PORTABLE CD PLAYER

DPC-181/183/381/382/383

SERVICE MANUAL

VOLUME

PHONES

LINE OUT

DC-IN

REPEAT

P.MODE

OPEN

VOLUME

PHONES

LINE OUT

OFF

Knob (P. MODE)

(K27-2252-08)

Knob

(K27-2244-08)

Display lens

(B10-2416-08)

CD door *

(A52-)

Top cabinet*

(A02-)

Knob

(K27-2245-08)

Knob (OPEN)

(K27-2243-08)

Knob (SKIP/SEARCH)

(K27-2246-08) Knob (PLAY/STOP)

(K27-2247-08) Variable resistor

(R31-0086-08)

Display lens *

(B10-)

CD door lens *

(B10-)

CD door *

(A52-)

Variable resistor

(R31-0086-08)

Knob (REPEAT)

(K27-2253-08)

Knob (SKIP/SEARCH)

(K27-2256-08)

Knob (OPEN)

(K27-2251-08)

Knob (PLAY/STOP)

(K27-2255-08)

Knob (SKIP/SEARCH)

(K27-2257-08)

Illust is DPC-183/383.

* Refer to parts list on page 13.

Illust is DPC-181/381/382.

In compliance with Federal Regulations, following are reproduc-

tions of labels on, or inside the product relating to laser product

safety.

KENWOOD-Corp. certifies this equipment conforms to DHHS

Regulations No. 21 CFR 1040. 10, Chapter 1, Subchapter J.

DANGER : Laser radiation when open and interlock defeated.

AVOID DIRECT EXPOSURE TO BEAM.

DPC-183/383(k)1P98.4.243:25PM y[W 2

DPC-181/183/381/382/383

CONTENTS / ACCESSORIES

MODEL

FEATURE

Contents

CONTENTS / ACCESSORIES ....................................2

CIRCUIT DESCRIPTION.............................................3

PC BOARD ..................................................................5

SCHEMATIC DIAGRAM..............................................9

EXPLODED VIEW .....................................................13

PARTS LIST...............................................................15

SPECIFICATIONS.....................................................19

Model feature list

K P E T M M2 X K P E T M X K P E T M M2 K P E T M X K P E T M M2

‡ ‡

‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡ ‡‡‡‡‡‡‡‡‡‡‡

‡ ‡ ‡ ‡ ‡ ‡

‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡

‡‡‡‡‡‡‡‡‡‡‡‡‡

‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡‡

‡‡‡‡‡‡‡‡‡‡‡‡‡

OPTICAL

OUT

LINE OUT

REMOTE

TERMINAL

DASC

KNOB

B.B KNOB

B.BOOST

P.MODE

DPC-181 DPC-183 DPC-381 DPC-382 DPC-383

Accessories

AC adapter(110~120V /220-240V 50/60Hz)...............(1)

(W08-0657-08) : KP

(W08-0658-08) : E

(W08-0659-08) : T

(W08-0660-08) : X

(W08-0667-05) : M,M2

Innerphone..........................................(1)

(W01-0925-05) : DPC-181(MXTE)

DPC-183(X)

DPC-381(TE)

(W01-0923-05) : DPC-181(M2)

DPC-183(M)

DPC-381(M,M2)

DPC-383(M2)

AC plug..........................................(1)

(E03-0115-05) : M,M2

Rechargeable battery.....................(1)

(W09-1239-05) : KP

(W09-1240-05) : ETMXM2

Audio cable....................................(1)

(E30-2782-05) : DPC-381(E.T)

Car battery adapter........................(1)

(W01-0921-05) : DPC-382

Car cassette adapter......................(1)

(W01-0922-05) : DPC-382 Remote control...............................(1)

(A70-1190-05) : DPC-381/383 (M,M2)

Remote control...............................(1)

(A70-1111-08) :DPC-181 (M2)

DPC-183 (M)

Headphone ....................................(1)

(W01-0924-05) : DPC-181(KP)

(W01-0943-05) : DPC-381(KP)

(T17-0015-08) : DPC-383(M)

(T17-0016-08) : DPC-383(KPETX)

DPC-183/383(k)1P98.4.243:26PM y[W 3

DPC-181/183/381/382/383

CIRCUIT DESCRIPTION

1. Microprocessor : (MN171603 H3)

1–1 Pin description

Pin No. Pin name I/O Function description Active

1, 2 – I NOT USED

3 AVSS – GND

4 BBS O BBS CONTROL SIGNAL OUTPUT ON = "H"

5 DATA O REMOTE CONTROL SIGNAL OUTPUT

6, 7 – NOT USED

8 KEY I KEY INPUT

9 HOLD I HOLD ON/OFF CONTROL ON = "H"

10 ESP I ESP ON/OFF CONTROL ON = "L"

11 LOW BATTERY I BATTERY VOLTAGE DETECTION LOW BATT. = "H"

12 AVDD – SUPPLY VOLTAGE

13~15 VLC1~VLC3 – LCD DRIVER BIAS CONTROL

16~19 COM1~COM4 O LCD COMMON SIGNAL OUTPUT (COMMON1~4)

