IP+HD SDI Integrated Camera
User manual V1.0
Safety Notes
Before installing the device, please read this manual carefully and follow instructions
indicated to ensure proper operation. Please keep this manual for future reference.
Please powering on the device, please check the input power voltage carefully, the camera
accepts DC12V, otherwise, it may cause damage to the camera.
Please put power, video and control cables at safe place in order not to cause malfunction to
the device.
Please put the device into use at required working temperature and humidity, working
condition of the device is 0℃~+40℃,humidity at＜90﹪. Please avoid to have unrelated
objects get into the device like corrosive liquid that may cause damage / danger.
Please avoid shock, vibration, soaking may cause to the device when transporting and
installing, otherwise, it may cause damage to the camera.
Please only refer to authorized personnel to repair the device, do not disassemble the
camera by yourself.
Only use shielded control and video cables, and the cables should be connected separately
in order to ensure proper use. Do not aim the camera lens at sunlight or strong lights that
may cause damage to the imaging system of the device.
Please use soft cloth to clean the device, do not use strong or abrasive detergent to clean
that will damage the device’s housing / lens.
Warnings
1.If you need to extend the power cable, please extend the power cable from the part on
below picture (220V/110V), do not extend from part 1 on below picture (DC12V), otherwise
it will cause unexpected damage to the device.
2.To prevent infringement of the rights of others, please confirm that it is installed and used
within the scope permitted by local law!
CONTENTS
ABOUT THE PRODUCT-------------------------------------------------------- 1
FEATURES -------------------------------------------------------------------------------- 1
LIST OF PARTS &ACCESSORIES ------------------------------------------------------------ 1
MAIN PARTS &INTERFACES ---------------------------------------------------------------- 2
INSTALLATION ---------------------------------------------------------------- 3
WALL MOUNT------------------------------------------------------------------------------ 3
OPERATION ------------------------------------------------------------------- 4
INTERNET EXPLORER ---------------------------------------------------------------------- 4
MENU------------------------------------------------------------------------------------- 4
SPECIAL PRESETS LIST ------------------------------------------------------ 5
MENU SETTINGS -------------------------------------------------------------- 6
MENU CONFIGURATION--------------------------------------------------------------------- 6
MENU EXPLANATION ----------------------------------------------------------------------- 9
VIDEO ----------------------------------------------------------------------------------- 10
EXPOSURE ------------------------------------------------------------------------------- 10
COLOR----------------------------------------------------------------------------------- 11
ZOOM FOCUS----------------------------------------------------------------------------- 11
SYSTEM---------------------------------------------------------------------------------- 12
STATUS ---------------------------------------------------------------------------------- 12
RESTORE DEFAULTS ---------------------------------------------------------------------- 13
NETWORK SETTING--------------------------------------------------------- 14
QUICK GUIDE ----------------------------------------------------------------------------- 14
IPCAMCONF ------------------------------------------------------------------------------ 15
LOCAL MONITORING AND SETUP ----------------------------------------------------------- 17
ANNEX 1 TECHNICAL SPECIFICATIONS------------------------------------ 29
ANNEX 2 SIZE AND DIMENSION -------------------------------------------- 31
TROUBLE SHOOTING ------------------------------------------------------- 32
1
ABOUT THE PRODUCT
Features
2.14MP, 1/2.8” CMOS;
H.265/H.264 video compression;
Dual stream, provide various video
resolutions;
3G-SDI full HD output at a variety of video
formats;
Built in OSD menu;
Up to 72.5°FOV;
12x/20x optical zoom;
RS-485/RS-232 control interface;
TF card recording;
Image flip.
List of Parts & Accessories
When you open the box, check all accessories
according to the packing list. In case of any
items missing, please contact your supplier.
Camera (1)
Power Adapter (1)
Wall Mount Bracket (1)
RS-232/RS-485 Connector (1)
Software Disc (1)
2
Main Parts & Interfaces
Camera
Front View
1 Camera Lens
Rear View
2 RS-232/RS-485
3 3G-SDI Interface
4 3.5mm Audio
5 USB Interface
6 TF Card Slot
7 Power Input（DC12V）
8 Power Indicator
9 Ethernet
Bottom View
10 Mounting Hole (1/4”)
Pin Definition of Control Port
No
Definition
1
RS-485B
2
RS-485A
3
GND
4
RS-232RXD
5
RS-232TXD
3
INSTALLATION
The installation type of the camera is wall
mount.
Wall Mount
1. According to diameter and position of the
4 installation holes (as shown below on
the bracket ), drill 4 holes on the wall and
fix the bracket onto the wall by using 4
screws, which should be prepared by
yourselves .
2. Use screws to fix the camera on the
bracket, fix the limit screw to lock the
camera. Make sure the camera is tightly
fixed onto the bracket before your hands
leave the camera.
Note
Before installing, make sure there is
enough space to install the camera and its
parts.
Make sure the installed place is strong and
safe enough to hold the camera and
relative parts, it is suggested that the
installed place can withstand 4 times the
weight of the camera and its relative parts.
4
OPERATION
Before operation, make sure all connections
are correct and firm.
Internet Explorer
1.Make sure PC and the camera are in the
same LAN;
2.Open Internet Explorer and enter Internet
options for security setting;
Tick below two options
options:
Meanwhile make sure the following setting
options are ticked;
3. Input IP address+ port number 88 (default is
88) in the IE address bar:http://IP:88, such
as http://192.168.18.229:88;
4.Install plug-in;
5.Name: admin Initial password: No
password.
Menu
Choose 95—Menu in the preset list to open
OSD menu.
Menu Options
In menu, press or to choose a menu
item. Press or to change current value.
