Create a profile on the next page to define your location and room.
CONNECT TO SMARTERHOME™ APP
Set device in pairing mode
When the device is first turned on, it may automatically enter pairing mode and the blue
light will blink quickly.
If not automatically in pairing mode when powered on, you can manually set the device in
pairing mode by holding the reset button for five seconds until the light flashes blue rapidly.
Using Smart Mode to add device
Once registered, tap “+” in the upper right corner of the app’s home page to add a new
device through the network.
Select the product type from the list of options in the app Home Security > Door Bells,
and then select “Other Mode” from the top-right corner when asked to reset the
device.
Select “Smart Mode” for the set-up type.
Ensure that the device is in pairing mode, and tap “Confirm light is rapidly flashing”.
Upon successfully confirming pairing mode, enter your Wi-Fi details. It is important that your
SmarterHome™ device and the app are connected to the same Wi-Fi network during setup.
The device will commence the pairing process and connect to the app. Ensure your Wi-
Fi router, mobile phone, and the SmarterHome™ device are kept close until
connection is complete.
After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.
Notes:
•The device and the app have to use the same Wi-Fi network.
•The device is only compatible with 2.4Ghz networks.
