User Guide P/N 1210-7202-00 Rev.A EN 2/2014

ATTENTION: Please take a few minutes to thoroughly read this

user guide, which should be saved for future reference and

passed on to any subsequent owner.

moke Alarm

User Guide

Model: i12010 CA

SINGLE AND/OR MULTIPLE

STATION SMOKE ALARM

120 V AC Operated with sealed 3V Lithium Battery Backup

Smoke alarms are designed to minimize false alarms. Cigarette

smoke will not normally set off the alarm, unless the smoke is

blown directly into the alarm. owever, large quantities of

combustible particles from spills or broiling could still cause the

unit to alarm. Careful location of the unit away from the kitchen

area will give the maximum nuisance alarm protection.

Combustion particles from cooking may set off the alarm if

located too close to the cooking area. Large quantities of

combustible particles are generated from spills or when broiling.

Using the fan on a range hood which vents to the outside (non-

recirculating type) will also help remove these combustible

products from the kitchen.

If the alarm sounds, check for fires first. If a fire is discovered

follow these steps. Become thoroughly familiar with these items,

and review with all family members!

• Alert small children in the home. Children sleep very

sound and may not be awakened by the sound of the

smoke alarms.

• Leave immediately using one of your planned escape

routes (see page 21). Every second counts, don’t stop

to get dressed or pick up valuables.

• Before opening inside doors look for smoke seeping in

around the edges, and feel with the back of your hand

If the door is hot use your second exit. If you feel it’s

safe, open the door very slowly and be prepared to

close immediately if smoke and heat rush in.

• If the escape route requires you to go through smoke,

crawl low under the smoke where the air is clearer.

• Go to your predetermined meeting place. When two

people have arrived one should leave to call 911 from

a neighbor’s home, and the other should stay to perform

a head count.

What to do When the Alarm ounds!

• Do not reenter under any circumstance until fire

officials say that it is safe to do so.

• There are situations where a smoke alarm may

not be effective to protect against fire as noted

by the NFPA Standard 72. For instance:

- Smoking in bed

- Leaving children unsupervised

- Cleaning with flammable liquids, such as gasoline

- Fires where the victim is intimate with a flaming

initiated fire; for example, when a person's

clothes catch fire while cooking

- Fires where the smoke is prevented from reaching

the detector due to a closed door or other

obstruction

- Incendiary fires where the fire grows so rapidly that

an occupant's egress is blocked even with

properly located detectors

Introduction ............................Page1

Product View ...........................Pages2-3

Features ................................Pages4-5

Limitations of Smoke Alarms ..............Pages5-6

Installation Instructions

Step 1: Installation Instructions:

A. Recommended Installation Locations . . . . Pages 6-8

B. Locations to Avoid . . . . . . . . . . . . . . . . . . Page 9

Step 2: Wiring Instructions . . . . . . . . . . . . . . . . Page 10-11

Step 3: Mounting Instructions.. . . . . . . . . . . . . . Pages 12-13

Step 4: Testing the Alarm. . . . . . . . . . . . . . . . . . Page 13

Operating Instructions

Interconnect Feature . . . . . . . . . . . . . . . . . . . . . Page 14

US Control Feature . . . . . . . . . . . . . . . . . . . . Page 15

LED Indicator Operation. . . . . . . . . . . . . . . . . . . Page 16

Tamper Resist Feature . . . . . . . . . . . . . . . . . . . . Page 17

Alarm Removal ..........................Page17

Battery Information

End of Product Life Notification . . . . . . . . . . . . . Page 18

Deactivation of Alarm.....................Page19

General aintenance .....................Page20

Fire Safety Information

EscapePlan............................Pages21

FirePrevention..........................Page22

Industry Safety Standards

National Fire Protection Association . . . . . . . . . Page 23

NRC .................................Page23

Limited Warranty ........................Page24

Table of Contents

Thank you for purchasing the Kidde Smoke Alarm model

i12010SCA.

This unit is suitable as a Single Station and/or Multiple

Station (24 devices) alarm. This alarm has a ten-year limited

warranty.

I PORTANT: This unit is only approved to

interconnect with the Kidde line of products. It is not

approved to interconnect with any other

manufacturer’s products.

Please take a few minutes to thoroughly read this user

guide which should be saved for future reference. Teach

children how to respond to the alarms, and they should

never play with the unit.

