Kenmore 592. 30412 Manuel utilisateur

ENGLISH FRANÇAIS

Use & Care Guide

Manuel Du Propriétaire

Vacuum Cleaner

Aspirateur

Model, Modèle

592. 30412(Canada)

CAUTION:

Read and follow all

safety and operating

instructions before ﬁrst

use of this product.

ATTENTION :

Veuillez lire toutes les

consignes de sécurité et le

mode d’emploi avant d’utiliser

ce produit.

Printed in Korea

Imprimé en Korea

Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8

www.sears.ca

TABLE OF CONTENTS

BEFORE USING YOUR NEW VACUUM CLEANER

Please read this guide. It will help you assemble and operate your new Kenmore

vacuum cleaner in the safest and most effective way.

For more information about vacuum cleaner care and operation, call your

nearest Sears store. You will need the complete model and serial numbers when

requesting information.

Your vacuum cleaner’s model and serial numbers are located on the Model and

Serial Number Plate.

Use the space below to record the model number and serial number of your new

Kenmore vacuum cleaner.

Model No. ____________________________________________

Serial No. ____________________________________________

Date of Purchase ______________________________________

Keep this book and your sales check (receipt) in a safe place for future reference.

Before Using Your New Vacuum

Cleaner ........................................... 2

Kenmore Vacuum Cleaner Warranty

Important Safety Instructions.....4-5

Parts and Features......................... 6

Assembly Instructions ................ 7-8

Operating Instructions ................ 8-9

Power Cord .................................. 8

Floor/ Carpet Cleaning................. 9

Vacuum Cleaner Care ............. 10-13

Dust Bin Removal and

Replacement……....................... 10

Motor Filter Removal and

Replacement .............................. 11

Exhaust Filter Removal and

Replacement .............................. 11

Belt or Brushroll Removal and

Replacement .............................. 12

Light Bulb Replacement............. 13

Pet Handimate Maintenance...... 13

Troubleshooting ........................... 14

Master Protection Agreements ... 15

Requesting Service.......(back page)

ENGLISH

KENMORE VACUUM CLEANER WARRANTY

ONE YEAR LIMITED WARRANTY ON KENMORE VACUUM CLEANER

When installed, operated and maintained according to all instructions

supplied with the product, if this appliance fails due to a defect in material and

workmanship within one year from the date of purchase, return it

to any Sears store for replacement of the same item. Appliance

must be used for private family purposes, or warranty is void.

This warranty covers only defects in material and workmanship. Sears

will NOT pay for:

1. Expendable items that can wear out from normal use, including but not

limited to ﬁlters, belts, light bulbs, and bags.

2. A service technician to instruct the user in correct product installation,

operation or maintenance.

3. A service technician to clean or maintain this product.

4. Damage to or failure of this product if it is not installed, operated or

maintained according to the all instructions supplied with the product.

5. Damage to or failure of this product resulting from accident, abuse, misuse

or use for other than its intended purpose.

6. Damage to or failure of this product caused by the use of detergents,

cleaners, chemicals or utensils other than those recommended in all

instructions supplied with the product.

7. Damage to or failure of parts or systems resulting from unauthorized

modiﬁcations made to this product.

Disclaimer of implied warranties; limitation of remedies

Implied warranties, including warranties of merchantability or ﬁtness for a

particular purpose, are limited to one year or the shortest period allowed by

law. Sears shall not be liable for incidental or consequential damages. Some

states and provinces do not allow the exclusion or limitation of incidental or

consequential damages, or limitation on the duration of implied warranties of

merchantability or ﬁtness, so these exclusions or limitations may not apply to

you.

This warranty applies only while this appliance is used in Canada.

This warranty gives you speciﬁc legal rights, and you may also have other rights

which vary from state to state.

Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS IN

THIS MANUAL BEFORE

ASSEMBLING OR USING YOUR

VACUUM CLEANER.

Do not use outdoors or on wet

surfaces. Electrical shock could

occur.

Do not allow to be used as a toy.

Close attention is necessary when

used by or near children.

Use only as described in this manual.

Only use attachments designed for

this vacuum.

Do not use with damaged cord or

plug. If appliance is not working as

it should, has been dropped,

damaged, left outdoors, or dropped

into water, return it to a Sears or

other qualiﬁed service center for

inspection.

Do not pull or carry by cord, use cord

as handle, close a door on a cord,

or pull cord around sharp edges or

corners. Do not run appliance over

cord. Keep cord away from heated

surfaces.

Do not unplug by pulling on cord.

To unplug, grasp the plug, not the

cord.

Do not leave appliance when

plugged in. Unplug from outlet when

not in use and before servicing.

Do not handle plug or

appliance with wet hands.

