ruse and Care Guide

KitchenAid*

Table of Contents

(complete) ................. 2

A Note to You ............... 3

Range Safety ............. 4-6

Getting to Know

Your Range .................. 7

Using and Caring for

Your Cooktop ............. 11

Using and Caring for

Your Oven .................. 18

Using EASY

CONVECT*

Conversion .............. 36

Using the

Self-Cleaning Cycle ... 51

Troubleshooting ........ 55

Requesting Assistance

or Service .................... 57

Index ........................... 62

Warranty ..................... 64

In the U.S.A. for assistance or service,

call the Consumer Assistance Center:

1-800-422-1230

In Canada for assistance or service,

see page 58.

KITCHENAID*THERMAL-CONVECTION*

Electric Ranges

Models: KESC307 KESH307 KERC607

PART NO. 9751685 Rev. E YKESC307 YKESH307 YKERC607

-able of Contents

A Note to You ............................................ 3

Range Safety ......................................... 4-6

Getting to Know Your Range ................... 7

Feature locations ................................. 7

The oven vent ....................................... 9

The storage drawer ............................... 9

The anti-tip bracket ............................. 10

Using and Caring for Your Cooktop ...... 11

Using the surface units ....................... 11

Cookware tips ..................................... 13

Caring for your cooktop ....................... 14

Using and replacing the surface light ... 16

Using and Caring for Your Oven ............ 18

Using the electronicoven control ........ 18

Oven settings ..................................... 21

Setting the clock ................................. 22

Using the timer ................................... 22

Baking or convection baking ............... 24

Roasting ............................................. 25

Cooking tips ........................................ 27

Adjusting oven temperature ................ 30

Using the temperature probe ............... 31

Using Convect Full Meal ..................... 33

Using EASY CONVECT*

Conversion ......................................... 36

Broiling ............................................... 38

Convection broiling ............................. 40

Timed cooking .................................... 43

Dehydrating ........................................ 46

Raising (proofing) bread ...................... 47

Cleaning your oven and controls ......... 48

Using and replacing the oven light(s)... 50

Using the Self-Cleaning Cycle ............... 51

Before you start .................................. 51

Before setting the controls................... 52

Setting the controls ............................. 52

For best cleaning results..................... 54

How the cycle works ........................... 54

Troubleshooting ...................................... 55

Requesting Assistance or Service ......... 57

Index ........................................................ 62

Warranty .................................................. 64

mNote to You

_nkyou for buying a KITCHENAID* appliance!

KitchenAid designs the best tools for the most important room in your house. To ensure

that you enjoy many years of trouble-free operation, we developed this Use and Care

Guide. It contains valuable information concerning how to operate and maintain your

new appliance properly and safely. Please read it carefully.

Also, please complete and mail the enclosed Product Registration Card.

If you need assistance or service, first see the "Troubleshooting" section of this book.

After checking "Troubleshooting," additional help can be found by checking the

"Requesting Assistance or Service" section.

When calling, you will need to know your appliance's complete model number and

serial number. You can find this information on the model and serial number plate

(see diagrams on pages 7 or 8).

Keep this book and the sales slip together in a safe place for future reference. You

must provide proof of purchase or Installation date for in-warranty service.

Model Number Builder/Dealer Name

Serial Number Address

Date Installed Phone

nge Safety

IMPORTANTSAFETYINSTRUCTIONS

Your safety is important to us.

This guide contains safety symbols and

statements. Please pay special attention to

these symbols and follow any instructions

given. Here is a brief explanation of the use

of the symbol.

General

This symbol alerts you to

hazards such as fire,

electrical shock, or

other injuries.

To reduce the risk of fire, electrical

shock, injury to persons, or damage

when using the range, follow basic

precautions, including the following:

• Read all instructions before using

the range.

• Install or locate the range only

in accordance with the provided

Installation Instructions. The

range must be installed by a

qualified installer. The range must

be properly connected to electri-

cal supply and grounded.

