Keurig Eccellenza touch Manuel utilisateur
1
ECCELLENZA TOUCH™CLEANING & STARTUP PROCEDURE
This procedure demonstrates how to properly clean
and sanitize the Eccellenza Touch™brewer
This procedure should take approximately 60 minutes
Tools Needed
Keurig®Bean to Cup Deep Cleaning kit (if available)
Large bucket or container
Available sink
Slotted screwdriver
Key to main door
Small paint brush
2
Table of Contents
Disconnecting & Draining ………………………………………………. Pg. 3
Removing the Brewer Assembly ………………………………………. Pg. 4
Removing the Coffee Hopper ………………………………………….. Pg. 5
Removing the Powder System ………………………………………… Pg. 6 - 9
Cleaning & Sanitizing Procedure ……………………………………… Pg. 10
Cleaning Interior & Exterior Components …………………………….. Pg. 11
Reinstalling the Powder System ………………………………………. Pg. 12
Reinstalling the Brewer Assembly …………………………………….. Pg. 13
Reinstalling the Coffee Hopper ………………………………………… Pg. 14
Restarting & Refilling ……………………………………………………. Pg. 15
How to Perform Both Cleanings & Rinses ……………………………. Pg.'s 16 - 20
Performing Test Brews ………………………………………………….. Pg. 21
Note: Cleaning: Refers to generally wiping down/removing debris or spills from surfaces.
Sanitization: Refers to using a disinfecting solution, wipe, or a cloth with disinfectant on it
to help eliminate contaminants and germs.
3
Disconnecting & Draining
Turn power switch to O position and unplug
from grounded outlet.
Turn machine around to access back cover and
remove 4 screws and lift back cover up and
away from machine.
Note: Water supply may need to be disconnected to
achieve above step.
Locate drain hose, open valve, drain hot water
into a large bucket or water-tight container then
close valve and restow.
Replace back panel with the 4 screws.
Note: Ensure back panel lower tabs are
inserted correctly.
CAUTION
WATER MAY BE VERY HOT
Shown with factory installed tape
4
Removing the Brewer Assembly
Turn machine back around to front.
Remove waste container, empty & clean.
Insert key and turn counterclockwise then open
main door.
Remove coffee spout from
front of brewer assembly.
Remove brewer assembly by
pressing red button and turning
to the clockwise while lifting.
Carefully remove wiper and
thoroughly clean exterior of
both parts.
NOTE: Brewer assembly cleaning
instructions can be found on page
17.
5
Removing the Coffee Hopper
LOOSEN ONLY the two screws beneath the coffee hopper.
Lift coffee hopper from unit and remove.
If necessary, discard coffee beans and wipe down or thoroughly clean.
NOTE: See cleaning instructions on page 11.
6
Removing the Powder System
Disconnect hoses to mixing chambers. Unlock and remove mixing chambers.
Remove mixing disks by sliding forward from
the whipper motor shaft.
Remove locking rings.
7
Removing the Powder System cont.
Grab and pull towards you to remove powder
drawer.
Lift powder lid.
Remove powder hopper caps. Carefully remove powder hopper liner.
8
Removing the Powder System cont.
Disconnect hot water hose and all hoses.
Clean and sanitize all removed powder system parts in
accordance with the Cleaning & Sanitizing procedure on page 11.
NOTE: We recommend cleaning and sanitizing all parts with Urnex®products from
the Keurig®Bean to Cup Deep Cleaning Kit, but comparable agents may also be
used
9
Removing the Powder System cont.
Remove and empty powder hoppers.
NOTE: If needed, hoppers can be disassembled (shown below) then cleaned
and sanitized following instructions on page 11.
Otherwise they can just be refilled following instructions on page 21.
10
Cleaning Interior & Exterior Components
Wipe interior area around the brewer motor
and powder system with a clean cloth dipped
in Urnex®Complete Café sanitizer.
NOTE: If available, Urnex®Café Wipz can be used.
Remove and wipe down or clean cup stand &
grill using cleaning instructions on page 11.
We recommend using the Urnex®Complete Café solution noted on Page 11 on all external
surfaces ONLY. But any household or commercial certified disinfectant wipe can be used
(following manufacturer's instructions).
