Keysight M9185A Guide de l'utilisateur
Keysight M9185A PXI
Isolated 8/16-Channel D/A
Converter
Startup
Guide
M9185A Startup Guide I
II M9185A Startup Guide
Notices
© Keysight Technologies 2011, 2014
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Keysight
Technologies as governed by United States
and international copyright laws.
Manual Part Number
M9185-90001
Edition
Edition 3, November 2014
Keysight Technologies
1400 Fountaingrove Parkway
Santa Rosa, CA 95403
Sales and Technical Support
To contact Keysight for sales and technical
support, refer to the "support" links on the
following Keysight web resources:
•www.keysight.com/find/M9185A
(product-specific information and
support, software and documentation
updates)
•www.keysight.com/find/assist
(worldwide contact information for
repair and service)
Information on preventing damage to your
Keysight equipment can be found at
www.keysight.com/find/tips.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Keysight disclaims all warran-
ties, either express or implied, with
regard to this manual and any infor-
mation contained herein, including
but not limited to the implied warran-
ties of merchantability and fitness for
a particular purpose. Keysight shall
not be liable for errors or for inciden-
tal or consequential damages in con-
nection with the furnishing, use, or
performance of this document or of
any information contained herein.
Should Keysight and the user have a
separate written agreement with
warranty terms covering the material
in this document that conflict with
these terms, the warranty terms in the
separate agreement shall control.
Restricted Rights Legend
If software is for use in the performance of a
U.S. Government prime contract or subcon-
tract, Software is delivered and licensed as
“Commercial computer software” as
defined in DFAR 252.227-7014 (June 1995),
or as a “commercial item” as defined in FAR
2.101(a) or as “Restricted computer soft-
ware” as defined in FAR 52.227-19 (June
1987) or any equivalent agency regulation or
contract clause. Use, duplication or disclo-
sure of Software is subject to Keysight
Technologies’ standard commercial license
terms, and non-DOD Departments and
Agencies of the U.S. Government will
receive no greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users will receive
no greater than Limited Rights as defined in
FAR 52.227-14 (June 1987) or DFAR
252.227-7015 (b)(2) (November 1995), as
applicable in any technical data.
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and
met.
The following safety precautions should be
observed before using this product and any
associated instrumentation.
This product is intended for use by qualified
personnel who recognize shock hazards and
are familiar with the safety precautions
required to avoid possible injury. Read and
follow all installation, operation, and main-
tenance information carefully before using
the product. Refer to the user documenta-
tion for complete product specifications.
M9185A Startup Guide III
WARNING
If this product is not used as spec-
ified, the protection provided by
the equipment could be impaired.
This product must be used in a
normal condition (in which all
means for protection are intact)
only.
The types of product users are:
• Responsible body is the individual or
group responsible for the use and main-
tenance of equipment, for ensuring that
the equipment is operated within its
specifications and operating limits, and
for ensuring that operators are ade-
quately trained.
• Operators use the product for its
intended function. They must be trained
in electrical safety procedures and
proper use of the instrument. They must
be protected from electric shock and
contact with hazardous live circuits.
• Maintenance personnel perform rou-
tine procedures on the product to keep
it operating properly (for example, set-
ting the line voltage or replacing con-
sumable materials). Maintenance
procedures are described in the user
documentation. The procedures explic-
itly state if the operator may perform
them. Otherwise, they should be per-
formed only by service personnel.
• Service personnel are trained to work
on live circuits, perform safe installa-
tions, and repair products. Only properly
trained service personnel may perform
installation and service procedures.
Exercise extreme caution when a shock
hazard is present. Lethal voltage may be
present on cable connector jacks or test fix-
tures. The American National Standards
Institute (ANSI) states that a shock hazard
exists when voltage levels greater than 30V
RMS, 42.4V peak, or 60VDC are present.
A good safety practice is to expect that haz-
ardous voltage is present in any unknown
circuit before measuring.
Operators of this product must be protected
from electric shock at all times. The respon-
sible body must ensure that operators are
prevented access and/or insulated from
every connection point. In some cases, con-
nections must be exposed to potential
human contact. Product operators in these
circumstances must be trained to protect
themselves from the risk of electric shock.
Before operating an instrument, ensure that
the line cord is connected to a prop-
erly-grounded power receptacle. Inspect the
connecting cables, test leads, and jumpers
for possible wear, cracks, or breaks before
each use.
When installing equipment where access to
the main power cord is restricted, such as
rack mounting, a separate main input power
disconnect device must be provided in
closed proximity to the equipment and
within easy reach of the operator.
For maximum safety, do not touch the prod-
uct, test cables, or any other instruments
while power is applied to the circuit under
test. ALWAYS remove power from the entire
test system and discharge any capacitors
before: connecting or disconnecting cables
or jumpers, installing or removing switching
cards, or making internal changes, such as
installing or removing jumpers.
Do not touch any object that could provide a
current path to the common side of the cir-
cuit under test or power line (earth) ground.
Always make measurements with dry hands
while standing on a dry, insulated surface
capable of withstanding the voltage being
measured.
The instrument and accessories must be
used in accordance with its specifications
and operating instructions, or the safety of
the equipment may be impaired.
CAUTION
• Do not exceed the maximum signal
levels of the instruments and
accessories, as defined in the
specifications and operating
information, and as shown on the
instrument or test fixture panels, or
switching card.