Your Kidde Smoke Alarm was designed to detect smoke from

any source of combustion in a residential environment. It is

not designed for use in a recreational vehicle (RV) or boat.

If you have any questions about the operation or

installation of your alarm, please call our toll free Product

Support Line at 1 800-880-6788.

The guide on page 21 will help you determine the correct

location of safety products that will help keep your home a

safer place.

Introduction

Test/Reset/Hush®

Button Green & Red LED

(Light Emitting Diode)

Alarm Sounder

Front

Product View

Back

Product View

Tamper-Resist

Feature

AC Connector Pins

• Loud 85 decibel alarm.

• Ionization smoke sensor.

• Powered by 120V AC (60 z, 45 mA max) wire-in connector

and a sealed 3V Lithium battery backup, which will last the

life of the alarm. No need to replace batteries.

• Interconnectable to other Kidde smoke and CO alarms (see

page 14 for details).

• Alarm warning system that alerts you of the following

conditions in the manner described below:

S OKE ALAR : The alarm pattern is three long alarm

beeps, which will repeat until the smoke is eliminated. The

red LED light will flash during alarm.

LOW BATTERY: If the battery is low, the red LED light will

flash and the unit will "chirp" once every 60 seconds for a

minimum of seven (7) days. This alarm contains a sealed 3V

Lithium battery, which will last the life of the alarm. No need

to replace batteries.

• The End of Product Life Alarm/Signal is a double chirp and

flash every 30 seconds (see page 17).

• End of Life ush. At end of product life, the button can be

pushed to silence the end of life "chirp" for approximately

3 days at a time, for a maximum of 30 days life extension.

• One “chirp” every 30 seconds coupled with a green LED flash

twice a second is an indication that the alarm is

malfunctioning. If this occurs call the Product Support Line at

1-800-880-6788.

• Test/Reset button performs functions.(See page 14).

• US Control Feature that silences the unit during nuisance

alarm situations (see page 16).

• Alarm Memory Feature that gives visual indication when an

alarm has sensed a hazardous condition (see page 16).

• Green and red LED lights that indicate normal operation and

alarm status (see page 17 for details).

• Tamper Resist Feature that deters children and others from

removing the alarm (see page 18).

Features

moke Alarm

The smoke alarm monitors the air for products of combustion

that are produced when something is burning or smoldering.

When smoke particles in the smoke sensor reach a specified

concentration, the alarm warning system will sound, and be

accompanied by the flashing red LED light.

WARNING: PLEA E READ CAREFULLY AND

THOROUGHLY

NFPA 72 states: Life safety from fire in residential occupancies is

based primarily on early notification to occupants of the need

to escape, followed by the appropriate egress actions by those

occupants. Fire warning systems for dwelling units are capable

of protecting about half of the occupants in potentially fatal

fires. Victims are often intimate with the fire, too old or young,

or physically or mentally impaired such that they cannot escape

even when warned early enough that escape should be

possible. For these people, other strategies such as protection-

in-place or assisted escape or rescue are necessary.

• Smoke alarms are devices that can provide early warning of

possible fires at a reasonable cost; however, alarms have

sensing limitations. Ionization sensing alarms may detect

invisible fire particles (associated with fast flaming fires)

sooner than photoelectric alarms. Photoelectric sensing

alarms may detect visible fire particles (associated with slow

smoldering fires) sooner than ionization alarms. ome fires

develop in different ways and are often unpredictable. For

maximum protection, Kidde recommends that both Ionization

and Photoelectric alarms be installed.

• A battery powered alarm must have a battery of the specified

type, in good condition and installed properly.

• Smoke alarms must be tested regularly to make sure the

batteries and the alarm circuits are in good operating

condition.

Features and General Information

Limitations of moke Alarms

• Smoke alarms cannot provide an alarm if smoke does not

reach the alarm. Therefore, smoke alarms may not sense fires

starting in chimneys, walls, on roofs, on the other side of a

closed door or on a different floor.

• If the alarm is located outside the bedroom or on a different

floor, it may not wake up a sound sleeper.

• The use of alcohol or drugs may also impair one’s ability to

hear the smoke alarm. For maximum protection, a smoke

alarm should be installed in each sleeping area on every level

of a home.

