1. Brief introduction

The GSM Alarm System S3526 is a new security protection solution

special for home, house and office and other applications. It based on

Wireless GSM Communication network. When any sensor activated, it

will Call&Send SMS to owners telephone immediately.

The GSM Alarm System S3526 can setup by SMS easiler.

What you need is a SIMCard which supports Call ID function.

2.Safety Directions

Safe Startup

Do not use GSM Alarm System when using GSM equipment

is prohibited or might bring disturbance or danger.

Interference

All wireless equipment might interfere network signals of

GSM Alarm System and influence its performance.

Avoid Use at Gas Station

Do not use GSM Alarm System at a gas station. Power off

GSM Alarm System it near fuels or chemicals.

Power it off near Blasting Places

Please follow relevant restrictive regulations. Avoid using the

device in blasting places.

Reasonable Use

Please install the product at suitable places as described in

the product documentation. Avoid signal screening by

covering the mainframe.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com

King Pigeon Hi-Tech. Co., Ltd. Page ３of 21 Ver 1.2 File No.: 35260011

Use Qualified Maintenance Service

Maintenance can be carried out only by qualified maintainer.

Waterproofness

The product is not waterproof. Please install it at dry places

and keep it dry.

3. Standard Packing List

ControlUnitX1 Wireless Magnetic Door Sensor X1

Wireless Remote Controls X 2 Wireless PIR Motion Sensor X1

Wired Mini Siren(110dB) X1 GSM ANT X 1

Regulated 12vDC Power Supply X1 User Manual X1

Optional Accessories: (Wired or Wireless Sensors)

PIR Motion Sensors Glass Break Sensors

Magnetic Window Sensors Magnetic Steel Scrolling Door Sensor

Temperature Sensors and Other Sensors.

4. Physical Layout

4.1 Control Unit physical layout

Power External 12VDC Power Status LED,power on will on.

Status Arm Status LED,in armed mode, it flashs green, always

green is disarmed.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com

King Pigeon Hi-Tech. Co., Ltd. Page ４of 21 Ver 1.2 File No.: 35260011

Busy Always red color means the mainframe calling out or

sending SMS out or triggered,normally, it flashs.

Run GSM Network Led, flash 1 time per 1 second, means

searching and registering GSM network. Flash 1

second and off 3 seconds, means the gsm netwok was

registered, always on means under the

communication.Otherwise,means the SIMCard hasn’t

been fixed well or GSM network signal is weakness.

Alarm Alarming it will on and the buzzer will make a sound.

Out Relay output closed it will on, otherwise it is off.

Monitor Microphone working, will on,otherwise it is off.

Charge Under charge the internal backup battery,it will on,

otherwise, it is off.

4.2 8Pin connector definition

Interface

PIN 1 GND

PIN 2 Siren positive electrode

PIN 3 12VDC Power Output Source, can use it for any device or

sensors that need 12VDC to work.

PIN 4 Output relay negative electrode

(Relate Voltage:2A/250VAC)

PIN 5 Output relay positive electrode

(Relate Voltage:2A/250VAC)

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com

King Pigeon Hi-Tech. Co., Ltd. Page ５of 21 Ver 1.2 File No.: 35260011

PIN 6 GND

PIN 7 Wired sensor input 1 (e.g.: Temperature sensor.)

PIN 8 Wired sensor input 2(e.g.: Photoelectric Beams Sensor.)

Tips:

1. The Output relay is similar the Power Switch, you can use it to control the light,

gate,DVR and other applications. Its drived by 5VDC, related voltage is

2A/250VAC,<40W, when you use high vlotage applications, please note the

cables.

