Keysight 9000 Series Manuel utilisateur

Keysight Infiniium

9000 Series Oscilloscopes

Service Guide

Publication Number 54904-97021

July 2017

Infiniium 9000 Series Oscilloscopes

The Keysight Technologies Infiniium 9000 Oscilloscope at a Glance

Ease of use with high performance

The Keysight Technologies Infiniium oscilloscopes

combine unprecedented ease-of-use with high-

performance digitizing oscilloscope functionality to

simplify your design and analysis measurement

tasks.

• Traditional oscilloscope front-panel interface

provides direct access to the controls needed

for most troubleshooting tasks.

• Graphical user interface with menus, windows,

dialog boxes, and toolbars provides easy access

to dozens of configuration and analysis tools,

ensuring you can set up and make the most

complex measurements.

• Models with bandwidths from 250 MHz to

4GHz.

Display shows waveforms and graphical user

interface

• Graphical interface allows direct interaction

with waveforms, including drag-and-drop

positioning and instant waveform zoom.

•Touchscreendisplayallows oscilloscope

operation without an external pointing device.

• Waveforms displayed in color, making

correlation easy.

• Current configuration parameters displayed

near the waveform display and are color-coded

to make identification easy.

• Graphical interface menus and toolbars simplify

complex measurement setups.

Horizontal controls set sweep speed and position

• Main sweep speeds from 5 ps/div to 20 s/div.

• Intensified waveforms on main sweep window

make it easy to see what will appear in the zoom

window.

Acquisition and general controls start and stop the

scope and do basic setup

• Run and stop controls for continuous or single

acquisitions.

• Clear display before one or more acquisitions.

• Default setup and Autoscale set initial

configuration.

Hard disk drive and USB 2.0 port for saving and

restoring setups and measurement results

• Store measurement displays for inclusion in

reports and test setup guides.

• Store oscilloscope setups to repeat tests

another time.

• Hard disk stores oscilloscope operating system.

Trigger setup controls set mode and basic

parameters

• Select Edge, Glitch, or Advanced Modes.

• Choose input source and slope.

• Use graphical user interface to simplify

configuration of pattern, state, delay, and

violation trigger modes.

Vertical controls set attenuation and position

• Input attenuation adjustable from 1 mV/div to 1

V/div.

• Color-coded knobs make it easy to find the

controls that affect each waveform.

Marker and quick measurements help measure

waveform parameters

• Waveform markers A and B to check voltage or

Δ-time at any point on the displayed waveform.

Service Policy

The service policy of this instrument requires

replacing defective assemblies. Some assemblies

can be replaced on an exchange basis.

In This Service Guide

This book provides the service documentation for the Keysight Technologies 9000 Series oscilloscopes.

It is divided into eight chapters.

Chapter 1, "General Information," provides information about which oscilloscopes are covered by this

manual, environmental requirements, and oscilloscope dimensions.

Chapter 2, "Calibration," explains how and when you should run the user calibration procedure.

Chapter 3, "Testing Performance," provides information about testing the oscilloscope to verify that it

performs according to specifications.

Chapter 4, "Troubleshooting," provides information about how to identify defective assemblies.

Chapter 5, "Replacing Assemblies," gives the procedures and techniques for replacing defective parts.

Chapter 6, "Replaceable Parts," includes a list of exchange assemblies and other replaceable parts, part

ordering information, and shipping information.

Chapter 7, "Theory of Operation," briefly describes the internal operation of the oscilloscope.

At the back of the book you will find safety notices.

If you have any questions after reviewing this information, please contact your local Keysight

Technologies representative or contact us through our website at www.keysight.com.

The Declaration of Conformity (DoC) for any Keysight product can be found at www.keysight.com/

go/conformity.

