DP405 Digital Two-way Radio User Manual

User Manual

DP405

Digital Two-way Radio

We are very grateful for your purchasing KIRISUN brand two-way radios produced by

Kirisun Communications Co., Ltd.

We believe KIRISUN two-way radio, which always incorporates the latest technology, can

bring great convenience to your life and work.

We also believe that the quality and function of KIRISUN two-way radio can meet your

demands for reliable communication.

DP405 Digital Two-way Radio User Manual

Notice to user

RF Energy Exposure Information

RF Energy Exposure Awareness And Control

Information For Fcc Occupational Use Requirements

I before using the two-way portable radio, review the following important RF energy awareness and control

information and operational instructions. Comply with this information and instructions in order to ensure

compliance with RF exposure guidelines.e the capability to access information in that form.

Changes or modifications not expressly approved by Kirisun Communications Co., Ltd. could void the

user's authority to operate the equipment.

This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide

communications between two or more users over a distance. It uses RF energy or radio waves to send and

receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to,

electric power, sunlight, and x-rays. RF energy, however, should not be confused with these other forms of

electromagnetic energy, which, when used improperly, can cause biological damage. Very high levels of x-rays,

for example, can damage tissues and genetic material.Experts in science, engineering, medicine, health, and

industry work with organizations to develop standards for exposure to RF energy.These standards provide

recommended levels of RF exposure for both workers and the general public. These recommended RF exposure

levels include substantial margins of protection. All two-way radios marketed in North America are designed,

manufactured, and tested to ensure they meet government-established RF exposure levels. In addition,

manufacturers also recommend specific operating instructions to users of two-way radios. These instructions are

important because they inform users about RF energy exposure and provide simple procedures on how to

control it.

DP405 Digital Two-way Radio User Manual

III

Federal Communications Commission Regulations

Before it was marketed in the United States, the Digital portable radio was tested to ensure compliance with FCC

RF energy exposure limits for two-way portable radios. When two-way radios are used as a consequence of

employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational

requirements. Exposure awareness can be facilitated by the use of a label directing users to specific user

awareness information. The radio has an RF exposure product label.Also, the Product Safety Manual and this

Operator’s Manual include information and operating instructions required to control RF exposure and to satisfy

compliance requirements.

Operation Safety Recommendations

Occupational Safety Guidelines And Safety Training Information

To ensure bodily exposure to RF electromagnetic energy is within the FCC allowable limits for occupational use.

Always adhere to the following basic guidelines:

•The push-to-talk button should only be depressed when intending to send a voice message.

•The radio should only be used for necessary work-related communications.

•The radio should only be used by authorized and trained personnel. It should never be operated by children.

•Do not attempt any unauthorized modification to the radio. Changes or modifications to the radio may cause

harmful interference and/or cause it to exceed FCC RF exposure limits. Only qualified personnel should

service the radio.

•Always use only authorized accessories (antennas, control heads, speakers/mics, etc.). Use of unauthorized

accessories can cause the FCC RF exposure compliance requirements to be exceeded.

The information listed above provides the user with information needed to make him or her aware of a RF

exposure, and what to do to assure that this radio operates within the FCC exposure limits of this radio.

This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this

device does not cause harmful interference.

DP405 Digital Two-way Radio User Manual

Content

1UNPACKING AND CHECKING.............................................................................................1

1.1 SUPPLIED ACCESSORIES ................................................................................................................1

2BATTERY INFORMATION...................................................................................................2

2.1 NOTICE....................................................................................................................................2

2.2 BATTERY CHARGING ....................................................................................................................3

3ATTACHING THE ACCESSORIES..........................................................................................4

3.1 ATTACHING/DETACHING THE BATTERY............................................................................................4

3.2 ATTACHING/DETACHING THE ANTENNA ..........................................................................................4

3.3 ATTACHING/DETACHING THE BELT CLIP ..........................................................................................5

3.4 ATTACHING THE MICROPHONE ......................................................................................................5

4INTRODUCTION ................................................................................................................6

5PROGRAMMABLE KEYS.....................................................................................................8

5.1 PROGRAMMABLE KEYS.................................................................................................................8

