KENT 13 Manuel utilisateur

SelectLine 13, 17, 20

SelectLine 17HD, 20HD, 20TS

7/05 revised 8/06 FORM NO. 71052A

PARTS LIST

KENT Models: 01283A (13); 01300A (17); 01380A (20);

01340A (17HD); 01420A (20HD); 01450A (20TS)

FORMNO.71052A

05-7

2TABLE OF CONTENTS

DESCRIPTION PAGE

Optional Accessories ............................................................................... 3

Assembly Drawing.................................................................................... 4

Assembly Parts List.................................................................................. 5

WiringDiagram ......................................................................................... 5

WHENORDERINGPARTS

* Use the 6 or 8 digit numbers from the “Part No.” columns in this parts list.

* Specify the model and serial number of the machine.

* Use the space below to record the model and serial number for future reference.

Model Serial No.

FORMNO.71052A

05-7

OPTIONALACCESSORIES

Part No. Description

56172305 Splash Guard Assembly (17 Models)

56172313 Splash Guard Assembly (20 Models)

53853A Solution Tank Kit (All Models)

11022A Weight Kit (HD Models only)

56020194 Bassine Brush 13

56020196 Union Mix Brush 13

56020200 Steel Brush 13

56020223 Polypropylene Brush 13

56020309 Nylon Medium Grit Brush 13

56505910 Short-Trim Pad Holder 17 (w/pad centering device)

56505270 Level-Set Pad Holder 17

56505915 ProLite™ Brush 17

56505914 Prolene Brush 17

56505911 MagnaGrit™ 46 Brush 17

56505912 DynaGrit™ 80 Brush 17

56505918 MidLite Grit™ 180 Brush 17

56505917 MidGrit™ 240 Brush 17

56505913 AgLite™ 500 Brush 17

56505916 Union Mix Brush 17

56505539 Soft-Touch™ Shampoo Brush 17

56505920 Short-Trim Pad Holder 20 (w/pad centering device)

56505280 Level-Set Pad Holder 20

56505925 ProLite™ Brush 20

56505924 Prolene Brush 20

56505921 MagnaGrit™ 46 Brush 20

56505922 DynaGrit™ 80 Brush 20

56505928 MidLite Grit™ 180 Brush 20

56505927 MidGrit™ 240 Brush 20

56505923 AgLite™ 500 Brush 20

56505926 Union Mix Brush 20

56505540 Soft-Touch™ Shampoo Brush 20

56506006 NP-92 Clutch Plate-Nylon Replacement

56506007 NP-92 Clutch Plate-Zinc Replacement

56161750 Brown Stripping Pad, 17” (case of 5)

56161716 Blue Scrubbing Pad, 17” (case of 5)

56161738 Blue Scrubbing Pad, 20” (case of 5)

56161737 Red Buffer Pad, 20” (case of 5)

56505019 Pad Centering Unit (includes 56393567) (for use w/56505910 and 56505920)

56393567 “Big Mouth” Pad Retainer (for use w/56505910 and 56505920)

NOTE: Pad Holders and Brushes come complete with Industry Standard NP-92 Clutch Plate.

SelectLine 13, 17, 20, 17HD, 20HD, 20TS

OPTIONALACCESSORIES

06-6

FORMNO.71052A

05-7

4SelectLine 13, 17, 20, 17HD, 20HD, 20TS

ASSEMBLY DRAWING

2, 4

2, 7

519 2, 52, 5 5

2, 5

06-6

FORMNO.71052A

05-7

SelectLine 13, 17, 20, 17HD, 20HD, 20TS

ASSEMBLY PARTS LIST & WIRING DIAGRAM

Ref. # Part No. Description Qty.

1 40760A Cord Power 1

2 11015A Hardware Kit 1

3 56201657 Handle, Rear 1

4 11017A Trigger Kit 1

5 11018A Wheel Kit 2

6 61726A Handle Mount 2

7 11019A Handle Clamp Kit 1

8 56201034 Switch, SPST 1

9 56201656 Handle, Front 1

10 70976A Label, Handle Kent 1

11 61373A Handle Tube 1

12 40774A Cord, Interconnect 1

13 61741A Link Arm, Right 1

14 71170A Label, SelectLine 13 1

70984A Label, SelectLine 17 1

70985A Label, SelectLine 17HD 1

70986A Label, SelectLine 20 1

70987A Label, SelectLine 20HD 1

70988A Label, SelectLine 20TS 1

15A 61844A Housing (13) 1

50972A Bumper (13) 1

15B 11006A Housing Assembly (17) 1

61715A Housing (17) 1

30381A Bumper (17) 1

15C 11007A Housing Assembly (20) 1

61714A Housing (20) 1

50784A Bumper (20) 1

Ref. # Part No. Description Qty.

16 61716A Cover, Drip (13, 17, 20, 17HD, 20HD) 1

61717A Cover, Drip (20TS) 1

17A 40761A Motor, (13, 17, 20) 1

40694A Start Capacitor (supplied with motor) 1

40695A Run Capacitor (supplied with motor) 1

53190A Start Switch (supplied with motor) 1

53645A Gearbox, (13, 17, 20) 1

69195A Coupling (supplied with gearbox) 1

17B 40763A Motor, (17HD, 20HD) 1

40694A Start Capacitor (supplied with motor) 1

53191A Run Capacitor (supplied with motor) 1

53190A Start Switch (supplied with motor) 1

53646A Gearbox, (17HD, 20HD) 1

69195A Coupling (supplied with gearbox) 1

17C 40764A Motor, (20TS) 1

51405A Brush (supplied with motor) 4

912287 Rectifier (supplied with motor) 1

46735A Speed Control (supplied with motor) 1

40851A Toggle Switch (supplied with motor) 1

53647A Gearbox, (20TS) 1

69195A Coupling (supplied with gearbox) 1

18 21088A Mainframe 1

19 61740A Link Arm, Left 1

NI 30758A Pad Driver (13) 1

NI 30638A Pad Driver (17) 1

NI 30639A Pad Driver (20) 1

06-8

COMMON NORM

OPEN

FloorMachine Schematic

TSMotor Schematic AllModels(exceptTS) Motor Schematic