5. Features

1) GSM Frequency: Dual-Band(900/1800MHz), Quad-Band is

optional(850/900/1800/1900Mhz) ;

2) Supports armed, disarmed by SMS or remote control or telephone;

3) Supports start or stop the siren by telephone or SMS command;

4) Supports Swith On or Off the output relay by telephone or SMS

command;

5) Automaticed send SMS Alert and dial to the pre-set cellphone when

any sensor triggered;

6) Equips with 2 Wired Zones,NC/NO, and Zone Name is editable;

7) Equips with 8 Wireless Zones, Zone Name is editable;

8) Supports 3 SMS alarm cellphones and 5 dial alarm telephone numbers;

9) Equips with 1 relay output, it likes a switch, use for driving DVR, light,

gate or other electric appliances once the system activated;

10) Reserved 12VDC power source from the control unit for wired sensors;

11) Supports external power failure&recovery alert function;

12) Supports wiretap through internal Mircophone;

13) Supports wired and wireless siren;

14) Supports alert user by SMS when the remote control has been used to

control the system; this function can enable or disable by user;

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com

King Pigeon Hi-Tech. Co., Ltd. Page ６of 21 Ver 1.2 File No.: 35260011

15) Standby internal rechargeable battery which can last 12 hours;

16) Based on the GSM communication network and Voice Operation Menu

technology, apply to wide range situations.

6. Settings

The S3526 designed for easiler setup, all the setup can be done by SMS

commands. Also, you can setup it by call, the commands are the same as

the SMS Commands.

Before the setting, please read the user manual carefully. Then insert the

SIMCard and fix it well, then power on the mainframe, the control unit will

search and register the GSM Network automatically, once the Run Led

flashs 1 second and off 3 seconds, means the gsm netwok was

registered,then you can start to set it. Also, you can set the system by SMS

after it finished GSM Network registration.

Please setup it following the follow table:

Notice:

1) Please use SMS command to set at least one SMS Alarm Phone number firstly

after you reset the system, otherwise, you don’t know if the sensors learned to the

system successfully;

2) When set the system by SMS, if success, will return one SMS to confirm, otherwise,

means the setting failure;

3) The relay will be switched on for 3 minutes when you use phone to control it or the

system triggered, or use SMS commands to switched on it.

4) If you need to reset the system to factory deflaut, then please press the Reset

Button, then power on the system, once you heard “Di” sound then release the

button. The button near the SIMCard Socket.

5) When set the Control Unit by phone, the system will request you input password to

enter the system. Please enter the password slowly. Otherwise, you should enter

many times. if success, will make a long Di sound to confirm, if it makes didi sound,

means the setting failure.The operation commands please see tables.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com

King Pigeon Hi-Tech. Co., Ltd. Page ７of 21 Ver 1.2 File No.: 35260011

6) Depending on the infrastructure, the SMS Command Control functions may not

work in all countries.

Telephone and SMS Commands For GSM Alarm System

Setup Basic Functions

Com. Functions&Descriptions

11# Set the control unit when triggered, The siren will sound.(Default)

11* When the control unit triggered, the siren will not sound.

12# Enable to alert user by SMS when use remote control to Arm or

Disarm the system;

12* Disable to alert user by SMS when use remote control to Arm or

Disarm the system;(Deflaut)

21# Set wired zone as NC type.

21* Set wired zone as NO type. (Default)

31# Modify password. The original password is 1234.

Setup SMS Alert Telephone numbers

Com. Functions&Descriptions

40# Inquire the preset SMS Alert telephone numbers. (Can’t inquire it

by telephone,only by SMS.)

41# Set the 1st SMSAlert telephone Number.

42# Set the 2nd SMS Alert telephone Number

43# Set the 3rd SMS Alert telephone Number.

Setup Call Alert Telephone numbers

Com. Functions&Descriptions

50# Inquire the preset Dial phone number. (Can’t inquire it by phone,

only by SMS.)

51# Set the 1st dial phone number.

52# Set the 2nd dial phone number.

53# Set the 3rd dial phone number.

54# Set the 4th dial phone number.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com

King Pigeon Hi-Tech. Co., Ltd. Page ８of 21 Ver 1.2 File No.: 35260011

55# Set the 5th dial phone number.