Instruments covered by this service guide 8

Accessories supplied 9

Specifications and Characteristics 9

Environmental Conditions 10

Measurement Category 10

Setting Up the Oscilloscope 11

General Information

Instruments covered by this service guide

Oscilloscopes manufactured after the date this manual was released may be different from those

described in this manual. The release date of this manual is shown on the title page. This manual will

be revised when necessary.

If you have an oscilloscope that was manufactured after the release of this manual, please check the

Keysight Technologies website at www.keysight.com to see whether a newer version of this manual is

available.

The following 9000 Series oscilloscopes are covered in this guide.

Oscilloscopes Covered by this Service Guide

The oscilloscope can be identified by the product number on the front or rear panel.

DSO9024H, DSO9054H, DSO9104H, and DSO9204H models have up to 12 bits of resolution.

Model Bandwidth

DSO/MSO9064A 600 MHz

DSO/MSO9104A 1 GHz

DSO/MSO9254A 2.5 GHz

DSO/MSO9404A 4 GHz

DSO9024H 250 MHz

DSO9054H 500 MHz

DSO9104H 1 GHz

DSO9204H 2 GHz

Chapter 1: General Information

Accessories supplied

The following accessories are supplied.

•Mouse

•Stylus

• Keyboard

• Accessory Pouch

• Front panel Cover

• Localized Power Cord

• N2873A 10:1 Divider Passive Probe (one per scope channel)

• Channel Flying Lead Set Logic Probe, MSO Cable, and Calibration Fixture (MSO models only)

• Keysight I/O Libraries Suite 15.0

Specifications and Characteristics

For complete specifications and characteristics, direct your web browser to www.keysight.com and

perform a search for the oscilloscope’s model number. Then select “Data Sheets” from the Library.

Specifications that are pertinent to each test are given in the "Testing Performance" chapter.

Specifications are valid after a 30-minute warm-up period, and within ± 5°C from the temperature at

which the last self-calibration was performed.

Chapter 1: General Information

Environmental Conditions

Overvoltage Category

This product is intended to be powered by MAINS that comply to Overvoltage Category II, which is

typical of cord-and-plug connected equipment.

Pollution Degree

The 9000 Series oscilloscope may be operated in environments of Pollution Degree 2 (or Pollution

Degree 1).

Pollution Degree Definitions

Pollution Degree 1: No pollution or only dry, non-conductive pollution occurs. The pollution has no

influence. Example: A clean room or climate controlled office environment.

Pollution Degree 2. Normally only dry non-conductive pollution occurs. Occasionally a temporary

conductivity caused by condensation may occur. Example: General indoor environment.

Pollution Degree 3: Conductive pollution occurs, or dry, non-conductive pollution occurs which

becomes conductive due to condensation which is expected. Example: Sheltered outdoor environment.

Measurement Category

The Keysight Infiniium 9000 Series oscilloscopes are not rated for Measurement Category II, III, or IV.

Measurement Category Definitions

Measurement Category II is for measurements performed on circuits directly connected to the low

voltage installation. Examples are measurements on household appliances, portable tools and similar

equipment.

Measurement Category III is for measurements performed in the building installation. Examples are

measurements on distribution boards, circuit-breakers, wiring, including cables, bus-bars, junction

boxes, switches, socket-outlets in the fixed installation, and equipment for industrial use and some other

equipment, for example, stationary motors with permanent connection to the fixed installation.

Measurement Category IV is for measurements performed at the source of the low-voltage installation.

Examples are electricity meters and measurements on primary overcurrent protection devices and ripple

control units.

Transient Withstand Capability

The maximum transient withstand capability of this instrument is not specified. Do not apply more than

5 volts rms at the oscilloscope’s vertical input BNC connectors.

WARNING SAFETY CLASS 1 PRODUCT

This is a Safety Class 1 Product (provided with a protective earth ground incorporated in the power

cord). The mains plug shall only be inserted in a socket outlet provided with a protective earth contact.

Any interruption of the protective conductor inside or outside of the product is likely to make the product

dangerous. Intentional interruption is prohibited.
