KIRLOSKAR CPHM Manuel de programmation

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 0 | 48 REVISION NO.1

INSTRUCTIONS

INSTALLATION

OPERATION

MAINTENANCE

FOR

TYPE

CPHM

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 1 | 48 REVISION NO.1

KIR OSKAR BROTHERS

IMITED

Udyog Bhavan, Tilak Road, Pune 411 002 (India)

WARRANTY

We warrant that the pump supplied by us is free from defective material and

faulty workmanship. This warranty holds good for a period of 12 months from

the date of commissioning of the equipment or 18 months from the date of

dispatch from our factory, whichever is earlier. Our liability in respect of any

complaint is limited to replacing part/parts free of charge ex-works or repairs of

the defective part/parts only to the extent that such replacement/repairs are

attributable to or arise solely from faulty workmanship or defective material.

The warranty holds good only for the products manufactured by us.

KIR OSKAR BROTHERS IMITED

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 2 | 48 REVISION NO.1

CONTENTS

1. GENERA

2. INSTA ATION

3. OPERATION

4. TECHNICA DATA

5. MAINTENANCE

6. OVERHAU ING

7. PART IST AND CROSS-SECTIONA DRAWING

8. GENERA OUT INE DIMENSIONS OF CPHM PUMPS

CAUTION

THIS INSTRUCTION MANUA COVERS THE GENERA REQUIREMENTS OF

INSTA ATION, OPERATION AND MAINTENANCE. HOWEVER, THE END

USER SHOU D REFER TO THE DRAWINGS AND DOCUMENTS IF SUPP IED

AGAINST SPECIFIC ORDER.

P EASE FURNISH PUMP TYPE, NAME OF THE PART, PART NUMBER,

MATERIA CONSTRUCTION AND OTHER NAMEP ATE DETAI S WHI E

ORDERING SPARE PARTS FOR THE PUMP.

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 3 | 48 REVISION NO.1

1. GENERAL:

1.1 The booklet covers instructions for following pump types of CPHM

series.

UNIT-5

UNIT-7

UNIT-9

UNIT-11

UNIT-

11A

UNIT-

11B

UNIT-13

UNIT-13A

32/13 25/26A

65/32 125/26

(

2900

)

125/45

150/43

200/38M

125/32

(2900RPM)

32/16 32/26 80/32 200/46

32/16A

40/26

80/40

150/52

32/20

40/32

80/40N

32/20A

50/26

00/26

40/13

50/32

100/32

40/16

65/16

100/40

40/20

65/20

125/26

40/20A

65/26

125/32

50/13

65/26N

125/40

50/16

80/16

125/40

50/16A

80/20

150/32

50/20

80/26

150/32

65/13

100/20

150/40

65/43

NOTES:

1. CPHM pumps with driving unit-11, 11A, 11B, 1 3 , 1 3 A are

supplied with oil lubrication bearings as a standard supply.

2. Pump models with suffix “N” are modified for improvement in rising

nature performance towards shut-off.

1.2 Description of ‘CPHM’ pumps:

KIR OSKAR CPHM pumps are of back pullout design which enables to remove

the rotating unit of the pump for inspection and repairs without disturbing the

pipe connections.

1.3 The complete range of CPHM pumps is covered by eight driving units thereby

reducing inventory and achieving interchangeability of parts.

1.4 Pumps when properly installed and given due care in operation and

maintenance should operate satisfactorily for a long period.

1.5 When the pump is received, sometime before the actual use, it should be

inspected and located in a dry place. The coupling should be rotated once in a

month to prevent pitting of bearing surfaces.

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 4 | 48 REVISION NO.1

2. INSTALLATION:

2.1 For location, preparing foundation, installation, alignment, piping, general

maintenance, trouble, publication ‘GENERA INSTRUCTIONS FOR

INSTA ATION, OPERATION AND MAINTENANCE OF KIR OSKAR

CENTRIFUGA PUMPS’ which is also printed along with this booklet must be

followed carefully. If the pump is drawing liquid from the vessel under vacuum,

then vacuum equalizing connection piping must be made as per instructions

given in above publication. The external sealing connection to the pump, if

applicable, must be made after installing and before commissioning the pump.

2.2 Mounting and alignment:

A spacer type flexible coupling is recommended to connect pump shaft to the driver.

