Thanks for choosing

Cooking gestures are

invisible ingredients.

They turninspiration

into emotions and

emotionsinto a

masterpiece.

It’s all about artisanality,

that’s why we take it so

seriously.

QuickReference Guide

Index

EN ��page 3

KitchenAid

Induction Hob

Quick reference guide

Thanks for choosing

Cooking gestures are

invisible ingredients.

They turn inspiration

into emotions and

emotions into a

masterpiece.

It’s all about artisanality

that’s why we take it so

seriously.

1. Hob

2. Control panel

Quick Guide

THANK YOU FOR BUYING A KITCHENAID

PRODUCT

In order to receive a more complete assistance, please

Before using the appliance

carefully read the Safety

Instruction.

Control Panel

Product description

12 11 13

2 5

4 14 144

4 48 9 8

3 10

MaxMinMed

Oﬀ

1. Identifying the cooking

zone

2. Cooking zone off button

3. Cooking level selected

4. Indicator light - function

active

5. Quick heat button

6. Special function indicators

7. On/ off button

8. Cooking time indicator

9. “Gourmet Library” button

(special functions)

10. OK/ Key lock button - 3

secs

11. Slide touchscreen

12. Vertical exible zone

button

13. Timer

14. Timer indicator

Example of cooking zone

POTS AND PANS

Only use pots and pans made from ferromagnetic material which are suitable for

use with induction hobs� To determine whether a pot is suitable, check for the

symbol (usually stamped on the bottom)� A magnet may be used to check

whether pots are magnetic�

The quality and the structure of the pot base can alter cooking performance�

Some indications for the diameter of the base do not correspond to the actual diameter of the

ferromagnetic surface�

EMPTY POTS OR POTS WITH A THIN BASE

Do not use empty pots or pans when the hob is on�

The hob is equipped with an internal safety system that constantly monitors the temperature, activating

the “automatic off” function where high temperatures are detected� When used with empty pots or

pots with thin bases, the temperature may rise very quickly, and the “automatic off” function may be

triggered with a slight delay, damaging the pot or pan� If this occurs, do not touch anything, and wait

for all components to cool down�

If any error messages appear, call the service centre�

MINIMUM DIAMETER OF POT/PAN BASE FOR THE DIFFERENT COOKING AREAS

160 mm 130 mm 180 mm

NOOK

SETTING THE POWER

At the time of purchase, the hob is set to the maximum possible power (nL)� The maximum power level

(nL) is printed on the identication plate on the bottom of the hob.

To set the power of the hob:

Once you have connected the device to the mains power supply, you can set the power level within 60 seconds�

• Press the “+” button for at least 3 seconds� On the screen, the symbol will be displayed�

• Press the button until the last power level selected appears�

• Use the “+” and “–” buttons to select the desired power level�

The power levels available are: 2�5 kW – 4�0 kW – 6�0 kW – 7�2 kW�

• Conrm by pressing

�

The power level selected will stay in the memory even if the power supply is interrupted�

To change the power level, disconnect the appliance from the mains for at least 60 seconds, then plug

it back in and repeat the steps above�

If an error occurs during the setting sequence, the symbol will appear, and you will hear a beep� If

this happens, repeat the operation�

If the error persists, contact the After-Sales Service�

First time use

Accessories

TURNING THE BEEP ON/OFF

To activate/deactivate the beep:

• Switch on the hob�

• Press the

button on the rst left-hand slide touchscreen for 3 seconds.

Any alarms set will remain active�

SWITCHING THE HOB ON/OFF

To turn the hob on, press the power button for around 1 second� To turn the hob off, press the same

button again, and all cooking zones will be deactivated�

POSITIONING

Locate the desired cooking zone by referring to the position symbols at the bottom of each slide touchscreen�

Do not cover the control panel symbols with the cooking pot�

Please note: In the cooking zones close to the control panel, it is advisable to keep pots and pans inside

the markings (taking both the bottom of the pan and the upper edge into consideration, as this tends

to be larger)�

This prevents excessive overheating of the touchpad� When grilling or frying, please use the rear

cooking zones wherever possible�

ACTIVATING/DEACTIVATING COOKING ZONES AND ADJUSTING POWER LEVELS

O

To activate the cooking zones:

Move your nger horizontally across the slide touchscreen (SLIDER) of the cooking area you have

selected� Above the slide touchscreen, the corresponding power level will appear� Using the slide

touchscreen, you can also select the quick heating function (

)�

To deactivate the cooking zones:

Select the “OFF” button on the top of the slide touchscreen�

CONTROL PANEL LOCK

To clean the hob, lock the settings and prevent it being switched on accidentally, press and hold the

OK/lock button for 3 seconds� A beep and a warning light above the symbol indicate that this function

has been activated� The control panel is locked, with the exception of the “off” function� To unlock the

controls, repeat the activation procedure�

TIMER

There are two timers - one controls the left-hand cooking zones, while the other controls the right-hand

cooking zones�

To activate the timer:

Press the “+” or “–” button to set the desired time on the cooking zone in use� Once the set time has

elapsed, a beep will sound, and the cooking zone will switch off automatically�

The time can be changed at any point.