• Chassis connections must only be
used as shield connections for
measuring circuits, NOT as safety
earth ground connections.
• If you are using a test fixture, keep
the lid closed while power is
applied to the device under test.
Safe operation requires the use of a
lid interlock.
• Instrumentation and accessories
shall not be connected to humans.
To maintain protection from electric shock
and fire, replacement components in mains
circuits - including the power transformer,
test leads, and input jacks - must be pur-
chased from Keysight. Standard fuses with
applicable national safety approvals may be
used if the rating and type are the same.
Other components that are not
safety-related may be purchased from other
suppliers as long as they are equivalent to
the original component (note that selected
parts should be purchased only through
Keysight to maintain accuracy and function-
ality of the product). If you are unsure about
the applicability of a replacement compo-
nent, call a Keysight office for information.
WARNING
No operator serviceable parts
inside. Refer servicing to qualified
personnel. To prevent electrical
shock do not remove covers.
IV M9185A Startup Guide
Front and Rear Panels Symbols
The CE mark is a registered trade-
mark of the European Community.
The C-Tick mark is a registered
trademark of the Australian Spec-
trum Management Agency.
This symbol indicates
product compliance with
the Canadian Interfer-
ence-Causing Equipment Standard
(ICES-001). It also identifies the product is
an Industrial Scientific and Medical Group 1
Class A product (CISPR 11, Clause 4).
This symbol indicates separate
collection for electrical and elec-
tronic equipment, mandated under
EU law as of August 13, 2005. All
electric and electronic equipment are
required to be separated from normal waste
for disposal (Reference WEEE Directive,
2002/96/EC).
This symbol indicates the time
period during which no hazard-
ous or toxic substance elements
are expected to leak or deterio-
rate during normal use. Forty years is the
expected useful life of the product.
Cleaning Precautions
WARNING
To prevent electrical shock, dis-
connect the Keysight Technolo-
gies instrument from mains before
cleaning. Use a dry cloth or one
slightly dampened with water to
clean the external case parts. Do
not attempt to clean internally. To
clean the connectors, use alcohol
in a well-ventilated area. Allow
all residual alcohol moisture to
evaporate, and the fumes to dissi-
pate prior to energizing the instru-
ment.
M9185A Startup Guide V
Contents
Introduction 1
Related documentation 1
Step 1: Unpack and Inspect the Module 2
ESD precaution 2
Inspect the module for damage 3
Return the module for service 4
Step 2: Verify the Shipment Contents 5
Step 3: Install the Software 6
System requirements 6
Power up the controller 8
Install the softwares 8
Step 4: Install the Module 10
M9185A front panel for 8-channel and 16-channel 14
M9185A system connections 20
Step 5: Verify the Operation of the M9185A Module 21
Conduct performance verification (optional) 24
Specifications 26
VI M9185A Startup Guide
THIS PAGE IS INTENTIONALLY LEFT BLANK.
Keysight M9185A PXI D/A Converter
M9185A Startup Guide 1
Introduction
The scope of this Startup Guide is to detail the processes of
receiving and setting up the Keysight M9185A PXI Isolated
8/16- Channel D/A Converter, installing the required
software, and verifying basic module operation.
If you have any questions after reviewing this information,
please contact your local Keysight Technologies
representative or contact us through our Web site at
http://www.keysight.com/find/M9185A.
Related documentation
A softcopy of this Startup Guide, and the documentation
listed below, can be found on the CD- ROM that is shipped
with this product. You can also download them for free
through our Web site at www.keysight.com/find/M9185A.
Check the manual revision on the first page of each manual.
•StartupGuide. This manual. Printed copy for outdoor
use, included with shipment.
• Keysight M9185A PXI D/A Converter Device Drivers
and Help. Available for IVI- C and IVI- COM, and LabVIEW
G drivers.
• Keysight M9185A PXI D/A Converter Soft Front Panel
Software and Help.
• Keysight M9185A PXI D/A Converter Data Sheet.
2M9185A Startup Guide
Keysight M9185A PXI D/A Converter
Step 1: Unpack and Inspect the Module
ESD precaution
Electrostatic discharge (ESD) can damage or destroy
electronic components. All work on electronic assemblies
should be performed at a static- safe work station. The
following figure shows an example of a static- safe work
station using two types of ESD protection.
Figure 1 Static-safe work station example
CAUTION
The M9185A is shipped in materials which prevent damage from static.
The module should only be removed from the packaging in an
anti-static area after ensuring that correct anti-static precautions are
taken. Store all modules in anti-static envelopes when not in use.
Table des matières
Autres manuels Keysight Convertisseur de média
Keysight
Keysight N7004A Manuel utilisateur
Keysight
Keysight N7004A Manuel utilisateur
Keysight
Keysight E1418A Series Manuel utilisateur
Keysight
Keysight M9361A Guide de l'utilisateur
Keysight
Keysight APM0100E Manuel utilisateur
Keysight
Keysight LPDDR5 Manuel utilisateur
Keysight
Keysight E1418A Series Manuel utilisateur
Keysight
Keysight M9710A Guide de l'utilisateur
Keysight
Keysight 34951A Manuel utilisateur
Keysight
Keysight N9029ACST Manuel utilisateur