By using spacer type coupling, the complete rotating unit can be removed from the

volute without removing pump casing or motor and without disconnecting piping

connections. This also avoids any re-alignment of pump and motor after reassembly of

rotating unit. However, other types of coupling can be supplied against request.

Alignment:

A WAYS REMEMBER “F EXIB E COUP ING IS NOT A UNIVERSA JOINT”.

Correct alignment is essential for the smooth operation of the pump. There are two

types of mis-alignment between the pump shaft and the drive shaft which are –

i. Angular mis-alignment- Shaft with axis concentric but not parallel.

ii. Parallel mis-alignment- Shaft with axis parallel but not concentric. Mis-

alignment is checked by using straight edge as shown in Fig. 1 at 90

apart.

STD

COUP ING

STEE STRAIGHT

EDGE

STEE STRAIGHT

EDGE

CORRECT

3mm

INCORRECT

PARA E

MISA IGNMENT

STEE STRAIGHT

EDGE

INCORRECT

ANGU AR

MISA IGNMENT

Fig.

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 5 | 48 REVISION NO.1

2.3

Before commissioning the pump set, please ensure:

2.3.1 The pipe connections are flushed and tightened properly.

2.3.2 Alignment is proper.

2.3.3 Auxiliary piping connection such as sealing / flushing, etc., are made.

2.3.4 ‘CPHM’ pumps are grease lubricated as standard supply. However, against specialty

oil lubrication can be given. Then the pump is provided with constant level oiler.

Please note that CPHM pumps in units- 11, 11A, 11B, 13, 13A are always with oil

lubrication.

2.3.4.1

Constant level oiler:

Fix the constant level oiler and fill the oil. Procedure for fitting the constant level oiler

and method of filling oil is given below.

Constant level oiler has plastic container and aluminum body as a standard supply.

Connection stem is ¼” BSP tapped and its capacity is 70ml approx. If the constant

level oiler is properly fitted and oil is filled as per instructions given, practically no

attention is required as far as lubrication of bearing is concerned other than to

replenish the visible reserve supply of the oil in the container (Refer Fig. 2, 3 and 4).

2.3.4.2 Method of fitting:

Screw constant level oiler stem into the tapped hole of the bearing housing reservoir.

Before fitting oiler, check the level of the tapped hole with the help of turn bar with

¼” BSP tapping at one end and a sprit level (Refer Fig. 2). If the level is incorrect and

oiler tilts downward, oil will not flow from oiler into the reservoir (Refer Fig. 3). Hence

it is necessary to check the level before fitting in the constant level oiler.

2.3.4.3

Method of filling the oil:

Tilt the container (Refer Fig. 4) and fill it with oil through stem of the oiler. Replace

the container and allow oil to flow into the reservoir. The oil in the container shall

flow into the bearing housing reservoir and shall become empty. Repeat above

procedure till the level in the reservoir is equal to the level of which the oiler is

adjusted. When the desired level is attained the oil in container shall remain steady at a

position. Visible level of the oil in the container indicates that bearing housing reservoir

is filled up to the mark.

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 6 | 48 REVISION NO.1

CAUTION

1. In no case oil should be filled in directly into the bearing housing reservoir, through

breather cap.

2. Replenish the visible reserve supply of oil in the container as oil is used up.

3. Please ensure that “Air Groove” provided on aluminum body on which plastic

container rests, is not clogged with dust/fiber, oil film, etc. This groove allows

atmospheric air to enter inside the body to maintain oil level in bearing housing.

SPIRIT

EVE

Fig. 2

CORRECT

METHOD

Fig. 3

INCORRECT METHOD

A WAYS FI OI

HERE

NEVER FI OI

HERE

Fig.

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 7 | 48 REVISION NO.1

OPERATION:

3.1 Before startin the pump check the followin :

3.1.1 The pump rotates freely by hand.

3.1.2 Fill the grease/oil for bearings, if not done earlier. The bearings are packed with

grease/oil initially at the factory, however if the pump is stored for a longer time it is

necessary to refill the grease/oil in the bearings. Check the level of the oil in constant

level oiler is up to the mark.

3.1.3 The sealing liquid connections are properly tightened and adjusted.

3.1.4 The direction of rotation of the driver should correspond to the direction of rotation of

the pump.