• Although smoke alarms can help save lives by providing an

early warning of a fire, they are not a substitute for an

insurance policy. ome owners and renters should have

adequate insurance to protect their lives and property.

tep 1 Installation Instructions

I PORTANT: THIS ALAR UST BE OUNTED ON A

CEILING OR WALL. IT WAS NOT DESIGNED FOR USE AS A

TABLETOP DEVICE! INSTALL ONLY AS DIRECTED!

A. Recommended Installation Locations:

Kidde recommends the installation of a Smoke Alarm in the

following locations. For maximum protection we suggest an

alarm be installed on each level of a multilevel home, including

every bedroom, hallways, finished attics and basements. Put

alarms at both ends of bedroom, hallway or large room if

hallway or room is more than 9.1m (30 ft) long. If you have

only one alarm, ensure it is placed in the hallway outside of the

main sleeping area, or in the main bedroom. Verify the alarm

can be heard in all sleeping areas.

Locate an alarm in every room where someone sleeps with the

door closed. The closed door may prevent an alarm not located

in that room from waking the sleeper. Smoke, heat and

combustion products rise to the ceiling and spread horizontally.

Mounting the alarm on the ceiling in the center of the room

places it closest to all points in the room.

Limitations of moke Alarms

Installation Instructions

Table des matières

Autres manuels Kidde Détecteur de fumée

Kidde

Kidde HART XL Manuel utilisateur

Kidde

Kidde P4010LDCS-WCA Manuel utilisateur

Kidde

Kidde p9050CA Manuel utilisateur

Kidde

Kidde I9030 Manuel utilisateur

Kidde

Kidde SMOKE AND CARBON MONOXIDE ALARM Manuel utilisateur

Kidde

Kidde P4010DCSCO-WCA Manuel utilisateur

Kidde

Kidde P4010ACS Manuel utilisateur

Kidde

Kidde P4010ACS-WF Manuel utilisateur

Kidde

Kidde FIRE SENTRY 0914 Manuel utilisateur

Kidde

Kidde 900-0114 Manuel utilisateur

Kidde

Kidde RF-SM-ACDC Manuel utilisateur

Kidde

Kidde 1276 Manuel utilisateur

Kidde

Kidde 1276E Manuel utilisateur

Kidde

Kidde Fire Smart FS301 Manuel utilisateur

Kidde

Kidde 120VAC Manuel utilisateur

Kidde

Kidde PI9000 Manuel utilisateur

Kidde

Kidde i12010S Manuel utilisateur

Kidde

Kidde TRUSENSE SMOKE 3050-VAS10 Manuel utilisateur

Kidde

Kidde 916 Manuel utilisateur

Kidde

Kidde P9040 Manuel utilisateur

Kidde

Kidde KN-COSM-BCA Manuel utilisateur

Kidde

Kidde KN-COSM-XTR-B Manuel utilisateur

Kidde

Kidde KN-SMFM-i Manuel utilisateur

Kidde

Kidde 976 Manuel utilisateur

Manuels Détecteur de fumée populaires d'autres marques

x-sense

x-sense SD19-W Manuel utilisateur

BRK electronic

BRK electronic First Alert P1010 Manuel utilisateur

FireAngel

FireAngel Thermoptek ST-622 Manuel utilisateur

teko

teko Astra-42A Manuel utilisateur

Safetec

Safetec SDS-2/6 Manuel du propriétaire

Siemens

Siemens PE-11C Manuel utilisateur

System Sensor

System Sensor DH500ACDC Manuel utilisateur

Resolution Products

Resolution Products RE612 CryptiX Manuel utilisateur

First Alert

First Alert PC900V Manuel utilisateur

Eminent

Eminent EM6590 E-Domotica Manuel utilisateur

Ei Electronics

Ei Electronics Ei Ei168RC Manuel utilisateur

Carrier

Carrier Kidde Quell Q301 Manuel utilisateur

VESDA

VESDA VLF-500 Manuel utilisateur

ELRO

ELRO FS8110 Manuel utilisateur

Heiman

Heiman SMOKI NS-626PHS Manuel utilisateur

Regin

Regin SDD-S65 Manuel utilisateur

Family Gard

Family Gard FG225 Manuel utilisateur

Greystone

Greystone DSD120 Manuel utilisateur

Kidde i12010SCA Manuel utilisateur

Manuels Détecteur de fumée populaires d'autres marques