•WARNING: To reduce the risk

of tipping the appliance, the

appliance must be secured by a

properly installed anti-tip bracket.

To check if the bracket is installed

properly, see "The anti-tip bracket"

on page 10.

• CAUTION: Do not siore things

children might want above the

range. Children could be burned

or injured while climbing on it.

• Do not leave children alone or

unattended in area where the

range is in use. They should

never be allowed to sit or stand

on any part of the range. They

could be burned or injured.

•Do not use the range for warming

or heating the room. Persons could

be burned or injured, or a fire could

start.

• Use the range only for its intended

use as described in this manual.

• Do not touch surface units, areas

near units, heating elements, or

interior surfaces of oven. Surface

units and heating elements may

be hot even though they are dark

in color. Areas near surface units

and interior surfaces of an oven be-

come hot enough to cause burns.

During and after use, do not touch,

or let clothing or other flammable

materials contact surface units,

areas near units, heating elements,

or interior surfaces of oven until

they have had sufficient time to

cool. Other surfaces of the range,

such as the oven vent opening, the

surface near the vent opening, the

cooktop, and the oven door and

window, could also become hot

enough to cause burns.

nge Safety

*Do not operate the range if it is

damaged or not working properly.

oDo not wear loose or hanging

garments when using the range.

They could ignite if they touch a

hot surface unit and you could

be burned.

*Use only dry pot holders. Moist or

damp pot holders on hot surfaces

could result in burns from steam.

Do not let pot holder touch hot

heating elements. Do not use a

towel or bulky cloth for a pot

holder. It could catch on fire.

*Keep range vents unobstructed.

*Do not heat unopened containers.

They could explode. The hot

contents could cause burns and

container particles could cause

injury.

.Use only cookware approved for

oven use. Follow cookware manu-

facturer's instructions, especially

when using glass or plastic

cookware.

.Do not store flammable materials

on or near the range. The fumes

could create an explosion and/or

fire hazard.

*Do not repair or replace any part

of the range unless specifically

recommended in this manual. All

other servicing should be referred

to a qualified technician.

oDisconnect the electrical supply

before servicing the range.

When using the cooktop

.Do not cook on a broken ceramic

glass cooktop. If cooktop should

break, cleaning solutions and

spillovers could penetrate the

broken cooktop and create a risk

of electrical shock. Contact a

qualified technician immediately.

*Select a pan with a flat bottom

that is about the same size as the

surface unit. If pan is smaller than

the surface unit, some of the

heating element will be exposed

and could result in the igniting of

clothing or pot holders. Correct

pan size also improves cooking

efficiency.

*Check to be sure glass cookware

is safe for use on the range. Only

certain types of glass, glass-

ceramic, ceramic, earthenware,

or other glazed cookware are

suitable for cooktops without

breaking due to the sudden

change in temperature.

*Never leave surface units un-

attended at high heat settings.

A boilover could result and cause

smoking and greasy spillovers

that could ignite.

oTurn pan handles inward, but not

over other surface units. This will

help reduce the chance of burns,

igniting of flammable materials,

and spills due to bumping of

the pan.

continued on next page

_ange Safety

*Grease is flammable. Do not

allow grease to collect around

cooktop or in vents. Wipe spill-

overs immediately.

*Do not use water on grease fires.

Never pick up a flaming pan.

Smother flaming pan on range

by covering with a well-fitting lid,

cookie sheet, or flat tray. Flaming

grease outside of pan can be

extinguished with baking soda

or, if available, a multipurpose

dry chemical or foam-type

extinguisher.

*Clean ceramic glass cooktop

with care. Some cleaners could

produce noxious fumes if applied

to a hot surface. If a wet paper

towel is used to wipe spills on a

hot cooking area, be careful to

avoid steam burns.