3.1.5 The pump casing and suction pipe line is fully primed with liquid.

3.1.6 Valve on delivery side is closed.

3.1.7 The cock for pressure gauge connection is closed.

3.1.8 The gland bolts are properly tightened.

3.2 Startin the pump:

3.2.1 Start the pump. et the prime mover pick up its full speed.

3.2.2 Open the valve on delivery line gradually.

3.2.3 Open the cock for pressure gauge connection.

3.3

During running the pump check the following things and regulate, if necessary.

3.3.1 The pump is running smooth.

3.3.2 The bearings are not getting abnormally hot.

3.3.3 The gland is properly tightened to ensure sufficient leakage to dissipate heat generated.

Maximum permissible leakage is 60 to 80 drops per minute.

3.3.4 Head and capacity developed by the pump is as specified.

3.3.5 Power consumption is within limit.

3.3.6 Ensure that there is no mechanical friction in the pump.

3.3.7 Stop the pump immediately, if any defects are detected. Do not start the pump unless

defects are rectified. Report immediately to the supplier, if it is not possible to rectify

the defects.

3.4 Durin stoppin the pump:

3.4.1 Close the valve on delivery side.

3.4.2 Stop the motor.

3.4.3 If the pump is not required to be operated for a long time, drain the casing completely.

If the pump is required to be stored for a long time the bearing housing should be

dried internally with hot air and should be flushed with moisture free protective

such as light oil or kerosene.

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 8 | 48 REVISION NO.1

4. TECHNICAL DATA:

4.1 Direction of rotation:

The direction of rotation is clockwise when viewed from driving

end.

4.2 Speeds:

The limitations of the rotational speeds for CPHM pumps shall be as

follows.

Sr.

No.

Pump Type

Water Fill

Capacity

( itres)

Weight

(kg

approx.)

Max.

solid

size

(mm)

Max.

Rotational

Speed

(rpm)

1 CPHM 32/13 0.8 32 4.0 3000

2 CPHM 40/13 1.1 34 6.0 3000

3 CPHM 50/13 1.8 36 11.0 3000

CPHM 65/13

2.4

15.0

3000

CPHM 32/20

1.2

3.5

3000

6 CPHM 32/20A 1.2 40 3.5 3000

7 CPHM 40/20 1.5 41 3.5 3000

8 CPHM 40/20A 1.5 41 3.5 3000

CPHM 50/20

2.1

3000

PHM 32/

1.0

3.4

3000

11 CPHM 32/16A 1.0 34 3.4 3000

12 CPHM 40/16 1.2 36 4.5 3000

13 CPHM 50/16 1.8 39 9.0 3000

CPHM 50/16A

1.8

9.0

3000

CPHM 65/16

2.8

12.0

3000

16 CPHM 80/16 4.0 73 18.0 3000

17 CPHM 65/20 3.1 67 11.0 3000

18 CPHM 80/20 4.4 90 15.0 3000

CPHM 100/20

6.5

119

20.0

3000

CPHM 25/26A

1.7

3.0

3000

21 CPHM 32/26 1.8 76 3.0 3000

22 CPHM 40/26 2.1 77 3.5 3000

23 CPHM 50/26 3.9 79 5.0 3000

CPHM 65/26

4.2

9.0

3000

CPHM 65/26N

4.2

9.0

26 CPHM 80/26 4.9 99 12.0 3000

27 CPHM 40/32 1.8 87 4.5 3000*

28 CPHM 50/32 4.5 102 5.0 3000*

CPHM 100/26

8.0

133

17.0

3000

CPHM 125/26

12.0

152

22.0

1500

31 CPHM 125/26 at 2900

RPM

12.0 190 22.0 3000

32 CPHM 65/32 7.3 114 8.0 3000*

33 CPHM 80/32 8.3 120 9.0 3000*

CPHM 100/32

14.0

145

13.0

3000*

CPHM 125/32

14.0

160

17.0

1500

36 CPHM 125/32 14.0 179 17.0 2900

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019

Page 9 | 48 REVISION NO.1

Sr.

No.

Pump Type Water Fill

Capacity

( itres)

Weight

(kg

approx.)

Max.

solid

size

(mm)

Max.

Rotational

Speed

(rpm)

CPH

M 150/3

18.