5.2 LED INDICATION.........................................................................................................................9

DP405 Digital Two-way Radio User Manual

6BASIC OPERATION ..........................................................................................................10

6.1 POWER ON/OFF THE RADIO ........................................................................................................10

6.2 SELECTING THE CHANNEL............................................................................................................10

6.3ADJUSTING THE VOLUME............................................................................................................11

6.4 INITIATING A CALL .....................................................................................................................11

6.5 RECEIVING...............................................................................................................................11

6.6 REPLYING TO THE CALL...............................................................................................................11

7FEATURES AND OPERATION ...........................................................................................12

7.1 TOT (TIME-OUT-TIMER).............................................................................................................12

7.2 CHANNEL SCAN ........................................................................................................................12

7.3 SCAN THE REPLY MESSAGE .........................................................................................................12

7.4 PRIORITY SCAN.........................................................................................................................12

7.5 KILL AND UNKILL.......................................................................................................................13

7.6 EMERGENCY.............................................................................................................................13

7.7 ENABLING COLOR CODE ON DIGITAL MODE ...................................................................................14

7.8 TECHNICAL PARAMETERS............................................................................................................14

8TROUBLE SHOOTING.......................................................................................................15

DP405 Digital Two-way Radio User Manual

FCC STATEMENT..............................................................................................................16

DP405 Digital Two-way Radio User Manual

1 Unpacking and Checking

Please carefully open the box, and check if the accessories listed below are contained in the package. For

any missed or damaged item, please contact your local dealer for solution.

1.1 Supplied Accessories

Material

Quantity

Radio

Charger

Power Adaptor

Battery

Belt Clip

Antenna

Strip

User Manual

Charger

Belt Clip and

Screws

Battery

Power Adapter

配器

Antenna

Hand Strap

DP405 Digital Two-way Radio User Manual

2 Battery Information

2.1 Notice

The battery is not charged before delivery, so please charge the battery

for your first use. If the battery is not used for a long time or the battery is

used up, please charge it before use. Charge/discharge for twice or three

times alternately to achieve its optimal performance. For low battery,

please charge it or replace it.

Note:

◆Do not cause any short circuit on the battery or throw the battery into fire.

◆When attaching the battery to the radio for charging, please make sure the radio is powered off to guarantee

it can be fully charged.

◆Do not leave the radio or battery on the charger after it is fully charged. Unnecessary constant charging will

shorten the battery life.

◆Do not put the fully-charged battery back to the charger for

re-charging, or it may shorten the battery life.

◆Please try to keep the battery in an indoor environment at around

25℃. The battery may get easily spoiled after being kept in the

environment below -10℃for a long time.

◆In temperature higher than 35℃or below -10℃, the dischargeable

power of the battery may decrease due to the physical property of

lithium battery.

DP405 Digital Two-way Radio User Manual

2.2 Battery Charging

(1) Plug the power adaptor in the proper socket of AC power.

(2) Plug the cable of the power adaptor at the back of the socket, and the green indicator glows.

(3) Plug the battery or radio in the charger.

(4) Make sure that the battery is in proper contact with the charger terminal, and the red indicator glows.

(5) After the battery is charged for 6 hours, the red light goes out, indicating that the battery is fully charged.

(6) When the green indicator glows, keep the battery on the charger for 1-2 hours before taking it out so as to

achieve the optimal performance.

(7) Take out the power adaptor from the socket of AC power output.

Note:

The battery is not charged before delivery from the factory, so please charge the battery before your first

use.

Kirisun KB-760B lithium-ion can be used for this radio.

If the battery which is stored for over 2 months or a new battery is charged for the first time, it should be

charged repeatedly to gain full battery capacity. The battery should be at least charged once every

three months.

When the battery is fully charged or the battery power is above the level of low power alert, do not

charge the battery, or it may affect the battery life and performance. Please take out the battery from

the charger after it is fully charged.

When the radio enters the state of low voltage alarm, please charge the battery before using it and do

not force to power on the radio in case that the battery life and performance is impaired.

There is protection circuit inside KB-760B lithium battery. The power supply will be cut off in state of low

power, and when you charge it in the charger, the indicator will glow after 1-5 minutes.
