Kitchen Idea Cooking Master K2303 Manuel utilisateur
Cooking Master
K2303
Important Safety Instruction
The following safety precautions should always be followed, to reduce the
risk of electric shock, personal injury or fire. It is important to read all of
these instructions carefully before using the product, and to save them for
future reference or new users.
•Appliances can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe
way and if they understand the hazards involved.
•This appliance shall not be used or played by children. Keep the appli-
ance and its cord out of reach of children.
•Take care when handling the sharp cutting blades emptying the bowl and
during cleaning.
•Switch off the appliance and disconnect from supply before changing
accessories or approaching parts that move in use.
•Always disconnect the appliance from the supply if it is left unattended
and before assembling, disassembling or cleaning.
•If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
•Accessories, other than those supplied with the appliance, shall include
instructions for their safe use.
•WARNING: Do not remove the lid while the machine is working.
•The appliance must not be immersed.
•This appliance is intended to be used in household and similar applica-
tions such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
1
•Please put the unit on stable, flat table which will not become hot and
ensure it is in safe distance from the edge to avoid falling down. When it
is used to knead the dough or cut food, the unit may move because of vi-
bration. So please do not use it without supervision of people so as to
avoid the equipment falling down to the floor.
•Please pull out the plug when cleaning the appliance or put it away for a
long time.
•Regularly check whether the main body, jar, steamer or other compo-
nents are damaged or not. The damaged parts will decrease the safety of
use. Once something wrong is found, please stop using and contact our
after sales service center.
•If the appliance stops unexpectedly or appears to malfunction, switch off
the power supply, unplug from the mains and stop using immediately.
Seek professional advice to rectify the fault or make repairs.
•The measuring cup is the only part which can be used to cover the round
hole in the jar lid. Please do not use cloth or similar things to cover the
hole.
•Do not touch the edge of blades. Please be careful and hold the top part
when you assemble or remove the blade.
•Pay attention to the capacity mark on the blender jar.
•Open the lid until the food in the jar stops rotating.
•Pay attention to the high-temperature food when you open the jar lid.
Please put the measuring cup at the hole of jar lid correctly when pro-
cessing food.
•Do not touch the stainless steel jar when processing hot food of more
than 60°C.
•Do not working exceed 2 minutes when at the highest speed levels
8,9,10, suggest to take break 1 minutes to continue cycle working.
•Please press the lid surround firmly to the jar edge then close the lid to
make sure correct lid closed.
2
•Make sure that steamer and the jar are connected well when using
steamer.
•Pay attention that vapor will outflow through the cover top or sides.
•In operation, do not touch any place of the steamer except its handles.
•Do not use the steamer without the steamer lid in place.
•When opening the steamer lid, be careful not to be scalded by vapor.
•When using steaming and boiling setting, pay attention that vapor will
outflow through jar mouth when move the steamer.
•Keep on checking that the vent hole on the steamer lid is unblocked, or
else the vapor may come out somewhere else.
•Please put the appliance and its hot after-use parts in the place which is
out of the children’s reach and warn the children that the unit will become
hot and do not touch it.
•The leakage of food: Make sure that the blade sealing ring is placed well
and the blade assembly is tightly fixed by the fixing bracket on the bottom.
The failure of installation will cause the food leakage which will damage
the appliance.
•Damage of poor ventilation: Ensure that the vents on the back of the
main body are not blocked by any articles, or else the equipment will be
damaged.
•It’s normal that there will be some tiny motor smell in the first few times
use.
•It’s normal that there will stop and noise when changing the speed be-
tween level 5 and 6.
•Keep the connector dry, and avoid water spillage on the connector.
•Clean the stainless steel jug and other components by soft cloth.
•The jug may still hot after use because of the residual heat. Pay attention
not to get burnt.
•Misuse may bring potential injury, please strictly follow the instruction
manual.
3
•Please do not overload in jug when you use high speed working. Liquid
please lower than 1L .
Technical Data
4
Rating AC220-240V~, 50Hz, 1700W；
Motor Power 700W;
Heater Power 1000W;
When opening the packing box, take out all the accessories and get to
know them according to the components list. The spare parts are as fol-
lows:
Package Checking
5
7
1
2
3
4
5
6
Main body
Cooking jar
Jar lid
Measuring cup
Big steamer rack
Big steamer body
7
8
9
10
11
Big steamer cover
Butterfly Whisk
Filter basket (small steamer)
Spatula
Kneading blade
12 Multifunction
6
5
8
2
3
4
1
9
10
11
12
Cooking Jar assembly:
•There are jar capacity marks on one side of the jar. The max capacity for
heaty without blending is 2.3L and 2L for blending.
•Put the lid on the jar, press the lid around firmly to the jar edge and turn
the lid clockwise to fix the lid onto the jar, or else the motor cannot be
started.
Blade assembly:
•Fix the blades on the blade base by the hole, and press it with enough
force for good connection, it should have click voice if connected
sucessfully, turn the blades counterclockwise to make it locked on the
blade base.
•Put the jar onto the main body at the correct direction and sit properly,
or else the machine cannot be started
Accessories
6
Kneading shaft assembly:
•Remove the blade, fix the kneading shaft the same way as fixing the
blade. It can be used for kneading, or stirring and mixing without cutting
the food. Do not use it for speed over 3, otherwise it will cause big vibra-
tion to the machine and cause risk.
7
Spatula:
•The spatula is the only component to be used to scrape the food in the
jar. The other articles may cause damage to the non-stick coating inside
of the jar.
•Do not use it to mix in the jar when the blade is working.
Filter basket:
•Sieve. Filter fruit and Vegetable juice. After grinding or making fruit
sauce with the appliance, put the basket into the jar to help pour out the
juice.
•Stew soft food such as pasta or noodles;
•Cook side dishes, such as rice and potatoes.
Whisk:
•Installed on the blade, the butterfly can help to mix the food but prevent-
ing from cutting by blades, and prevent the food from being adhesive to-
gether and let the food keep on mixing.
8
•Fix the butterfly on the blade assembly by the hole, and press it with
enough force for good connection, turn the butterfly bar counterclockwise
to make it locked on the blade.
•Do not use above speed 4 when using butterfly.
•Do not add ingredients into the jar when the appliance is working with
the butterfly, or the butterfly may be damaged or blocked.
Steamer Assembly:
•Remove the measuring cup, sit the steamer on the jar lid.
•Please make sure that the steamer lid is covered properly before heating
and steaming.
•The steamer cannot be used in microwave oven or other electric appli-
ances.
•Do not touch or get close to the holes of the steamer lid to avoid hurt by
hot steam.
•Do not cover or block the holes of the steamer lid by any articles or else
the steam may come out from the edge or other places and cause danger.
9