Daily use

To deactivate the timer:

Press the “+” or “–” buttons together until the timer is deactivated�

FLEXIBLE ZONE

The entire left-hand area can be controlled as a single cooking zone using the “Flexible Zone” button�

Either of the slide touchscreens can be used. Ideal for cooking with oval or rectangular pots or with pan

supports�

GOURMET LIBRARY

The “Gourmet Library” button activates the special functions�

Place the pot in position and select the cooking zone�

Press the “Gourmet Library” button� “A” will appear on the display�

The indicator for the rst special feature available for the cooking zone will light up.

Select the desired special function by pressing the “Gourmet Library” button one or more times�

The function is activated once the

button has been pressed to conrm.

KEEP WARM

This feature allows you to keep your food at an ideal temperature, usually after cooking is complete, or

when reducing liquids very slowly� Ideal for serving foods at the perfect temperature�

SLOW COOKING

This function is ideal for maintaining a simmering temperature, allowing you to cook food for long

periods with no risk of burning� Ideal for long-cooking recipes (rice, sauces, roasts) with liquid sauces�

BOILING

This function allows you to bring water to the boil and keep it boiling, with lower energy consumption�

A minimum of 2 to 3 litres of water (preferably at room temperature) should be placed in the pan, and

left uncovered� In all cases, users are advised to monitor the boiling water closely, and check the amount

of water remaining regularly�

MOKA

Dedicated accessories should be used for this function: Moka, Bialetti MOKA INDUZIONE

6TZ ANTRACITE.

Place the moka on one of the four areas of the exible zone as illustrated. Activate the

function and wait for this to switch off automatically�

MELTING

This function allows you to bring food to the ideal temperature for melting and to maintain the condition

of the food without risk of burning� This method is ideal, as it does not damage delicate foods such as

chocolate, and prevents them from sticking to the pot�

Functions

CHEF CONTROL

This function divides the exible zone into three areas (see gure) and activates

a predened power setting. It allows you to move the pot from one area to

another, so you can continue cooking at different temperatures�

high

low

medium

Indicators

RESIDUAL HEAT

If the display shows “H”, the cooking zone is still hot� When the cooking zone cools down, the display

goes off�

TIMER INDICATOR

This light indicates that the timer has been set for a cooking zone�

POT INCORRECTLY POSITIONED OR MISSING

This symbol appears if the pot is not suitable for induction cooking, is not positioned correctly or is not

of an appropriate size for the cooking zone selected� If no pot is detected within 30 seconds of making

the selection, the cooking zone switches off�

Cooking table

POWER

LEVEL 1 - 4 5 - 9 10 - 14 14 - 18 Max� heat

setting (P)

COOKING

METHOD

Keeping

food warm,

creaming

risotto

Melting,

defrosting

Cooking,

simmering,

thickening,

creaming

Cooking,

stewing,

sautéing,

grilling,

cooking

until

creamy

Browning,

cooking,

stewing,

sautéing,

grilling

Browning,

sautéing,

boiling,

grilling

Frying,

boiling Fast heating

Troubleshooting

• Check that the electricity supply has not been shut off�

• If you are unable to turn the hob off after using it, disconnect it from the power supply�

• If alphanumeric codes appear on the display when the hob is switched on, consult the following

table for instructions�

Please note: The presence of water, liquid spilled from pots or any objects resting on any of the hob

buttons can accidentally activate or deactivate the control panel lock function�

ERROR CODE DESCRIPTION POSSIBLE CAUSE SOLUTION

C81, C82

The control panel switches

off because of excessively

high temperatures�

The internal temperature of

electronic parts is too high�

Wait for the hob to cool

down before using it again�

F02, F04 The connection voltage is

wrong�

The sensor detects a

discrepancy between the

appliance voltage and that of

the mains supply�

Disconnect the hob from

the mains and check the

electrical connection�

F01, F06, F12,

F13, F25, F34,

F35, F36, F37,

F41, F47, F58,

F61, F76

Disconnect the hob from the power supply� Wait a few seconds then reconnect the hob to

the power supply� If the problem persists, call the service centre and specify the error code

that appears on the display�

Maintenance and cleaning

WARNING

• Do not use steam cleaning equipment.

• Before cleaning, make sure the cooking zones are switched off and that the

residual heat indicator (“H”) is not displayed.