221

3.0

1500

CPHM 150/32N

18.0

221

23.0

1500

CPHM 65/43

10.0

195

15.0

1500

CPHM 80/40

11.0

124

8.0

1500

CPHM 80/40N

11.0

124

8.0

1500

CPHM 100/40

13.8

134

11.0

1500

CPHM 125/40

15.5

180

13.0

1500

CPHM 125/40N

15.5

180

CPHM 200/38M

25.5

550

26.0

1500

CPHM 200/46

27.5

560

26.0

1500

CPHM 125/45

17.0

290

14.0

1500

CPHM 150/40

15.5

285

14.0

1500

CPHM 150/43

21.0

300

14.0

1500

CPHM 150/52

22.0

435

15.0

1500

NOTE:

Please contact the supplier or manufacturer if the pump is to be used for other

than the specified speeds.

4.3

Bearin s and Lubrication

4.3.1 Specifications of bearings, oil seals and felt rings.

PART

No.

DESCRIPTION

UNIT

11,11A

,11B

UNIT

11B

UNI

13,13A

2.1

Fel

t ring (DE)

25 x 38 x 6T

43 x 30 x 6T

40 x 53 x

502.2

Felt ring (NDE)

25 x 38 x 6T

35 x 47 x 5T

45 x 58 x

500.1

Oil Seal (DE)

25 x 37 x 7T

32 x 45 x 7T

72 x 42 x

10T

72 x 50 x

10T

72 x 50 x

10T

60 x 85 x

13T

500.2

Oil

Seal (N

DE)

5 x 37

x 7T

32 x 47 x 7T

60 x 45 x

72 x 50 x

10T

72 x 50 x

10T

65 x 85 x

13T*

Table des matières

Autres manuels KIRLOSKAR Pompe à eau

KIRLOSKAR

KIRLOSKAR i-CM32/13-0.75kW/2P Manuel utilisateur

KIRLOSKAR

KIRLOSKAR GOLD JALSENA Manuel utilisateur

KIRLOSKAR

KIRLOSKAR RKB Manuel de programmation

KIRLOSKAR

KIRLOSKAR DB 32/13 Instructions d'installation et d'utilisation

KIRLOSKAR

KIRLOSKAR Non-Clog Submersible Series Manuel de programmation

KIRLOSKAR

KIRLOSKAR RKBV Manuel de programmation

KIRLOSKAR

KIRLOSKAR Non Clog NS Series Manuel de programmation

KIRLOSKAR

KIRLOSKAR GK Series Manuel de programmation

KIRLOSKAR

KIRLOSKAR i-HT Manuel de programmation

KIRLOSKAR

KIRLOSKAR RKB Manuel de programmation

KIRLOSKAR

KIRLOSKAR CF Series Manuel de programmation

KIRLOSKAR

KIRLOSKAR GK Series Manuel de programmation

KIRLOSKAR

KIRLOSKAR KPDS Manuel de programmation

KIRLOSKAR

KIRLOSKAR SHS Manuel de programmation

KIRLOSKAR

KIRLOSKAR DSM Series Manuel de programmation

KIRLOSKAR

KIRLOSKAR KOSN Series Manuel d'instructions

KIRLOSKAR

KIRLOSKAR HSC LLC Manuel utilisateur

KIRLOSKAR

KIRLOSKAR IN 40/160 IL Manuel de programmation

Manuels Pompe à eau populaires d'autres marques

Neptun

Neptun NPHW 5500 Manuel utilisateur

Sensidyne

Sensidyne Gilian BDX-II Instructions d'installation et d'utilisation

Draper

Draper 47808 Manuel utilisateur

Trolla

Trolla 12820 Manuel utilisateur

Sunfab

Sunfab SVH Series Manuel utilisateur

WilTec

WilTec 50740 Manuel utilisateur

Fieldmann

Fieldmann FVC 5015 EK Manuel utilisateur

Everbilt

Everbilt EFSUB5-122HD Manuel utilisateur

Graco

Graco Husky 3300e Manuel utilisateur

esotec

esotec 101018 Manuel utilisateur

moyno

moyno 2000 CC Manuel utilisateur

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuel utilisateur

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guide de dépannage

DUROMAX

DUROMAX XP WX Series Manuel utilisateur

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuel utilisateur

Franklin Electric

Franklin Electric IPS Manuel utilisateur

Xylem

Xylem e-1532 Series Manuel utilisateur

Milton Roy

Milton Roy PRIMEROYAL Manuel utilisateur