When using the oven

•Always position oven rack(s) in

desired location while oven is

cool. If a rack must be removed

while oven is hot, do not let pot

holder contact hot heating ele-

ments in oven.

• Use care when opening oven door.

Let hot air or steam escape before

removing or replacing food.

*Small amounts of formaldehyde

and carbon monoxide are given

off in the Self-Cleaning cycle from

fiberglass insulation and food

decomposition. Significant expo-

sure to these substances could

cause cancer or reproductive

harm. Exposure can be minimized

by venting with a hood or open

window and wiping out excess

food spills prior to self-cleaning.

• Do not use oven cleaners. No

commercial oven cleaner or oven

liner protective coating of any kind

should be used in or around any

part of the oven.

*Before self-cleaning the oven,

remove broiler pan, broiler grid,

oven racks, and other cookware.

Do not use your oven to clean

miscellaneous parts unless you

are instructed to do so in this Use

and Care Guide.

• Do not clean door gasket. It is

essential for a good seal. Care

should be taken not to rub, dam-

age, or move the gasket. Clean

only parts recommended in this

Use and Care Guide.

-SAVE THESEINSTRUCTIONS-

etting to Know Your Range

This section tells you what features your range has and where they are located. It

also discusses some convenience features that you should know about, but which

are not needed to operate the range. Please review this information before using

your range. To help you find information on specific parts or features quickly, page

references are included.

Feature locations

(Slide-in models)

Oven vent

(p. 9)

Surface unit controls

(p. 11)

(pp. 11 and 14)

(p. 18)

Automatic

Model and oven light

aerial number switch

plate (p. 50)

(p. 3) Broil element

Anti-tip bracket (not shown)

(p. 10) (p. 21)

Removable storage Bake element

drawer (p. 21)

(p. 9)

Surface unit controls

Left rear Left front Right front Right rear

control knob control knob control knob control knob

(pp. 11 and 48) (pp, 11 and 48) (pp. 11 and 48) (pp. 11 and 48)

Getting to Know Your Range

(Freestanding models)

Surface Iigl

(p. 16)

Oven ven

(p. 9)

Surface unit

controls

(p. 11)

Anti-tip •

brac ket

(p. 10)

Model and

serial number

(p. 3)

Removable

storage drawer,

(p. 9)

Surface unit

(pp. 11 and 14)

Electronic oven

control

(p.18)

Automatic oven

light switch

(p. 50)

Broil element

(not shown)

(p. 21)

element

(p. 21)

Surface unit controls

Left rear Left front

control knob control knob

(pp. ! 1 and 48) (pp. 11 and 48)

Right front

control knob

(pp. 11 and 48)

Right rear

control knob

(pp. 11 and 48)

Getting to Know Your Range

The oven vent

Oven vent

Hot air and moisture escape from the oven

through a vent in the left rear corner of the

cooktop. Do not block the vent by using

large pans or covers. Poor baking/roasting _

can result.

NOTE: Plastic utensils left over the vent

can melt.

The storage drawer

You can remove the storage drawer to make

it easier to clean under the range and to

check for installation of the anti-tip bracket.

Use care when handling the drawer.

Removing the storage drawer:

1. Empty drawer of any pots and pans

before removing drawer. Use recessed

area on top edge of drawer to pull drawer

straight out to the first stop. Lift front and

pull out to the second stop.

2. Lift back slightly and slide drawer all the

way out.

Burn Hazard

Use pot holders when touching Items

left near oven vent.

Failure to do so can result in burns.

Replacing the storage drawer:

Drawer slide

rail

1. Fit ends of drawer slide rails into the

drawer guides on both sides of opening.

2. Lift drawer front and press in until metal

stops on drawer slide rails clear white

stops on drawer guides. Lift drawer front

again to clear second stop and slide

drawer closed.

Getting to Know Your Range

The anti-tip bracket

The range will not tip during normal use. However, tipping can occur if you apply too much

force or weight to the open door without the anti-tip bracket properly secured.