Important:

• Do not use abrasive sponges or scouring pads as they may damage the glass�

• After each use, clean the hob (when it is cool) to remove any deposits and stains from food residue�

• Sugar or foods with a high sugar content can damage the hob and must be immediately removed�

• Salt, sugar and sand could scratch the glass surface�

• Use a soft cloth, absorbent kitchen paper or a special hob cleaner (follow the Manufacturer’s

instructions)�

• Spills of liquid in the cooking zones can cause the pots to move or vibrate�

• After cleaning the hob, dry thoroughly�

The hob has been treated with a nish that makes it easy to clean and keeps the surface shiny for a long

time�

To clean Kitchenaid hobs, follow these recommendations:

• Use a soft cloth (microbre is best) dampened with water or with everyday glass cleaning detergent.

• For best results, leave a wet cloth on the glass hob surface for a few minutes�

Sounds produced during operation

Hobs may produce noises during normal operation�

During the pot recognition phase, the hob produces a click sound, while during cooking, hissing or

crackling sounds may be heard� Hisses and crackles actually come from the pots, and are produced by

specic features of the base of the pot being used (for example, when a base is made from several layers

of material, or is irregular)� These noises may vary depending on the accessories used and the amount

of food that these contain, and do not indicate any type of defect�

Please refer to our website www.kitchenaid.eu for complete instructions for use.

In addition, you will find a lot more useful information about your products, such as inspir-

ing recipes created and tested by our brand ambassadors or the nearest KitchenAid cookery

school.

Table des matières

Autres manuels KitchenAid Plaque

KitchenAid

KitchenAid KHDD2 38510 Manuel utilisateur

KitchenAid

KitchenAid KHMP5 77510 Manuel utilisateur

KitchenAid

KitchenAid KHIP4 77510 Manuel utilisateur

KitchenAid

KitchenAid KHID4 65510 Manuel utilisateur

KitchenAid

KitchenAid KHGL 7510 Instructions de montage

KitchenAid

KitchenAid KCGT 6010/I Manuel utilisateur

KitchenAid

KitchenAid KHDP1 38510 Manuel

KitchenAid

KitchenAid KHDD 3020 Manuel utilisateur

KitchenAid

KitchenAid KHGD5 77510 Manuel utilisateur

KitchenAid

KitchenAid KHMF 9010/I Manuel utilisateur

KitchenAid

KitchenAid KHSP5 77510 Manuel utilisateur

KitchenAid

KitchenAid KHGH 7510 Manuel utilisateur

KitchenAid

KitchenAid KHMP5 86510 Manuel utilisateur

KitchenAid

KitchenAid Cooktop Manuel utilisateur

KitchenAid

KitchenAid KHGD4 60510 Manuel utilisateur

KitchenAid

KitchenAid KHCMF 45000 Manuel utilisateur

KitchenAid

KitchenAid KHRT 6010 Manuel utilisateur

KitchenAid

KitchenAid KHGL9010B Manuel utilisateur

KitchenAid

KitchenAid KHPS 9010 Manuel utilisateur

KitchenAid

KitchenAid KHIP5 Manuel utilisateur

KitchenAid

KitchenAid KHIS 7720 Manuel utilisateur

KitchenAid

KitchenAid 2C-1R-2SR -1AUX Manuel utilisateur

KitchenAid

KitchenAid KHIP5 90510 Manuel utilisateur

KitchenAid

KitchenAid KHMS 9010/I Manuel utilisateur

Manuels Plaque populaires d'autres marques

Siemens

Siemens EX875KYV1E Fiche technique

AEG

AEG CERAMIC HOB 6010 K Manuel utilisateur

VALERA

VALERA CT 70A Manuel utilisateur

Zanussi

Zanussi ZGF 6420 Manuel utilisateur

Gaggenau

Gaggenau CI 273 Manuel utilisateur

G3 Ferrari

G3 Ferrari Energy Manuel utilisateur

Pkm

Pkm IN4B Manuel utilisateur

Award

Award H903BG Manuel utilisateur

Zanussi

Zanussi VCH 5005 RZ Manuel utilisateur

Miele

Miele KM 523 Manuel utilisateur

Hotpoint

Hotpoint IS67V8CCXT/E Manuel utilisateur

AEG

AEG HK854870XB Manuel utilisateur

Cookology

Cookology SEP600BK Manuel utilisateur

Bauknecht

Bauknecht Hob Manuel utilisateur

Zanussi

Zanussi ZGM 782 Manuel utilisateur

dipo INDUCTION

dipo INDUCTION DIBK218S Manuel utilisateur

Miele

Miele KM 5987 Manuel utilisateur

Miele

Miele KM 360 G Manuel utilisateur
