Ken A Vision MVP - 100 Manuel
Ken-A-Vision
®
VIDEO CAMERAS
Ken-A-Vision
®
VIDEO CAMERAS
Ken-A-Vision was founded with the foresight of
creating a company which would invent, design,
and manufacture high quality visual equipment
for demonstration, presentation, and education
applications. Our name is known and respected
world-wide. “KEN” is taken from an Anglo-Saxon
word meaning
knowledge
, and “A” comes from
the Latin word meaning
through
. Our mission, like
our name, is to create
knowledge through vision.
Contact us today
1-800-334-8407
www.ken-a-vision.com
Ken-A-Vision®has
manufactured high quality
products for over 50 years!
Ken-A-Vision®
Video Camera Table of Contents
PupilCAM®...........................................................................3
Aqua Flex ............................................................................4
Video Flex®Explorer 2100....................................................5
Video Flex®7100 .................................................................6
Video Flex®7300 .................................................................7
Video Flex®7600 .................................................................8
MVP-100 .............................................................................9
BookCAM ..........................................................................10
ShopCAM..........................................................................10
Vision Viewer™..................................................................11
Video Comprehensive Scope...............................................12
MP2 ..................................................................................13
Video Camera Accessories..................................................14
2
PupilCAM
Make your microscope so
the whole classroom can
see with the PupilCAM®! The
Ken-A-Vision®PupilCAM is
a video microscope camera
that connects directly to
your classroom monitor or
multimedia projector. It
has a pre-attached five-foot
video cable and a built-in
microscope adapter. The
adapter provides a secure
and precise alignment to your
microscope or stereoscope.
PupilCAM
Features
• One Piece Construction -
No Parts to Lose
• Plug-N-Play
• 350 Lines of Resolution
SPECIFICATIONS
Catalog # 1401KRN 1401KEN
Output Composite (NTSC or PAL) Composite (NTSC or PAL)
Connection Video Video
Lens 8mm Glass 8mm Glass
Eyepiece Built-in Adapter (25mm – 34mm) Built-in 10x
Resolution 350 Lines 350 Lines
Light Sensitivity 3.0 Lux 3.0 Lux
Cable Length Pre-attached 5' (1.5 meter) Pre-attached 5' (1.5 meter)
Video Cable Video Cable
Warranty 1 Year 1 Year
Specifications subject to change without notice
1-800-334-8407
www.ken-a-vision.com
3
Aqua Flex
1-800-334-8407
www.ken-a-vision.com
Aqua Flex
Ken-A-Vision®created the
Aqua Flex with classroom
underwater observation
in mind. With its patented
light technology that can
see through some turbidity,
the Aqua Flex is the ideal
addition to any field trip,
nature center or to monitor
an aquarium.
4
Features
• Water Proof
• Illumination – Powered by Ken-A-Vision Technology
• 33' (10 meters) Cable
• Optional Accessories:
Submersible Extension Rod Adapter
USB Adapter
Battery Pack
Applications
• Outdoor Aquatic Systems
• Locating Benthic Organisms
• Aquaria
SPECIFICATIONS
Catalog # 1470
Output Composite (NTSC or PAL)
Connection Video RCA
Resolution 350 Lines
Focal Distance 10cm to infinite, fixed
Cable Length 33' (10 meters) Video
Enclosure Aluminum, Water Proof
Warranty 1 Year
Specifications subject to change without notice
Video Flex Explorer
The Video Flex®Explorer will
meet all your needs without
exceeding your budget. It’s the
ideal solution when seeking
portability and versatility. The
40-inch neck can be coiled
into a base for microscope
applications, or can be
wrapped around a telescope,
object, or person to provide
a unique point of view.
Video Flex Explorer
1-800-334-8407
www.ken-a-vision.com
5
Features
• Baseless Construction
• Light Weight
• Poly-Carbonate Build
• C-Mount Lens
• Quick Focus™
• 450 Lines of Resolution
• Portable
SPECIFICATIONS
Catalog # 2100
Output Composite (NTSC or PAL)
Connection Video RCA
Lens 8mm Interchangeable C-mount
Resolution 450 Lines
Light Sensitivity 1.5 Lux
Magnification 50:1 or Greater
Focal Distance 1⁄4" (6mm) to Infinity
Cable Length 12' (3.7 meters) Video
Warranty 2 Years
Specifications subject to change without notice
1-800-334-8407
www.ken-a-vision.com
6
Video Flex 7100
Make learning fun with the
Video Flex®7100! With a
magnification power of up
to 50x, the 7100 can even
replace a microscope for
many applications. The Ball
and Socket head provides
maximum flexibility. Theft
protection is provided through
a Kensington®security slot.