Do not put any objects into

openings.

Do not use with any opening

blocked; keep free of dust, lint, hair,

and anything that may reduce air

ﬂow.

Keep hair, loose clothing, ﬁngers,

and all parts of body away from

openings and moving parts.

Do not pick up anything that

is burning or smoking, such as

cigarettes, matches, or hot ashes.

Do not use without Dust Bin and

ﬁlters in place.

Turn off all controls before

unplugging.

Do not use to pick-up ﬂammable

or combustible liquids, such as

gasoline,

or use in areas where they may be

present.

Keep the vacuum cleaner on the

ﬂoor. Do not use on stairs.

Do not use an extension cord with

this vacuum cleaner.

Store the vacuum cleaner indoors.

Put vacuum cleaner away after use

to prevent tripping accidents.

WARNING

Your safety is important to us. To reduce the risk of ﬁre,

electrical shock, injury to persons or damage when using

your vacuum cleaner, follow basic safety precautions

including the following:

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS

WARNING : The cords, wires,

and/or cables supplied with this

product contains chemicals,

including lead or lead compounds,

known to the state of California

to cause cancer and birth defects

or other reproductive harm. Wash

hands after using.

Using improper voltage may result

in damage to the motor and

possible injury to the user. Proper

voltage is listed on the cleaner

plate.

SAVE THESE INSTRUCTIONS

Proper assembly and safe use of your vacuum cleaner are your

responsibilities. Your vacuum cleaner is intended only for Household

use. Read this Use & Care Guide carefully for important use and safety

information. This guide contains safety statements under warning and

caution symbols. Please pay special attention to these boxes and follow any

instructions given.

Crevice Tool

Extension

Wand

PARTS AND FEATURES

It is important to know your vacuum cleaner’s parts and features

to assure its proper and safe use. Review these before using your

vacuum cleaner.

Item

Headlight DJ47-00004A

Belt 6602-001724

Part No. Accessories

Dust Brush/

Upholstery Tool Pet

Handimate

Cord Clip

Hose Clip

Vacuum

Hose

Crevice

Tool

Extension

Wand

Hose

Wand

Hose

Wand

Base

Quick

Release

Upper Cord

Wrap

Power

Cord

Combination

Dust Brush/

Upholstery Tool

Power

Switch

Handle

Release

Pedal

Handle

Carry Handle

(Dust Bin

Handle)

Pet Handimate

Cyclone

Grille

Dust Bin

Power Nozzle Height

Adjustment

Knob

Exhaust Filter

(Exhaust Filter

is located behind

the door.)

Lower Cord

Wrap

Headlight

ENGLISH

Please pay special attention to these hazard alert boxes, and follow any

instructions given. WARNING statements alert you to such dangers as ﬁre,

electric shock, burns and personal injury. CAUTION statements alert you to

such dangerous personal injury and/or property damage.

ASSEMBLY INSTRUCTIONS

WARNING

Electrical Shock Hazard

Do not plug into the electrical

supply until the assembly is

complete. Failure to do so could

result in electrical shock or injury.

CAUTION

Do not overtighten.

Overtightening could strip the

screw holes.

Do not operate the vacuum cleaner

without the screws in place.

Stand the vacuum upright and slide

the base of the handle ﬁrmly into the

grooves at the top of the vacuum body.

2. Check to be sure the handle is ﬁtted

to the vacuum body. If there is a

gap, continue to push ﬁrmly until the

handle is ﬂush.

3. Tighten securely with a screwdriver.

Place the pet handimate on the front of

the handle and push back to snap into

place as shown.

HANDLE ASSEMBLY

PET HANDIMATE PLACEMENT

HOSE ASSEMBLY

1. Align tabs on end of hose with slots

in edge of hose attachment hole on

back of vacuum. Push hose end in

and turn clockwise to lock into place.

2. Slide the end of the hose wand onto

the hose wand base.

Note: The vacuum will not operate

properly unless the hose wand

is ﬁrmly attached.

3. Snap the hose into the hose clip on

the back of the vacuum handle.

4. Attach the lower cord wrap by lining

up the tab on the base with the

corresponding notch on the back of

the vacuum and turn it clockwise as

shown.

ASSEMBLY INSTRUCTIONS

EXTENSION WAND

PLACEMENT

Place the crevice tool (A) in the top of

the extension wand. Place the

extension wand (B) in the wand holder

on the side of the vacuum cleaner.

2. Unclip the power cord plug from the

power cord. Place the power cord

into the cord clip on the body as

shown. This helps keep the power

cord out from under the vacuum

cleaner nozzle.

