KitchenAid KFCO22EV Manuel utilisateur

PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS

LOCATION REQUIREMENTS

KFCO22EV KFCS22EV

Electrical Requirements: A 115 Volt, 60 Hz.,

AC only 15- or 20-amp fused, grounded electrical

supply is required. It is recommended that a

separate circuit serving only your refrigerator be

provided. Use an outlet that cannot be turned

off by a switch. Do not use an extension cord,

2-prong adapter or power strip.

NOTE: Before performing any type of installation,

cleaning or removing a light bulb, turn Cooling

OFF, and then disconnect the refrigerator from the

electrical source. When you are finished, reconnect

the refrigerator to the electrical source and turn

Cooling ON.

Water Supply Requirements: Connect the ice

maker to a cold water line with water pressure

between 35 and 120 psi (241 and 827 kPa).

IMPORTANT: The pressure of the water coming

out of a reverse osmosis system going to the

water inlet valve of the refrigerator needs to be

between 35 and 120 psi (241 and 827 kPa).

If a reverse osmosis water filtration system is

connected to your cold water supply, the water

pressure to the system needs to be a minimum of

approximately 40 to 60 psi (276 to 414 kPa).

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. 12828187

07-01-08

2-1/2" (6.3 cm)

1/2"

(1.25 cm)

overall

top of

cabinet

not incl.

handle

incl.

handle

Model # Depth Cab. Width Cab. Height Overall Height Depth

"A" "B" "C" "D" "E"

KFCO22EV 27-5/8" 35-5/8" 70-7/8" 71-7/8" 30-1/8"

(70.17 cm) (90.49 cm) (180.02 cm) (182.56 cm) (76.52 cm)

KFCS22EV 27-5/8" 35-5/8" 70-7/8" 71-7/8" 30-1/8"

(70.17 cm) (90.49 cm) (180.02 cm) (182.56 cm) (76.52 cm)

To ensure proper ventilation for your refrigerator,

allow for a 1/2" (1.25 cm) space at the top and behind

the refrigerator. If your refrigerator has an ice maker,

allow extra space at the back for the water line

connections. When installing your refrigerator next to

a fixed wall, leave 2-1/2" (6.3 cm) minimum on both

sides (some models require more) to allow for the

doors to swing open.

NOTE: It is recommended that you do not install the

refrigerator near an oven, radiator, or other heat

source. Do not install the refrigerator in a location

where the temperature will fall below 55°F (13°C).

French Door Refrigerator