Video Flex 7100
Features
• Triangular Base
• 500 Lines of Resolution
• Poly-Carbonate Build
• C-mount Lens
• Quick Focus™
• Microphone
• 1.5 Lux
• Kensington Slot
SPECIFICATIONS
Catalog # 7100
Output Composite (NTSC or PAL)
Connection Video RCA
Lens 8mm Interchangeable C-mount
Resolution 500 Lines
Light Sensitivity 1.5 Lux
Magnification 50:1 or Greater
Focal Distance 1⁄4" (6mm) to Infinity
Audio Yes
Button Controls No
Cable Length 12' (3.7 meters) Audio/Video
Warranty 5 Years
Specifications subject to change without notice
Video Flex 7300
Video Flex 7300
The Video Flex®7300 includes
all the features of the 7100,
plus manual contrast controls
to adjust to any lighting
condition, Positive/Negative
switch reverses the video
image to highlight details,
and the Fluorescent Control
eliminates the pulse caused by
antiquated fluorescent lighting.
This Video Flex also comes
with a Discovery Scope Kit
and Carry Case.
Features
• Triangular Base
• Poly-Carbonate Build
• C-mount Lens
• Quick Focus™
• Microphone
• Discovery Scope Kit
• Carry Case
• Kensington Slot
• 1.5 Lux
SPECIFICATIONS
Catalog # 7300
Output Composite & S-Video (NTSC or PAL)
Connection Video RCA, Audio RCA & S-Video
Lens 8mm Interchangeable C-mount
Resolution 500 Lines
Light Sensitivity 1.5 Lux
Magnification 50:1 or Greater
Focal Distance 1⁄4" (6mm) to Infinity
Audio Yes
Button Controls Contrast Control
Positive/Negative Control
Fluorescent Control
Cable Length 12' (3.7 meters) Audio/Video
Warranty 5 Years
Specifications subject to change without notice
1-800-334-8407
www.ken-a-vision.com
7
1-800-334-8407
www.ken-a-vision.com
8
Video Flex 7600
The Video Flex®7600
connects to the USB port of
any computer to transmit or
capture images. The 7600 can
simultaneously display to a
computer, TV monitor and a
multimedia projector. This
means that a digital signal
can be received and “frozen”
in a computer while live action
from video signal continues
on the monitor.
Video Flex 7600
Features
• USB, Composite,
& S-Video outputs
• C-mount Lens
• Quick Focus™
• Microphone
• Discovery Scope Kit
• Carry Case
• Adjustable Contrast
• Positive / Negative Switch
• Fluorescent Control
• Kensington Slot
SPECIFICATIONS
Catalog # 7600
Output Digital, Composite & S-Video (NTSC or PAL)
Connection Video RCA, Audio RCA, S-Video & USB 1.1
Lens 8mm Interchangeable C-mount
Resolution 500 Lines
Light Sensitivity 1.5 Lux
Magnification 50:1 or Greater
Focal Distance 1⁄4" (6mm) to Infinity
Audio Yes
Button Controls Contrast Control, Positive/Negative Control, Fluorescent Control
Software Applied Vision™ Software for Windows®
Ken-A-Vision®Capture for Macintosh®
Cable Length 12' (3.7 meters) Audio/Video
6' (1.8 meters) UBS
Warranty 5 Years
Specifications subject to change without notice
9
1-800-334-8407
www.ken-a-vision.com
MVP-100
The MVP-100, is the first of
its kind to deliver a durable
exterior finish boasting
aluminum construction to meet
the rigors of daily use. The
Multi Video Product or MVP
is a line of high resolution
cameras with multiple signal
outputs. The MVP-100 has high
resolution output signals for
RCA, USB, VGA and Network.
This camera comes complete
with Applied Vision™ Software
for USB. The RJ-45 or network
output works with Internet
Explorer and does not require
any installed software. The RCA output is ideal for VCRs,
televisions or multimedia projectors, while the VGA input and
output (15 pin D Sub) is designed to maximize the interaction
of your computer and multimedia projector. Manage of your
audio visual electronics through the easy-to-use touch pad.
See the Ken-A-Vision Digital Camera Catalog for
more information!
MVP-100
SPECIFICATIONS
Catalog # MVP-100
Output / Connection Network: RJ-45
Digital: USB
Video: RCA & VGA (In & Out)
Audio: RCA
Lens 8mm glass
Resolution 800 X 600
Light Sensitivity 1.5 LUX
Magnification 50:1 or greater
Focal Distance 6mm to infinity
Audio Yes (Microphone Jack)
Button Controls Positive/Negative, Mirror, Dark, Bright, Computer, Iris
Freeze, XGA, Split
Software Applied Vision™ Software for Windows®
Built-in Ken-A-Vision®Viewer – Network Interface
Warranty 5 Years
Specifications subject to change without notice