3. Plug the polarized power cord into a

120 Volt outlet located near the ﬂoor.

4. To store cord, turn upper cord wrap

to the up position, then wrap cord.

1. The power switch is located on the

side of the vacuum. Push the rocker

switch “ON” to vacuum, and “OFF”

when cleaning is complete.

POWER CORD

OPERATING INSTRUCTIONS

WARNING

To reduce the risk of electric

shock, this appliance has a

polarized plug (one blade is wider

than the other). This plug will ﬁt in

a polarized outlet only one way.

If the plug does not ﬁt fully in the

outlet, reverse the plug. If it still

does not ﬁt, contact a qualiﬁed

electrician to install the proper

outlet. Do not change the plug in

any way.

WARNING

Personal Injury and Product

Damage Hazard

• DO NOT plug in if switch is in the

ON position. Personal injury or

damage could result.

• DO NOT use outlets above

counters. Damage from cord to

items in surrounding area could

occur.

ENGLISH

FLOOR/CARPET CLEANING

HEIGHT ADJUST KNOB

The power nozzle brushroll can be

adjusted to clean several ﬂoor surfaces.

Note : For optimal cleaning

performance, adjust to the

lowest practical setting. If your

cleaner is difﬁcult to push, adjust

to the next higher setting.

1. Turn Height Adjustment Knob to

desired setting.

Lowest Setting

– For bare ﬂoors

Intermediate Setting

– For short and medium pile carpets

Highest Setting

– For plush pile carpet

1. Upright

– For storage and above ﬂoor

cleaning with tools.

2. Normal Cleaning

– Press handle release pedal once.

Position used for most household

ﬂoor cleaning tasks.

3. Low Cleaning

– With the vacuum in normal cleaning

position, press handle release

pedal again. Use for reaching

under low furniture such as tables,

chairs or beds.

Press the handle release pedal, located

on the lower left side of the vacuum,

with your foot to place your vacuum

into one of three cleaning positions.

CARRY HANDLE

(DUST BIN HANDLE)

Use the dust bin handle to carry from

room to room.

Carry Handle

(Dust Bin Handle)

Cyclone

Grille

DUST BIN REMOVAL AND REPLACEMENT

WARNING

Electrical Shock and Personal Injury

Hazard

Disconnect electrical supply before

servicing or cleaning the unit.

Failure to do so could result in

electrical shock or personal injury

from vacuum cleaner suddenly

starting.

VACUUM CLEANER CARE

EMPTY DUST BIN

To remove the dust bin from the cleaner

body, push the dust bin release button.

Hold dust bin over waste receptacle

and push the thumb button to release

contents.

If the suction is weak although the dust

bin is empty, open the cover and clean

the cyclone grille.

After emptying dust bin, ensure that

dust bin is attached to body properly.

After emptying dirt, ﬁt the groove

located on the lower front side of the

dust bin to the hook located on the

cleaner body.

Attach the hook located on the dust bin

handle to the vacuum body.

Table des matières

Langues :

Autres manuels Kenmore Aspirateur

Kenmore

Kenmore 37100 - Twilight Upright Vacuum Manuel utilisateur

Kenmore

Kenmore 85930 Manuel utilisateur

Kenmore

Kenmore Premalite VF6712TC Manuel utilisateur

Kenmore

Kenmore 116.35922 Manuel utilisateur

Kenmore

Kenmore Sears 175.8690090 Hom? cleaning system Manuel utilisateur

Kenmore

Kenmore 116.35622 Manuel utilisateur

Kenmore

Kenmore 116.33922 Manuel utilisateur

Kenmore

Kenmore 116.35725 Manuel utilisateur

Kenmore

Kenmore BC4002 Manuel utilisateur

Kenmore

Kenmore 116.3172 Manuel utilisateur

Kenmore

Kenmore 116.29229 Manuel utilisateur

Kenmore

Kenmore 116.30608C Manuel utilisateur

Kenmore

Kenmore Complete SSV Manuel utilisateur

Kenmore

Kenmore AllergenSeal DU2109 Manuel utilisateur

Kenmore

Kenmore 116.23285C Manuel utilisateur

Kenmore

Kenmore KW3010 Manuel utilisateur

Kenmore

Kenmore 116.32923 Manuel utilisateur

Kenmore

Kenmore CROSSOVER DU3017 Manuel utilisateur

Kenmore

Kenmore 116.21714 Manuel utilisateur

Kenmore

Kenmore PowerMate Nozzle Manuel utilisateur

Kenmore

Kenmore 116.23106C Manuel utilisateur

Kenmore

Kenmore 116.28014 Manuel utilisateur

Kenmore

Kenmore CROSSOVER DU3017 Manuel utilisateur

Kenmore

Kenmore 116.23104C Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