Setup SMS Alert Contents

Com. Functions&Descriptions

70# Inquire the Wired zone Name.(Can’t inquire it by phone)

71# Set the the1st wired zone name. (Max. 23 letters)

72# Set the 2nd wireld zone name. (Max. 23 letters)

80# Inquire the wireless zone names. (Can’t inquire it by phone)

81# Set the 1st wireless zone name. (Max. 23 letters)

82# Set the 2nd wireless zone name. (Max. 23 letters)

83# Set the 3rd wireless zone name. (Max. 23 letters)

84# Set the 4th wireless zone name. (Max. 23 letters)

85# Set the 5th wireless zone name. (Max. 23 letters)

86# Set the 6th wireless zone name. (Max. 23 letters)

87# Set the 7th wireless zone name. (Max. 23 letters)

88# Set the 8th wireless zone name. (Max. 23 letters)

Tips!

1) Send 1234#01# to arm the system, or call into the system, then enter 1234# 01#

to arm it.

2) Change the password: send 1234#31#1111#, Or call into the system, then enter

1234#31#1111#. Means change the password 1234 to 1111.

3) Set the first dial phone Number 20202020:

Send SMS 1234#51#20202020# to the system or call the system, then enter

1234#51#20202020#.

4) Delete the preset alarm number:

Send SMS 1234#51## or call the sytsem, then enter 1234#51##. Will delete the

first dial phone number, the same format to delete the other alarm phone numbers

and SMS alert numbers.Send SMS 1234#41## or call the system, then enter

1234#41## to delete the first SMS alert number.

5) Change the zone name: (The zone names should less than 12 letters.) Send

1234#81#door# to change the wireless zone 1 name to door.

Please help to setup the first SMS Alert Number firstly, so that you can receive all

the confirmation SMS.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com

King Pigeon Hi-Tech. Co., Ltd. Page ９of 21 Ver 1.2 File No.: 35260011

7. Operating Instructions

7.1 Arm or Disarm and Emergency Alarm by remote controls

Press the button “ ” on the remote control, the Control Unit enters arm

status. under this status, any sensor triggered, the control unit will alarm

and the siren will sound 90S.

Press the button “ ” on the remote control, the Control Unit disarms

immediately. under this status, any sensor triggered, the control unit will not

alarm and the siren will not sound, except the Emergency Button.

Press Emergency button” ” on the remote control or Press any

Emergency button.The Control Unit will enter emergency alarm status.

The siren will not sound, but will alert the pre-set phone number

immediately.

7.2 Arm or Disarm by SMS and Telephone.

There’re two way to operate it.

Method 1: Send SMS to Arm or Disarm;

2: Call to the Control unit.

In order to operate it easier, we designed simply commands, as below:

Wireless ANT

Arm Button

Disarm Button

This Button Useless)

Emergency Button

Table des matières

Autres manuels King Pigeon Système de sécurité

King Pigeon

King Pigeon S800 Manuel utilisateur

King Pigeon

King Pigeon K9 Manuel utilisateur

King Pigeon

King Pigeon K2 Manuel utilisateur

King Pigeon

King Pigeon S100 Manuel utilisateur

King Pigeon

King Pigeon S100Pro Manuel utilisateur

King Pigeon

King Pigeon RTU5023 Manuel utilisateur

King Pigeon

King Pigeon GSM Elderly Guarder Manuel utilisateur

King Pigeon

King Pigeon S120 Manuel utilisateur

King Pigeon

King Pigeon RTU5012 Manuel utilisateur

King Pigeon

King Pigeon GSM 3G M2M RTU Manuel utilisateur

King Pigeon

King Pigeon K1 Manuel utilisateur

King Pigeon

King Pigeon S110 Manuel utilisateur

King Pigeon

King Pigeon RTU5023 Manuel utilisateur

King Pigeon

King Pigeon S3622 Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
