Installation Note N9020-90268 7
Option PFR Precision Frequency Reference Installation Kit
Utilities, Adjustments, and Performance Verification Tests
Calibration Software and specified test equipment is required to perform the adjustments, and can
be used to automate the performance verification testing. Information on how to obtain this
software can be found at
http://www.keysight.com/find/calibrationsoftware
Utilities Required
None
Adjustments Required
If the instrument is more than one year old, or if this instrument has been adjusted as part of
calibration or repair during its first year, the following adjustments are the minimum set required to
ensure that this newly installed option is functioning properly.
Performance Testing Required
If the instrument is more than one year old, or if the instrument has been adjusted as part of a
calibration or repair during its first year, the following performance verification tests are the
minimum set required to ensure that this newly installed option is functioning properly. Performing
only these tests does not guarantee the instrument meets all specifications.
A full calibration is required to assure the instrument meets all specifications
The end user must ultimately determine whether they want a full calibration to be performed after
the installation of this upgrade or not. If a full calibration is required, arrangements regarding the
level of calibration must be made between the end user and the calibration provider.
For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your
local Keysight office access the following URL, or if in the United States, call the following
telephone number:
http://www.keysight.com/find/assist
1-800-829-4444 (8 am - 8 pm ET, Monday - Friday)
Adjustments
10 MHz Reference Adjustment
Performance Verification Tests
Displayed Average Noise Level
10 MHz Frequency Reference Accuracy
Marker Count Accuracy
