GENERAL INFORMATION
___________________________________________________________________________________________
COVERING: SAFETY PRECAUTIONS AND PLACING INTO SERVICE
___________________________________________________________________________________________
READ THIS MANUAL CAREFULLY BEFORE INSTALLING, OPERATING OR SERVICING THIS
TOOL
_____________________________________________________________________________________________________
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THIS INFORMATION INTO THE HANDS OF THE OPERATOR.
_____________________________________________________________________________________________________
PLACING INTO SERVICE
_____________________________________________________________________________________________________
=Hazards or unsafe practices which could result in severe personal injury, death or
substantial property damage.
= Hazards or unsafe practices which could result in minor personal injury, product or
property damage.
=Important installation, operation or maintenance information.
Installation, adjustment repair and maintenance of this tool must be made by trained
and qualified personnel.
Always disconnect power supply from tool before:
(A) Installing or removing blade from tool.
(B) Making repairs or adjustments to the tool.
(C) performing maintenance or cleanup work.
INSTALLATION INSTRUCTIONS
ONLY TRAINED AND QUALIFIED PERSONNEL ARE TO PERFORM MAINTENANCE
AND SERVICE TO THIS TOOL.
8. MAKE ALL NECESSARY LINE CONNECTIONS TO THE TOOL.
9. AN AIR FILTER-REGULATOR-LUBRICATOR (PART NO. 7200030) MUST BE INSTALLED IN AIR SUPPLY
10. FILL LUBRICATOR WITH KENTMASTER AIR MIST OIL (PART NO. 7903050). SET DRIP RATE ACCORDING TO
INSTRUCTIONS SUPPLIED. TURN ADJUSTMENT ON SIGHT FEED DOME TO INCREASE/DECREASE OIL DELIVERY.
MONITOR THE DEVICE BEING LUBRICATED AND READJUST IF NEEDED.
11. TOOL REQUIRES GREASING AT START OF EACH SHIFT. GREASE FOUR (4) LOCATIONS USING KENTMASTER
GREASE GUN (PART NO. 4501470) AND GREASE (PART NO. 7903070).
12. TOOL REQUIRES 40 S.C.F.M. OF AIR @ 90 P.S.I. AIR PRESSURE.
13. FLUSH AIR MOTOR AT END OF EACH DAY’S USE BY SQUIRTING A FEW SQUIRTS OF KENTMASTER AIR OIL MIST
(PART 7903050) DIRECTLY INTO THE AIR INLET PORT. RUN TOOL A FEW SECONDS TO COAT AND PROTECT THE
AIR MOTOR AND INTERNAL PARTS OF TOOL
14. A BALANCER IS REQUIRED FOR OPERATION AND USE OF THIS TOOL. WEIGHT OF TOOL MUST FALL WITHIN
WEIGHT RANGE OF BALANCER.
15. INSTALL BALANCER ABOVE WORK AREA. BALANCER MUST HAVE SUFFICIENT VERTICAL TRAVEL SO OPERATOR
CAN REACH ENTIRE WORK AREA WITH TOOL WITHOUT STRAIN.
16. ADJUST BALANCER ACCORDING TO THE OPERATOR'S PREFERENCE AND COMFORT.
