45
When programming a User Access Code and you
are not sure of the next available location, you
can use this feature to exactly locate the next
available slot using the same procedure as the
“Code Locator Feature”.
[Master/Sub-Master/Manager Code] (#) (0) (0) (0)
EXAMPLE:
Assuming that the current Master, Sub-Master or
Manager Code is (1) (2) (3) (4) (5) and you want to
locate the next available location.
1. Press (1) (2) (3) (4) (5) ●(#) (0) (0) (0) ●●
2. At the start of the “Next Available Location
finder” sequence, the unit will flash both the BLUE
and RED LED and emit one long beep.
3. The unit will identify the Group number by
flashing the BLUE LED (with beeps) from 0 to 9
times.
4. To signify the end of the Group ID sequence,
the unit will flash both the BLUE and RED LED with
a long beep.
5. The unit will identify the User number by
flashing the BLUE LED (with beeps) from 0 to 9
times.
6. To signify the end of the Group ID sequence,
the unit will flash both the BLUE and RED LED with
a long beep.
No flash or tone means the corresponding
number is zero. If no available location is found,
the unit will a programming error tone.
A) NEXT AVAILABLE LOCA-
TION FINDER: PROGRAM 000
It is important to record all Codes in Group Table
for future reference. In the event of losing your
records, this feature will help you locate as to
where a certain Code is located in the lock’s
memory. The unit will identify the Group number
(0-9) and User location (09) by flashing both the
RED and BLUE LED accompanied by a beeping
sound.
B) CODE LOCATOR
FUNCTION: PROGRAM 009
[Master/Sub-Master/Manager Code] (#) (0) (0) (9)
[Enter Code to be located]
EXAMPLE:
Assuming that the current Master, Sub-Master or
Manager Code is (1) (2) (3) (4) (5) and you want to
search for code: (1) (2) (3) (4) (5).
1. Press (1) (2) (3) (4) (5) ●(#) (0) (0) (9) ●(1) (2) (3)
(4) (5) ●●
2. If the code entered is recognized, the following
sequence will occur:
a) At the start of the Code Locator sequence,
the unit will flash both the BLUE and RED LED
and emit one long beep.
b) The unit will identify the Group number by
flashing the BLUE LED (with beeps) from 0 to
9 times.
c) To signify the end of the Group ID
sequence, the unit will flash both the BLUE
and RED LED with a long beep.
d) The unit will identify the User number by
flashing the BLUE LED (with beeps) from 0 to
9 times.
e) To signify the end of the Group ID
sequence, the unit will flash both the BLUE
and RED LED with a long beep.
3. If the Code is not recognized, the lock will
sound one long beep with a RED LED.
NOTE: If the Group or User Number is zero,
the BLUE LED will not flash and no beep can
be heard.
Service Codes are single-entry Codes. They can
only be entered or used once. This unit can be
programmed to accept 5 Service Codes. It may be
the same code used 5 times, or it may vary from
each. Service Code numbers are 011, 012, 013, 014
and 015.
Service Code 1:
[Master, Sub-Master, Manager Code] (#) (0)
[Service Code Number] [Enter new Service Code]
C) ADD SERVICE CODES: PRO-
GRAM 011, 012, 013, 014, 015
EXAMPLE:
Assuming that the current Master, Sub-Master or
Manager Code is (1) (2) (3) (4) (5) and you want to
program Service Code1 with(3) (4) (5) (6) (7).
1. Press (1) (2) (3) (4) (5) ●(#) (0) (1) (1) ●(3) (4) (5)
(6) (7) ●●
2. Service Code 1 is now programmed for 1 entry
with (3) (4) (5) (6) (7) passcode.
3. Repeat procedure for other Service Codes.
[Master, Sub-Master, Manager Code] (#) (0)
[Service Code Number]
EXAMPLE:
Assuming that the current Master, Sub-Master or
Manager Code is (1) (2) (3) (4) (5) and you want to
delete Service Code 1.
1. Press (1) (2) (3) (4) (5) ●(#) (0) (2) (1) ●●
2. Service Code 1 is now deleted.
3. Repeat procedure for other Service Codes.
See table below for quick reference.
D) DELETE SERVICE
CODES: PROGRAM 021,
022, 023, 024, 025
SERVICE
CODES ADD DELETE
1 011 021
2 012 022
3 013 023
4 014 024
5 015 025
Master, Sub-Master and Managers can delete all
Service Codes.
[Master/Sub-Master/Manager Code] (#) (0) (2) (#)
E) DELETE ALL SERVICE
CODES: PROGRAM 02#
EXAMPLE:
Assuming that the current Master, Sub-Master or
Manager Code is (1) (2) (3) (4) (5) and you want to
delete all Service Codes.
1. Press (1) (2) (3) (4) (5) ● (#) (0) (2) (#) ●●
2. All Service Codes are now deleted.
Manager Codes are located at locations 00, 10,
20, 30, 40, 50, 60, 70, 80 and 90 (see Group
Table on page 9).
NOTE: New Manager Codes must use the same
number of digits as the (new) Master Code.
[Current Master/Sub-Master Code] (#) (1) [2-digit
Location Code] [New Manager Code]
EXAMPLE:
Assuming that the current Master or Sub-Master
Code is (1) (2) (3) (4) (5) and you want to add a new
Manager Code of (3) (4) (5) (6) (7) in location 20.
1. Press: (1) (2) (3) (4) (5) ●(#) (1) (2) (0) ●(3) (4) (5)
(6) (7) ●●
2. The unit will unlock upon entering the Master
Code and will remain unlocked while initiating the
program sequence.
3. Wait at least 5 seconds before trying your
Manager Code.
F) ADD/CHANGE A MANAGER
CODE: PROGRAM 1XX
User Codes are located at locations 01-09, 11-19,
21-29, 31-39, 41-49, 51-59, 61-69, 71-79, 81-89 and
91-99 (see Group Table on page 9).
NOTE: New User Codes must use the same
number of digits as the (new) Master Code.
[Current Master/Sub-Master/Manager Code] (#)(1)
[2-digit User Location] [New User Code]
EXAMPLE: Assuming that the current Master, Sub-
Master or Manager Code is (1) (2) (3) (4) (5) and
you want to add a new User Code of (3) (4) (5) (6)
(7) in location 21.
F) ADD/CHANGE A USER
CODE: PROGRAM 1XX
