Installation Manual
Scan Me
PLAY VIDEO
2
Read instructions carefully before
assembling and installing
Use caution when handling the Kleen Opener during
unpacking, assembly, and installation. Kleen Opener has
metal edges that can cause harm.
Misuse of this product can cause breakage and/or personal
harm.
DO NOT USE KLEEN OPENER TO MOVE DUMPSTER
For questions or comments please call us at:
1-(818)-280-3907
or E-Mail Us at:
owner@rmfresh.com
3
Components Shipped
With Kleen Opener Kits
This manual uses a Right
Side kit as an example. All
information and steps apply
to Left Side kits as well.
When shipped the
Kleen Opener is partially
disassembled.
Your Right Side kit comes with three tubes - the larger adapter tube attached to the
mounting bracket, the intermediate tube, and the end tube with the eyelet bolt.
Each kit comes with two orange pull down straps.
Make sure your kit(s) come with coordinating left vs right side tubes. Tubes are labeled
accordingly.
DO NOT REMOVE THE NYLON TIE UNTIL INSTRUCTED
For your safety leave the nylon tie attached to the mounting bracket. This holds the gas spring and
arm in place while you mount. Removing the tie before instructed can lead to injury.
Adapter Tube
Intermediate Tube
Eyelet Bolt
End Tube
Pull Down Straps
Mounting Bracket
DO NOT REMOVE
Other components to note are
the clamp bolts and gas spring.
Gas Spring (black)
Clamp Bolts
Extras Included with the Kleen Opener Kit:
• Threadlocker
• 2 extra orange pull down straps for a longer reach
• Bag of Extras:
- four 1/4” x 1” Clamp Bolts
- four longer 1/2” x 1 3/4” Mounting Bolts
- four Nylon Lock Nuts with Flange
TOOLS NEEDED FOR INSTALLATION not included
(These items come in our Installation Tool Kit for purchase on kleenopener.com)
• 3/8 in. ratchet
• 3/4 in. socket
• 7/16 in. socket
4
General Installation:
Assembling the Arm
1
2
3
Take the larger
adapter tube and the
intermediate tube.
Make sure they are
both labeled Right
Side (or Left Side when
mounting for the left side
dumpster)
Simply slide the
intermediate tube into
the adapter tube.
Insert intermediate tube
until the clamp bolts
meet with a small gap as
shown.
Do not tighten clamp
bolts until instructed.
Adapter Tube
Intermediate Tube
5
General Installation:
Mounting the Bracket
5
Up to 8 inches
Now it is time to mount your Kleen
Opener.
First place the mounting bracket on the
dumpster top rail. The arm should be
inside the dumpster with the mounting
bolts on the outside as shown.
It is easiest to hold the Kleen Opener with
your left hand.
Make sure the bracket is resting at
against the top rail.
The mounting bracket should be placed
anywhere from 1/2 inch up to 8 inches
from the back rail of the dumpster where
the hinge of the lid is located.
Smaller dumpsters can mount between 1/2
in to 4 inches from the back rail. For larger
dumpsters with long lids, mount between 4
to 8 inches from the back rail.
4
First make sure you are on the correct side
of the dumpster. Left Side and Right Side
are determined when facing the front of
the dumpster.
Manually open the lid before installation. LEFT SIDE RIGHT SIDE
This manual shows a general installation with a metal angled mount. There are
four dierent mount types based on dumpster material and conguration. To nd
mount specic instructions to match your dumpster see pages 11-13.
TOP RAIL
General Installation:
Mounting the Bracket
6
7
8
Use the 3/4 in. socket on the ratchet
to tighten the mounting bolts.
Alternate between each bolt as you
tighten.
Turn until both bolts are FIRM and
SNUG.
6
First hand tighten the mounting bolts to
steady the Kleen Opener on the top rail.
Then put a couple of drops of
Threadlocker on the mounting bolt as
shown.
YOU CAN NOW SAFELY REMOVE THE
NYLON TIE
with cutting tool, scissiors, or wire
cutters (not provided)
General Installation:
Adjusting Arm Length
9
10
11
Now it is time to adjust the length of the
arm.
Pull on the intermediate tube and end tube
with eyelet bolt to slide out arms.
Adjust the tubes so they are evenly spaced.
Leave at least a 1-2 inch gap
between the end of the eyelet
bolt and the front rail.
The eyelet bolt should be facing
up and down, meaning you
would not see the open circle
when looking from above (as
seen to the left)
1-2 INCH GAP
7
General Installation:
Secure Arm Length
12
13
14
Next you will secure the length of the
arm.
Use the 7/16 in. socket on the ratchet.
First raise the arm slightly while
holding in place. Use caution as the
gas spring will want to raise the arm
automatically.
Use the ratchet (with 7/16 in. socket)
to tighten the clamp bolts.
Make sure to tighten until the gap
closes.
Use the ratchet to secure both
clamp bolts. Make sure the
gap closes on each clamp bolt.
Tighten until both bolts are
secure and the intermediate and
end tubes cannot be twisted or
moved by hand.
CLOSE GAP
8
15
16
17
To attach the straps pull one end
through the eyelet bolt to create
a loop.
Pull the other end of the strap
through the loop.
Pull the strap through until
you see the knot form on the
eyelet bolt.
For longer reach you can
attach the extra strap to the
rst strap using this same
process.
General Installation:
Attach Straps
9
18
19
20
Pull up on the strap to lift the arm of the Kleen Opener. Then
manually close the dumpster lid onto the arm. Pull down on the strap
to close the lid.
To operate your Kleen Opener simply
lift up the orange strap 6-8 inches
until the gas spring arm takes over
and lifts the lid open.
To close the dumpster lid pull
down on the orange strap. Pull
down until the dumpster’s lid
closes completely. Let go of
the strap. Your dumpster lid
will remain closed.
Operational Instructions
10