20~33 SEG0~SEG13 O LCD SEGMENT SIGNAL OUTPUT (SEG0~SEG13)

34, 35 SEG14, 15 O NOT USED

36 MODE-M I MEMORY SELECT 4M = "H" OTHER = "L"

37 D-CNT I DIGITAL OUT CONTROL OUT = "H" (ESP OFF)

38 MODE-A I USE CUE/REV MODE

39 MODE-B I NOT USED

40 STDBY O NOT USED

41~44 – – NOT USED

45 DOOR OPEN I DOOR SWITCH DETECTION OPEN = "H"

46 PSET I PICKUP INITIAL POSITION

47 BTCHK I BATT. VOLTAGE DIRECTION.

48~51 – I NOT USED

52 POWER O POWER SUPPLY CONTROL.

53 BAT O BATTERY CONTROL OUTPUT CHARGING = "H"

54 D MUTE O MUTE CONTROL ON = "H"

55 SBCK O SUB CODE READ TIMING CLOCK FOR MN662740RE

56 FCLK I FRAME CLOCK SIGNAL from MN662740RE

57 FLAG I FLAG SIGNAL INPUT from MN662740RE

58 IPFLAG I CORRECTION = "H"

59 – I GND

60 STAT I STATUS SIGNAL from DSP

61 SENSE I SENSITIVE SIGNAL from DSP

62 TLOCK I TRACKING SERVO IN = "L"

63 FLOCK I FOCUSING SERVO IN = "L"

64 MCLK O COMMAND CLOCK for MN662740RE

65 MDATA O COMMAND DATA for MN662740RE

66 MLD O COMMAND DATA LATCH (LOAD) for MN662740RE

67 – O NOT USED

68 RST I SYSTEM RESET INPUT

69 X1 I GND

70 X2 O NOT USED

71 Vss – GND

72 – O NOT USED

73 SMCK I EXTERNAL SYSTEM CLOCK = 4.2336MHz

DPC-183/383(k)1P98.4.243:26PM y[W 6

DPC-181/183/381/382/383

CIRCUIT DESCRIPTION

Pin No. Pin name I/O Function description Active

74 VDD – SUPPLY VOLTAGE (ESP ON = 4.2V / OFF = 3.2V)

75 LRST O RESET SIGNAL for MN662740RE, SM5859AF

76 SQCK O SUBQ READ TIMING CLOCK to MN662740RE

77 SUBQ I SUBQ DATA from MN 662740RE

78 – O NOT USED

79 YMLD O COMMAND DATA LATCH (LOAD) for SM5859AF

80 YMCLK O COMMAND CLOCK for SM5859AF

81 ZSENSE I SENSITIVE SIGNAL from SM5859AF

82 YMDATA O COMMAND DATA for SM5859AF

83 BLKCK I SUBQ READ REQUEST SIGNAL IN.

84 – I GND

1-2 Voltage of pin No. 8 (IC3) / Key function.

KEY V Key of unit (Remocon)

0.00 PLAY/PAUSE (6)

0.75 STOP (7)

1.00 UP (¢)

1.23 B. BOOST / P. MODE

1.43 DOWN (4)

1.69 REPEAT

2.13 MUTE (Only Remocon)

2.55 KEY OFF

3.0

1-3 Microprocessor periphery block diagram

(KSM-542AAA)

/ / /

IC5

SHOCKPLOOF

SM5859AF

IC6

DRAM

FROM IC4 (Rch)

J105

EXCEPT

DPC-381/383 (M2 TYPE)

LINE OUT

J102

Rch

Lch H. P JACK

NJM2073M

VOLUME

DIGITAL OUTPUT J104 OPT. OUT

DPC-381/383 (M2 TYPE)

J103

REMOTE

DPC-181 (M2 TYPE)

DPC-183 (M TYPE)

DPC-381/383 (M/M2 TYPE)

MN171603

HFC

AN8819

NFB-M

LMT.

AN8806SB

DPC-381/382/383 ONLY

Lch

DPC-183/383(k)1P98.4.243:26PM y[W 7

ACEBD

Refer to the schematic diagram for the value of resistors and capacitors.

PC BOARD(Component side view) : DPC-181/381/382