Tip Over Hazard

Connect anti-tip bracket to the range.

Reconnect anti-tip bracket, if the range is moved.

Do not push down on the open oven door.

Follow the Installation Instructions.

Do not let children climb onto the oven door.

Failure to follow these instructions can result in death, burns,

or other injury.

To verify the anti-tip bracket is

engaged:

Rear

leveling

foot

•Remove the storage drawer. (See page 9.)

• Look to see if the anti-tip bracket is attached

to floor with screws.

•Make sure left rear leveling foot is positioned

under the anti-tip bracket.

•See Installation Instructions for further details.

Autres manuels pour KESC307

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels KitchenAid Gamme

KitchenAid

KitchenAid KDRS407 Manuel utilisateur

KitchenAid

KitchenAid KDRP462L Instructions d'utilisation

KitchenAid

KitchenAid KEDS200Y Manuel utilisateur

KitchenAid

KitchenAid KESC300BAL4 Manuel utilisateur

KitchenAid

KitchenAid KESC307 Manuel utilisateur

KitchenAid

KitchenAid KFED500EBS Manuel utilisateur

KitchenAid

KitchenAid YKFID500ESS Manuel utilisateur

KitchenAid

KitchenAid KERS507 Manuel utilisateur

KitchenAid

KitchenAid KAC-29 Manuel utilisateur

KitchenAid

KitchenAid KERI500 Manuel utilisateur

KitchenAid

KitchenAid KDRP407HBU09 Manuel utilisateur

KitchenAid

KitchenAid 9761936 Manuel utilisateur

KitchenAid

KitchenAid ARCHITECT SERIES II Manuel utilisateur

KitchenAid

KitchenAid KERA205PBL Manuel d'utilisation et d'entretien

KitchenAid

KitchenAid KERS202B Manuel de la liste des pièces

KitchenAid

KitchenAid KERS807SBL - 30 Inch Electric Range Manuel utilisateur

KitchenAid

KitchenAid YKFED500EBS Manuel utilisateur

KitchenAid

KitchenAid Architect II KDRS505XSS Manuel utilisateur

KitchenAid

KitchenAid KGRS308XSS Manuel utilisateur

KitchenAid

KitchenAid ARCHITECT II KERS206X Manuel utilisateur

KitchenAid

KitchenAid Thermal-Convection 9751683 Manuel utilisateur

KitchenAid

KitchenAid W10113902A Manuel utilisateur

KitchenAid

KitchenAid Thermal-Convection KGRT507B Manuel utilisateur

KitchenAid

KitchenAid YKFEG500ESS Manuel utilisateur

Manuels Gamme populaires d'autres marques

Samsung

Samsung FCQ321HTUW Manuel utilisateur

Kenmore

Kenmore 790.45712 Manuel utilisateur

Wolf

Wolf CHR CHSSR Manuel utilisateur

Smeg

Smeg Built-in Microwave Oven Mode d’emploi

Zanussi

Zanussi ZCG054G Manuel utilisateur

Whirlpool

Whirlpool 8575985-W Manuel de la liste des pièces

Frigidaire

Frigidaire 316000635 Manuel utilisateur

GE JCSS630 Manuel utilisateur

Samsung

Samsung NX58M9960P series Manuel utilisateur

Hotpoint

Hotpoint RB524R Guide d'installation

Whirlpool

Whirlpool Roper FGP305KW3 Manuel utilisateur

Amana

Amana ART6610 SERIES Manuel utilisateur

Maytag

Maytag MERH770WB Manuel utilisateur

Fulgor Milano

Fulgor Milano SOFIA Manuel utilisateur

Premier

Premier EF-4358GH Manuel utilisateur

Kenmore

Kenmore 790.9010 Series Manuel utilisateur

Frigidaire

Frigidaire FFEF3012LS Guide de l'utilisateur

Diamond

Diamond G65/2F4T Manuel utilisateur
